Zephyr Prw24c32cg Presrv French Door Dual Zone Cooler Instruction Manual

PRW24C32CG Presrv French Door Dual Zone Cooler

Product Information:

Product Name: PRW24C32CG PresrvTM French Door
Dual Zone Cooler

Product Model: PRW24C32CG

Product Description: The PRW24C32CG PresrvTM
French Door Dual Zone Cooler is a high-quality cooler designed to
preserve and store your beverages and wines. With its dual-zone
feature, you can independently control the temperature of each
zone, allowing you to store different types of beverages at their
ideal temperature. The cooler comes with various components and
accessories to ensure optimal performance and convenience.

Product Usage Instructions:

1. Before using the PRW24C32CG PresrvTM French Door Dual Zone
   Cooler, ensure that it is placed on a level surface and the
   leveling legs are adjusted for stability.
2. Connect the cooler to a power source using the provided power
   cord.
3. To open the cooler, gently pull the right or left door handle,
   depending on the desired zone.
4. Adjust the temperature settings for each zone using the control
   panel located inside the cooler. Refer to the user manual for the
   recommended temperature ranges for different types of
   beverages.
5. To store beverages, place them on the sliding wooden shelves
   inside the cooler. The sliding rail set allows for easy access and
   customization of shelf positions.
6. Ensure that the carbon filters (Z0F-C004) are properly
   installed to maintain air quality inside the cooler.
7. The door lock (50180012) can be used to secure the cooler and
   prevent unauthorized access. Keep the door lock key (15000019) in a
   safe place.
8. To clean the cooler, disconnect it from the power source and
   remove all items from inside. Use a mild detergent and a soft cloth
   to clean the interior and exterior surfaces. Avoid using abrasive
   cleaners or solvents.
9. Regularly check and clean the condenser (54270001) and
   condenser cover (54210015) to ensure proper functioning of the
   cooler.
10. In case of any issues or malfunctions, refer to the magnet
    switch (11040033) and contact customer support for assistance.

For more detailed instructions on installation, maintenance, and
troubleshooting, please refer to the complete user manual provided
with the PRW24C32CG PresrvTM French Door Dual Zone Cooler.

PRW24C32CG
PresrvTM French Door Dual Zone Cooler

PRW24C32CG

Ref # 1 2 3 4 5 6 7 8 9 10 11 12 13 15 16 17 18 18.1 19 20 21 22 23 23.1 24 25 26 27 28 29

Part # 56300004 11030118 56060005 56220051 50330031 56130041 12160006 11030119 11030120 50330010 56200105 11010162 11010163 54180062 54180063 54240015 54280001 54280002 12130032 54170007 54210017 54210014 11050009 11050007 54140283 12010011 52150014 56200125 52050031 54210038

PresrvTM

Description Dryer Filter Power Cord Solenoid Valve Anti Vibration Gasket Compressor Connecting Pipe Drip Tray Compressor Compressor Ground Wire Wire Connector Sealing Tube Main Control Board Box Main Power Control Board Display Control Board Upper Left Hinge Upper Right Hinge Evaporator Heater, Left Heater, Right Fan Air Duct Board Fan Cover Sensor Cover Temperature Sensor, Left Zone Temperature Sensor, Right Zone LED Light Holder LED Light LED Light Cover Display Control Box Display Panel Decal Door Axis Cover

Qty. 1 1 1 5 1 1 1 1 1 1 1 1 1 1 1 2 1 1 2 2 2 2 1 1 1 6 6 1 1 2

30

50330037

Door Axis Pin

2

31

54190056

Door Axis Plate, Right

1

32

50230033

Door, Right

1

32.1

50280003

Door Handle

1

32.2

56220045

Door Gasket

1

33

54050091

Door Lock Hook

2

34

50230034

Door, Left

1

34.1

50280003

Door Handle

1

34.2

56220045

Door Gasket

1

35

54220011

Magnet

2

36

54190057

Door Axis Plate, Left

1

37

50150019

Sliding Wooden Shelf

12

38

50320042

Sliding Rail Set

12

39

Z0F-C004

Carbon Filter

2

40

50260021

Kick Plate

1

41

50180012

Door Lock

1

42

11040033

Magnet Switch

1

43

54180066

Lower Right Hinge

1

44

54140345

Cabinet Bracket

2

45

50350008

Leveling Leg

4

46

54180067

Lower Left Hinge

1

47

54140284

Cabinet Support Bracket

1

48

54270001

Condensor

1

49

54210015

Condensor Cover

1

50

50330032

Gas Return Pipe

1

50.1

50330018

Gas Return Pipe

1

51

54210016

Fan Cover

1

52

12130032

Fan

1

53

54190058

Compressor Support Plate

1

54

50330038

Drain Pipe

2

55

15000019

Door Lock Key

1

JAN23.0101
