Bolt-Programmable Smart Robot Car STEAM Robot Kit
Product Information
The product is called CrowBot and it is an electronic robot that
can perform multiple functions such as ultrasonic obstacle
avoidance, line tracking, light chasing and music playing. It comes
with a tracking map, joystick for control, assembly instructions,
and various parts including an OLED screen, joystick board, top and
bottom acrylics and screws. The product is designed for educational
purposes and is suitable for STEAM education.
It requires two AAA batteries (not included) for operation. The
product contains small parts and is not recommended for children
under 3 years of age. Children should only use the product under
adult supervision.
For more information and help, customers can visit the website
https://www.elecrow.com/.
Product Usage Instructions
Step 1: Prepare the product by gathering all the parts
included in the package. This includes the OLED screen, joystick
board, top and bottom acrylics, screws, and screwdriver. Also,
prepare the two AAA batteries (not included).
Step 2: Install the OLED screen by tearing off the bottom
sticker and attaching it to the joystick board.
Step 3: Assemble the top and bottom acrylics using the
M3x8mm screws and M3x9mm copper columns. Use the screwdriver to
tighten the screws.
Step 4: Insert the joystick board into the assembled
acrylics and secure it using the M3x8mm screws and M3x9mm copper
columns.
Step 5: Install the two AAA batteries into the battery
compartment located on the bottom acrylic.
Step 6: Finish assembling the product by attaching the
button caps to the front and top acrylics. The product is now ready
to use.
Step 7: To operate the product, turn on the light using
the left button. The buzzer will sound to indicate that the product
is ready. Use the omnidirectional lever to move the robot forward
or backward and turn left or right. Press the A button to cancel a
program. The product can perform various functions such as
ultrasonic obstacle avoidance, line tracking, light chasing, and
music playing by pressing the corresponding buttons (B, C, D).
Tracking Map
Joystick for CrowBot
Assembly Instruction
3 Top Button Cap
ø13×8.2mm Button Cap x4
Explore Electronic World
4 Front Button Cap
For more product information and help, please visit the website. https://www.elecrow.com/
WARNING
CHOKING HAZARD Small parts. Not for kids under 3 years. Children to use only under adult supervision.
STEAM
EDUCATION
ø6x6mm Button Cap x2
1 Preparation
5 Bottom Acrylic
Joystick Board x1
Top Transparent Acrylic x1
Bottom Acrylic x1
OLED Screen x1
ø13×8.2mm Button Cap x4
M3x9mm Copper Column x4
AAA Battery x2 (not included)
M3x8mm Screw x8
ø6x6mm Button Cap x2
Screwdriver x1
Bottom Acrylic x1
M3x8mm Screw x4
M3x9mm Copper Column x4
2 OLED Screen
1x OLED Screen 1x Joystick Board
Tear the bottom sticker
6 Top Acrylic
M3x8mm Screw x4
Top Transparent Acrylic x1
7 Battery
AAA Battery x2 (not included)
8 Finish
Front
Back
Instructions for Factory Procedures
L Turn on the light
R Buzzer sounds
Omnidirectional lever Y Go ahead
y x
X
Go back
Turn left Turn right Press to cancel the program
A
B
Ultrasonic obstacle avoidance robot
Line tracking robot
C
Light chasing robot
D
Music playing robot
Notice: · Preset infrared remote controller functions.If you reload other programs, the above functions will be invalid. · If you need, visit the product link or contact customer service to ask for this factory setting program.
CrowBot
