HCT-9291D Upright Walker

Product Information:
Product Name: Upright Walker
Model: HCT-9291D (Gima 43172)
Manufacturer: Foshan HCT Medical Equipment Co., Ltd
Address: No.11, Dongyang 4th Road, Southern China Hardware Industry
Base, Danzao Town, Nanhai District, Foshan City, Guangdong
Province, China
Distributor: SUNGO Europe B.V.
Address: Olympisch Stadion 24, 1076DE Amsterdam, Netherlands
Gima S.p.A
Address: Via Marconi, 1 – 20060 Gessate (MI) – Italy
Email: [email protected], [email protected]
Website: www.gimaitaly.com
Material Components:
– Frame: Aluminum
– Wheels: PVC
– Handrail: Foam Padded PU material
– Handrest: Nylon and polyester
– Seat: Foam Padded PU material
Product Usage Instructions:
1. Before using the upright walker, visually check the device for
any anomalies. If there are any issues, immediately contact the
dealer from whom it was purchased. 2. The choice of the type of aid
and necessary settings for use should be determined by qualified
medical and technical staff, based on the user’s condition. 3. To
ensure safety, follow all safety information and instructions
provided. 4. Before use, check that all wheels are tight and the
height adjustment button is firm. 5. Fully deploy the walker and
pay attention to the surrounding area when using it. 6. The
backrest is designed to provide back support while seated but
should not be used to support full body weight. Avoid leaning while
sitting to prevent falls. 7. Before sitting on the seat, ensure
that the brakes are in the locked position. 8. The brakes are used
to prevent the wheels from rolling, but they may not stop the
walker from moving if it is pushed. 9. The walker is not intended
to be self-propelled while seated and should only be used as a
walking aid for individuals. It should not be used as a wheelchair.
10. Do not use the walker to walk backwards, on gradients, or to
climb stairs, curbs, or big obstacles as there is a serious risk of
fall or injury. 11. The seat should not be used to transport people
or large objects. 12. Do not sit on the seat when the walker is on
an incline. 13. Do not push the walker while the brakes are
enabled. 14. Avoid putting your hand into the folding area of the
walker to prevent pinching. 15. When sitting on the seat, do not
let yourself fall onto it but rather sit slowly and in a controlled
manner. 16. Refer to the component diagram for identification of
different parts of the walker.

View Fullscreen

PROFESSIONAL MEDICAL PRODUCTS
DEAMBULATORE IN PIEDI COMPLETAMENTE REGOLABILE alluminio – rosso FULLY ADJUSTABLE STANDUP ROLLATOR – aluminium – red DÉAMBULATEUR DEBOUT COMPLÈTEMENT RÉGLABLE aluminium – rouge ANDADOR DE PIE TOTALMENTE AJUSTABLE – aluminio – rojo
Manuale di istruzioni – Instruction Manual – Mode d’emploi – Manual de instrucciones
È necessario segnalare qualsiasi incidente grave verificatosi in relazione al dispositivo medico da noi fornito al fabbricante e all’autorità competente dello Stato membro in cui si ha sede. All serious accidents concerning the medical device supplied by us must be reported to the manufacturer and competent authority of the member state where your registered office is located. Il est nécessaire de signaler tout accident grave survenu et lié au dispositif médical que nous avons livré au fabricant et à l’autorité compétente de l’état membre où on a le siège social. Es necesario informar al fabricante y a la autoridad competente del Estado miembro en el que se encuentra la sede sobre cualquier incidente grave que haya ocurrido en relación con el producto sanitario que le hemos suministrado.
HCT-9291D (Gima 43172)
Foshan HCT Medical Equipment Co., Ltd No.11,Dongyang 4th Road, Southern China Hardware Industry Base, Danzao Town, Nanhai District, Foshan City, Guangdong Province, China Made in China
SUNGO Europe B.V. Olympisch Stadion 24, 1076DE Amsterdam, Netherlands Gima S.p.A Via Marconi, 1 – 20060 Gessate (MI) – Italy [email protected] – [email protected] www.gimaitaly.com

M43166-M-Rev.0-10.22

ENGLISH

WARNINGS
Before carrying out any operation, visually check the integrity of the device. Where the product presents anomalies, immediately contact the dealer from whom it was purchased. We assumes no responsibility for the misuse of the device.
DESCRIPTION UPRIGHT WALKER
HCT-9291D upright walker features compact folding design and aluminum stable frame and fully adjustable armrest, aimed at helping users to stand upright and Look ahead with better support.
The Upright Walker requires assembly before use. Please follow the instructions below:
MATERIAL COMPONENTS

Frame Wheels Handrail Handrest Seat

Aluminum PVC Foam Padded PU material Nylon and polyester

PREPARING FOR USE
The choice of the type of aid and the necessary settings for use must be carried out by medical and technical staff qualified, depending on the pathology and user terms and conditions.
1. To ensure your safety in using the the upright walker, the following safety information and all instructions must be followed.
2. Check whether all wheels are tight before use.
3. Check whether the height adjustment button is firm.
4. Make sure the walker is fully deployed.Pay attention to the surrounding area when using a walker.
5. The backrest is intended to provide back support while seated. The backrest is not intended to support full body weight. Avoid Leaning while sitting as this may result in fall.
6. The brakes MUST be in the locked position BEFORE sitting on the seat.
7. Brakes are to be used to keep the wheels from rolling. However, it may not prevent the walker from moving if it is pushed.
8. DO NOT seLf-propel the walker while seated. Walker are intended to use as a walking aid for individual only and are NOT TO BE USED AS A WHEELCHAIR.
9. DO NOT use the walker to walk backwards, down gradients or to climb stairs, curbs or to go over big obstacles. Serious risk of fall or injury may occur.
10. DO NOT use the seat to transport people or Large objects.
11. DO NOT sit on the seat when the walker is on an incline.
12. DO NOT push the walker while brakes are enabled.
13. DO NOT put your hand into the folding place of the walker to avoid being pinched.
14. DO NOT Let yourself fall on the seat of the walker, but always sit slowly on the seat in a controlled manner.

ENGLISH

COMPONENT

1. Handgrip 2. Backrest 3. Break wire 4. Shopping nylon bag 5. 10 inch front wheels 6. Quick-release screw 7. 8 inch rear wheels 8. Obstacle Aid Pedal 9. Brake cover 10. Cane holder 11. Joint part for folding design 12. Padded Seat 13. Push button for height adjustment 14. Foam handrail 15. Knob to adjust backrest height 16. Knob to adjust handle Length 17. Arm holder

TECHNICAL SPECIFICATIONS

Width between the handles

19.7 in

Overall width

24.6 in

Overall depth

29.5 in

Seat area

9.8*18 in

Seat height

21.6 in

Adjustable handle height

40.3-45.5in

Max. user weight

300Lb

Weight

22.4 lb

Front wheels

10in

Rear wheels

8 in

9
SAFETY INSTRUCTIONS
The Upright Walker requires assembly before use. Please follow the instructions below: 1. Identify the partially assembled base piece, unfold it, and ensure the seat is flat and Locked into place.

ENGLISH

2. Inserting and lock the rear wheels into position

5. Insert the 2 hand grips into the designated slot within the arm bars. Choose the desired Length by Lining up the scale number where you want the Length to be and secure with the knob by screwing it tight.

3. Attach the 2 front wheels to the seat inserting and Lock it into position.
6. Put handrail into the tube and Lock into the position.

4. Locate the 2 handles which comes with a backrest and insert them into the two tubes at two sides of the walker.Make sure it is Locked into the position.

7. Pull out two roll tubes at the front of the seat, then hang the bag through the two straps of the storage bag.

ENGLISH

HOW TO ADJUST ARMHOLDER
HEIGHT
There is a push button at each tube where the handle height can be adjusted up or down by pressing the button and snapping into place when desired height is reached.

HOW TO ADJUST THE HEIGHT OF THE BACKREST

OPERATING THE HAND BRAKES
Pull in the hand brake to slow or stop the walker. Push out the hand brakes until they”cLick” to lock the walker in position. Please attention: Brakes must be applied in the lock position when seated.pre-check the Lock by pushing.for- ward on the upright.
FOLDING THE UPRIGHT WALKER
To fold the upright walker, simply pull up the strap at the middle of the seat. Then pull back forward down the upright walker into flat. There are two screws at each sides of handle bar, backrest height can be adjusted up or down by Loosen the screws and tighten them when desired height is reached.

BRAKE ADJUSTMENT:
Turn the adjusting screw anti-clockwise to increase the tension then Lock the adjustment Locking nut clockwise whilst holding the adjuster screw stationary.
MAINTENANCE
Over a period of time the brake cables may stretch, and if no further adjustments can be made the cables should be replaced. Seek the help of your dealer when replacing brake cables. The castors should be checked that they are secure each time before using the walker. Also, check the brakes operate correctly and the handles and hand knobs are secure. Should any part of the walker appear Loose or insecure discontinue use until it is inspected by an authorized dealer.
The following shows the maintenance schedule:
WEEKLY · Check brake for malfunction · Check all wheels and castors for Loose bolts
and nuts
PERIODICALLY · Check handgrips for wear · Check frame bolts are secure · Check front and rear axle bolts are secure · Check tyres for wear or cracks
YEARLY Once a year take your walker to an authorised repai¬rer for a full check, clean, service and Lubrication of all moving parts Wheels Hand grips Brake Cables Brake Lever Bearings Knobs

ENGLISH

CLEANING
Your walker can be cleaned with a damp cloth or sponge and warm soapy water. Domestic anti-bacterial surface cleaners may be used if required. Care should be taken not to leave any cleaning residues on the handgrips or seat which may Leave them slippery when used. Do not use scouring pads or scrapers as this may damage surface coatings.

WARNINGS! 1. Maximum working Limit 300Lb. 2. Do NOT stand on this product. 3. Ensure both push handles are adjusted to the same height. 4. Seek advice from a trained health care professional or approved Freedom Healthcare dealer for
height adjust merit of this product. 5. Always maintain a safe distance between your walker and other pedestrians or objects. 6. Some components may cause harm or damage when they come into contact with other objects. 7. Do not attempt to replace the wheels or castors of your walker. If they are faulty or require a repla-
cement please contact an authorized repairer. 8. Ensure that your walker is opened fully (folding scissor arm is straight) before using it. 9. Ensure that your fingers are clear from the scissor arm when folding.

UPRIGHT WALKER USER MANUAL
We warrant the included accessories against defects in materials and workmanship for one year from the date of original retail purchase. We do not warrant against damage caused by accident or abuse. If you have any questions, please contact us.

Caution: read instructions (warnings) carefully
Manufacturer

Medical Device compliant with Regulation (EU) 2017/745
Non-sterile

Product code
Consult instructions for use

Keep away from sunlight

Keep in a cool, dry place

Medical Device

Serial number

Authorized representative in the European community

Date of manufacture

Lot number

Importer

GIMA WARRANTY TERMS
The Gima 12-month standard B2B warranty applies.
