PICO OHM Power Line
Product Information
The PICO OHM is a device that can control non-Lumitec RGB
lighted devices. It needs to be connected to a Lumitec POCO digital
controller output channel to function. The Lumitec POCO and
compatible interface device such as MFD, smartphone, tablet, etc.
can be used to issue PLI commands to the module. The PICO OHM has a
status LED indicator that gives off different messages depending on
its operation. It has a 2-wire power input and a 4-wire RGBW output
with specific color codes for each wire. The voltage input for the
device is 12VDC with a maximum current draw of 0.4 amps for RGB
output. For more information on the POCO system, visit www.lumiteclighng.com/poco-quick-start.
For warranty support, visit www.lumiteclighting.com/support/warranty.
Product Usage Instructions
- Connect the PICO OHM to a Lumitec POCO digital controller
output channel. - Use a compatible interface device such as MFD, smartphone,
tablet, etc. to issue PLI commands to the module. - Observe the status LED indicator for the following messages:
- Off – No power or no initial PLI command from POCO.
- Green steady – Power applied and output enabled.
- Green flash – Power applied and waiting for PLI command from
POCO.
- Connect the 2-wire power input with the red wire as positive
(V+) POCO output channel and the black wire as negative (V-)
input. - Connect the 4-wire RGBW output with the yellow wire as the main
RGB LED positive output, the red wire as the red RGB LED negative
output, the green wire as the green RGB LED negative output, and
the blue wire as the blue RGB LED negative output. - The voltage input for the device should be 12VDC only, with a
maximum current draw of 0.4 amps for RGB output.
Operation and Installation Instructions:
PLI (POWER LINE INSTRUCTION)
The PICO OHM can be used to control Non-Lumitec RGB lighted
devices. The PICO OHM must be connected to a Lumitec POCO digital controller output channel to funcon. The Lumitec POCO and compable interface device (e.g. MFD, smart phone, tablet, etc.) can be used to issue PLI commands to the module. For more informaon on the POCO system, visit:
www.lumiteclighng.com/poco-quick-start
Operation and Installation Instructions:
PLI (POWER LINE INSTRUCTION)
The PICO OHM can be used to control Non-Lumitec RGB lighted
devices. The PICO OHM must be connected to a Lumitec POCO digital controller output channel to funcon. The Lumitec POCO and compable interface device (e.g. MFD, smart phone, tablet, etc.) can be used to issue PLI commands to the module. For more informaon on the POCO system, visit:
www.lumiteclighng.com/poco-quick-start
STATUS LED INDICATOR MESSAGES
OFF
GREEN STEADY GREEN FLASH
No Power, Or, No Inial PLI Command From POCO
Power Applied And Output
Enabled Power Applied And Waing For PLI Command From POCO
STATUS LED INDICATOR MESSAGES
OFF
GREEN STEADY GREEN FLASH
No Power, Or, No Inial PLI Command From POCO
Power Applied And Output
Enabled Power Applied And Waing For PLI Command From POCO
2-WIRE POWER INPUT: RED = POSITIVE (V+) POCO OUTPUT CHANNEL BLACK = NEGATIVE (V-) INPUT
4-WIRE RGBW OUTPUT: YELLOW = MAIN RGB LED POSITIVE OUTPUT RED = RED RGB LED NEGATIVE OUTPUT GREEN = GREEN RGB LED NEGATIVE OUTPUT BLUE = BLUE RGB LED NEGATIVE OUTPUT
VOLTAGE INPUT: 12VDC ONLY MAX CURRENT DRAW: 0.4 AMPS (RGB OUTPUT)
3 Year Limited Warranty The product is warranted to be free from defects in workmanship and materials for a period of three years from the date of original purchase. Lumitec is not responsible for product failure caused by abuse, neglect, improper installation, or failure in applications other than those for which it was designed, intended, and marketed. Should your Lumitec product prove defective during the warranty period, promptly notify Lumitec and return product with freight prepaid. Lumitec will, at its option, repair or replace the product or defective portion without charge for parts or labor, or, at Lumitec’s option, refund purchase price. For more warranty information, visit:
www.lumiteclighting.com/support/warranty
600833
2-WIRE POWER INPUT: RED = POSITIVE (V+) POCO OUTPUT CHANNEL BLACK = NEGATIVE (V-) INPUT
4-WIRE RGBW OUTPUT: YELLOW = MAIN RGB LED POSITIVE OUTPUT RED = RED RGB LED NEGATIVE OUTPUT GREEN = GREEN RGB LED NEGATIVE OUTPUT BLUE = BLUE RGB LED NEGATIVE OUTPUT
VOLTAGE INPUT: 12VDC ONLY MAX CURRENT DRAW: 0.4 AMPS (RGB OUTPUT)
3 Year Limited Warranty The product is warranted to be free from defects in workmanship and materials for a period of three years from the date of original purchase. Lumitec is not responsible for product failure caused by abuse, neglect, improper installation, or failure in applications other than those for which it was designed, intended, and marketed. Should your Lumitec product prove defective during the warranty period, promptly notify Lumitec and return product with freight prepaid. Lumitec will, at its option, repair or replace the product or defective portion without charge for parts or labor, or, at Lumitec’s option, refund purchase price. For more warranty information, visit:
www.lumiteclighting.com/support/warranty
600833
