High Capacity Boltless Steel Shelving
Product Information: High Capacity Boltless Steel Shelving
The High Capacity Boltless Steel Shelving is a sturdy and
durable shelving unit that can be used for organizing and storing a
variety of items. It is designed with five support bars for each
shelf, providing a high weight capacity and stability. The shelving
unit is made of steel and is easy to assemble without the need for
bolts or screws.
Product Features:
- High weight capacity
- Boltless assembly
- Sturdy steel construction
- Five support bars per shelf
- Easy to assemble
Warnings:
It is important to review the warnings on the back of the user
manual before using the shelving unit. It is also recommended to
not assemble the unit alone.
Product Usage Instructions:
- With the help of others holding up the posts, begin by
installing the bottom outer shelf support beams by inserting the
knob through the wide circle of the slots on the posts and sliding
down. It is important to start from the bottom. - While continuing to hold the 4 posts, install the other 3
support beams for the bottom shelf. Continue to physically hold the
posts until at least 2 shelves are installed. - Install the middle support bar in the same manner that the
outer support beams were installed in the post. Align the holes in
the support bars with the knobs on the middle support bar, then
slide the support bar down. - Once all 5 support bars are secure, gently put the shelf plate
over the support bars. Tilt if necessary to secure one side first
before gently laying it directly on the support bars. - Repeat the above steps for the remaining shelves. Do not begin
another shelf assembly until all steps for the previous steps are
completed. It is recommended to install the bottom shelf first,
then the top, then fill out the remaining shelves from the second
lowest to the second highest.
Note: If you encounter any issues during assembly or usage of
the shelving unit, please contact customer service at
1-800-645-2986 for assistance.
User’s manual
Customer Service US: 1-800-645-2986
Manual del usuario
Servicio de atención al Cliente US: 1-800-645-2986
High Capacity Boltless Steel Shelving
Assembly Instructions With help from others holding up the posts, begin by installing the bottom outer shelf support beams by inserting the knob through the wide circle of the slots on the posts and sliding down.
IT IS IMPORTANT TO START FROM THE BOTTOM
Manuel de l’utilisateur
Service à la clientèle Canada: 888-645-2986
While continuing to hold the 4 posts, install the other 3 support beams for the bottom shelf. Continue to physically hold the posts until at least 2 shelves are installed.
WARNING! DO NOT ASSEMBLE
ALONE
Install the middle support bar in the same manner that the outer support beams were installed in the post. Align the holes in the support bars with the knobs on the middle support bar, then slide the support bar down.
BEFORE USE, REVIEW WARNINGS ON BACK OF PAGE
1
High Capacity Boltless
Once all 5 support bars are secure, gently put the shelf plate over the support bars. Tilt if necessary to secure osunpepeodrgtse. first before gently laying directly on the
Assembly Instructions
Repeat the above steps for the remaining shelves. Do not begin another shelf assembly until all steps for the previous steps are completed. It is recommended to install the bottom shelf first, then the top, then fill out the remaining shelves from the second lowest to the second highest.
2
