APMS01 Premier Modular Storage System
Product Information
The Premier Modular Storage System is a heavy-duty high-end
workshop storage system designed to enhance any garage or workshop.
It is versatile and durable, with a steel construction that will
last for years. The system can easily be adjusted to specific
needs, allowing users to purchase a simple base cabinet or create a
full workshop storage system. Please read the following
instructions carefully to ensure safe and proper usage of the
product.
Specifications
| Model No | Overall Size (W x D x H) | Small Drawer | Large Drawer | X-Large Drawer | Full Width Large Drawer |
|---|---|---|---|---|---|
| APMS01 | 775 x 610 x 955mm | – | – | – | – |
| APMS02 | 1550 x 610 x 955mm | – | – | – | – |
| APMS03 | 775 x 610 x 955mm (x3) | 670 x 535 x 55mm (x2) | 670 x 535 x 130mm (x1) | 670 x 535 x 205mm | – |
| APMS04 | 1550 x 610 x 955mm (x6) | 670 x 535 x 55mm (x2) | 670 x 535 x 130mm (x2) | 670 x 535 x 205mm (x1) | 1445 x 535 x 125mm |
Product Usage Instructions
Safety
- Ensure Health & Safety, local authority, and general
workshop practice regulations are adhered to when using these
cabinets. - Locate the cabinets in a suitable work area.
- Keep the work area clean, uncluttered, and ensure there is
adequate lighting. - Use the cabinets on level and solid ground, preferably
concrete. - Keep the cabinets clean and tidy in accordance with good
workshop practice. - Keep children and unauthorized persons away from the work
area. - DO NOT use these cabinets for any purpose other than that for
which they are designed. - DO NOT use the cabinets outdoors.
- DO NOT place the cabinets in a damp or wet location or an area
where there is condensation. - DO NOT clean the cabinets with any solvents which may damage
the surfaces or the protective coating.
Assembly
The only assembly required is to fit the worktop supplied
separately and the door handles (if applicable).
- Fit the worktop by screwing from underneath using 4 x hex
flange bolts for standard models or 6 x hex flange bolts for wider
models. - Screw on the handles from the rear using cross head
screws. - If applicable, remove drawers by pulling them out fully and
pushing the black lever in each drawer runner up or down, then
pulling out the drawer to release.
Environment Protection
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories, and packaging should be sorted,
taken to a recycling center, and disposed of in a manner compatible
with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if
applicable) into approved containers and dispose of the product and
fluids according to local regulations.
PREMIER MODULAR STORAGE SYSTEM MODEL NO’S: APMS01, APMS02, APMS03, APMS04
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to instruction
manual
Wear protective
gloves
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using these cabinets.
9
Locate the cabinets in a suitable work area.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use the cabinets on level and solid ground, preferably concrete.
9
Keep the cabinets clean and tidy in accordance with good workshop practice.
9
Keep children and unauthorised persons away from the work area.
8
DO NOT use these cabinets for any purpose other than that for which they are designed.
8
DO NOT use the cabinets outdoors.
8
DO NOT place the cabinets in a damp or wet location or an area where there is condensation.
8
DO NOT clean the cabinets with any solvents which may damage the surfaces or the protective coating.
2. INTRODUCTION
Heavy-duty high end Modular Workshop Storage System with an appearance to enhance any garage or workshop. Versatile and durable steel construction that will last for years. Easily adjusts to specific needs; purchase a simple base cabinet or create a full workshop storage system.
3. SPECIFICATION
MODEL NO: Overall Size (W x D x H): Small Drawer Large Drawer X-Large Drawer Full Width Large Drawer
APMS01 775 x 610 x 955mm
APMS02 1550 x 610 x 955mm
APMS03 775 x 610 x 955mm (x3) 670 x 535 x 55mm (x2) 670 x 535 x 130mm (x1) 670 x 535 x 205mm
APMS04 1550 x 610 x 955mm (x6) 670 x 535 x 55mm (x2) 670 x 535 x 130mm (x2) 670 x 535 x 205mm (x1) 1445 x 535 x 125mm
APMS01
APMS02
Pictured with top fitted, supplied separately.
APMS03
© Jack Sealey Limited
APMS04
Original Language Version
APMS01, APMS02, APMS03, APMS04 Issue 4 (H,2,3,F) 17/05/23
4. ASSEMBLY
4.1. 4.1.1. 4.1.2. 4.2. 4.2.1. 4.3. 4.3.1.
FIT WORKTOP The only assembly required is to fit the worktop supplied separately and the door handles (if applicable). Fit worktop by screwing from underneath using 4 x hex flange bolts (see fig.1) or 6 x hex flange bolts for 60″ wide models (see fig.2). FIT HANDLES Handles screw on from the rear, using cross head screws (see fig.2). REMOVE DRAWERS (if applicable) Pull drawer out fully and push black lever in each drawer runner up or down, then pull out drawer to release (see fig.1).
fig.1
fig.2
4.4. 4.5.
.
ENVIRONMENT PROTECTION Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids according to local regulations.
REGISTER YOUR PURCHASE HERE
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice. Important: No Liability is accepted for incorrect use of this product. Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500
www.sealey.co.uk
© Jack Sealey Limited
Original Language Version
APMS01, APMS02, APMS03, APMS04 Issue 4 (H,2,3,F) 17/05/23
