Statesman Skms0720mpw/b 20l 700w Manual Solo Microwave Instruction Manual

• Supervise children when using the oven and provide them with
  adequate instructions on safe usage.
• Do not heat liquid or other food in sealed containers to
  prevent explosions.
• Only trained personnel should perform service or repair
  operations involving the removal of covers that protect against
  microwave energy exposure.
• Do not install the oven over a range cooktop or any
  heat-producing appliance to avoid damage and warranty
  invalidation.
• Accessible parts may become hot during use, so keep young
  children away.

It is hazardous for anyone other than a competent person to
carry out service or repair operations involving the removal of
covers that protect against microwave energy exposure. Certain
non-metallic utensils may not be safe for microwaving. To test a
utensil, follow these steps:

1. Fill a microwave-safe container with 1 cup of cold water
   (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If it is warm, do not use it for
   microwave cooking.
4. Do not exceed 1 minute cooking time during the test.

You can safely use the following materials in the microwave
oven:

• Browning dish
• Dinnerware
• Glass jars
• Glassware
• Oven cooking bags
• Paper plates and cups
• Paper towels
• Parchment paper
• Plastic
• Plastic wrap
• Thermometers
• Wax paper

Follow the manufacturer’s instructions when using these
materials. Ensure that the bottom of the browning dish is at least
3/16 inch (5mm) above the turntable to avoid breakage.

SKMS0720MPW/B 20L 700W MANUAL SOLO MICROWAVE
WHITE/BLACK
Instruction Manual
Please read these instructions carefully before use and retain for future reference. Before switching on your appliance ­ Always check for any damage that may have
been caused in transit.

CONTENTS
Important Safety Instructions ………………………………….. 3-9 Product Specification…………………………………………………. 9 Appliance Overview………………………………………………….. 10 Installation……………………………………………………………….. 11 Operating Instructions ……………………………………………… 12 Cleaning & Maintenance…………………………………………… 13 Trouble Shooting Guide ……………………………………………. 14 Mains Plug Fuse Replacement………………………………….. 15 Disposal Information………………………………………………… 15 Statesman Warranty/Guarantee Information……………… 16
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.
2

IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:
Read all instructions before using the appliance and keep for future reference. · Use this appliance only for its intended use as described
in the manual. Do not use corrosive chemicals or vapours in this appliance. This type of oven is specifically designed to heat, cook or dry food. It is not designed for industrial or laboratory use. · Do not operate the oven when empty. · Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
WARNING! Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.
To reduce the risk of fire in the oven cavity: · When heating food in plastic or paper container, keep an
eye on the oven due to the possibility of ignition. · Remove wire twist-ties from paper or plastic bags before
placing bag in oven. · If smoke is observed, switch off or unplug the appliance
and keep the door closed in order to stifle any flames. · Do not use the cavity for storage purposes. Do not leave
3

paper products, cooking utensils, or food in the cavity when not in use. · The microwave oven is intended for heating food and beverages. Drying of clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
WARNING! Liquid or other food must not be heated in sealed containers since they are liable to explode.
· Microwave heating of beverages can result in delayed eruptive boiling; therefore, care has to be taken when handling the container.
· Do not fry food in the oven. Hot oil can damage oven parts and utensils and even result in skin burns.
· Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode even after microwave heating has ended.
· Pierce foods with heavy skins such as potatoes, whole squashes, apples, and chestnuts before cooking.
· The contents of feeding bottles and baby jars should be stirred or shaken and the temperature should be checked before serving in order to avoid burns.
· Cooking utensils may become hot because of heat transferred from the heated food. Potholders may be needed to handle the utensil.
· Utensils should be checked to ensure that they are suitable for use in microwave oven.
WARNING! It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.
4

· This product is a Group 2 Class B ISM equipment. The definition of Group 2 which contains all ISM (Industrial, Scientific and Medical) equipment in which radio-frequency energy is intentionally generated and/or used in the form of electromagnetic radiation for the treatment of material, and spark erosion equipment. For Class B equipment is equipment suitable for use in domestic establishments and in establishments directly connected to a low voltage power supply network which supplies buildings used for domestic purpose.
· This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
· Children should be supervised to ensure that they do not play with the appliance.
· The microwave oven should only be used as freestanding.
WARNING! Do not install oven over a range cooktop or other heat-producing appliance. This could cause damage and would invalidate the warranty.
· The microwave oven must not be placed in a cabinet. · The door or the outer surface may get hot when the
appliance is operating.
WARNING! Accessible parts may become hot during use. Young children should be kept away.
· During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.
5

WARNING! If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.
· The appliance is not intended to be operated by means of an external timer or separate remote-control system.
· The microwave oven is for household use only and not for commercial use.
· Never remove the distance holder in the back or on the sides, as it ensures a minimum distance from the wall for air circulation.
· Please secure the turntable before you move the appliance to avoid damages.
WARNING! It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
· The microwave oven is intended for defrosting, cooking and steaming of food only.
· Use gloves if you remove any heated food.
WARNING! Steam will escape, when opening lids or wrapping foil.
· This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
6

· Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are aged from 8 years and above and supervised.
· If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
· Please ensure that the grounding electrode of the power socket is equipped with a reliable grounding line.
WARNING: Improper use of the grounding plug can result in a risk of electric shock.
UTENSILS
Caution: Personal Injury Hazard It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. See the instructions on “Materials you can use in microwave oven or to be avoided in microwave oven.” There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below.
Utensil Test: 1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil in question. 2. Cook on maximum power for 1 minute. 3. Carefully feel the utensil. If the empty utensil is warm, do
not use it for microwave cooking. 4. Do not exceed 1 minute cooking time.
7

Materials you can use in a microwave oven

Browning dish
Dinnerware Glass jars Glassware Oven cooking bags Paper plates and cups Paper towels Parchment paper Plastic
Plastic wrap Thermometers Wax paper

Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.
Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow steam to escape.
Use for short­term cooking/warming only. Do not leave oven unattended while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be labelled “Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food.
Microwave-safe only (meat and candy thermometers).
Use as a cover to prevent splattering and retain moisture.

8

Materials to be avoided in microwave oven

Aluminium tray Food carton with metal handle Metal or metal-trimmed utensils Metal twist ties Paper bags Plastic foam
Wood

May cause arcing. Transfer food into microwave-safe dish. May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy. Metal trim may cause arcing.
May cause arcing and could cause a fire in the oven. May cause a fire in the oven. Plastic foam may melt or contaminate the liquid inside when exposed to high temperature. Wood will dry out when used in the microwave oven and may split or crack.

PRODUCT SPECIFICATION
Model: Rated Voltage: Rated Input Power (Microwave): Rated Output Power (Microwave): Oven Capacity: Turntable Diameter: Product Dimensions: Net Weight:

SKMS0720MPW/B 220-240V~ 50Hz 1100W 700W 20 Litres 245mm H:243mm x W:446mm x D:340mm 9.4kg

9

APPLIANCE OVERVIEW

8

7

2

6

5
34
1
1. Door Safety Lock System 2. Oven Window 3. Shaft 4. Roller Ring 5. Door Release Button 6. Control Panel 7. Wave Guide
(Please do not remove the mica plate covering the wave guide) 8. Glass Tray

10

INSTALLATION
1. Make sure that all the packing materials are removed from the inside of the door.
WARNING! Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surface, broken or loose door hinges and latches and dents inside the cavity or on the door. If there is any damage, do not operate the oven and contact qualified service personnel.
2. This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food likely to be cooked in the oven.
3. Do not place the oven where heat, moisture, or high humidity are generated, or near combustible materials.
4. For correct operation, the oven must have sufficient airflow. Allow a minimum of 20cm space above the oven, 10cm at the back and 5cm on both sides. Do not cover or block any openings on the appliance. Do not remove feet.
5. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
6. Make sure that the power supply cord is undamaged and does not run under the oven or over any hot or sharp surfaces.
7. The socket must be readily accessible so that it can be easily unplugged in an emergency.
8. Do not use the oven outdoors. 9. Place the oven as far away from radios and TV as possible. Operation of
microwave oven may cause interference to your radio or TV reception. 10. This appliance must be grounded. This oven is equipped with a cord having
a grounding wire with a grounding plug. It must be plugged into a wall socket that is properly installed and grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current. It is recommended that a separate circuit serving only the oven be provided. Using a high voltage is dangerous and may result in fire or other accidents or damage.
WARNING! Improper use of the grounding plug can result in a risk of electric shock.
Please Note: If you have any questions about the grounding or electrical instructions, consult a qualified electrician or service person. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures.
11

OPERATING INSTRUCTIONS

1. To set cooking power turn the power dial to desired level.
2. To set the cooking time turn the timer dial to desired time per your food cooking guide. Please Note: To set a time for less than 2 minutes, turn the timer dial past the 2 minute setting and then turn back to the desired time.
3. The microwave oven will automatically start cooking once the timer has been turned.
4. After the cooking time is up, a beep will sound to indicate the microwave has stopped.
5. If the unit is not in use, always set time to “0”.

Function/Power LOW ( ) DEFROST ( ) M.LOW ( ) MED ( ) M.HIGH ( )
HIGH ( )

Microwave Output Application

20%

Soften ice cream

42%

Defrost

52%

Soup, stew or soften butter

73% 88% 100%

Stew, fish Rice, fish, chicken, ground meat Reheat, milk, boil water, vegetables, beverage

Please Note: When removing food from the oven, please ensure that the oven power is switched off by turning the timer dial to 0 (zero). Failure to do so, and operating the microwave oven without food in it, can result in overheating and damage to the appliance.

12

CLEANING & MAINTENANCE
1. Turn off the oven and unplug the power cord from the wall when cleaning.
2. Keep the inside of the oven clean. When food splatters or is spilled liquids adhere to the oven walls, wipe with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using spray or other harsh cleaners. They may stain, streak or dull the door surface.
3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the operating parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides. Clean the door seals and adjacent parts frequently with a damp cloth to remove any spills or spatters. Do not use abrasive cleaners.
5. A steam cleaner should not be used. 6. Do not allow the control panel to become wet. Clean with a soft,
damp cloth. When cleaning the control panel, leave oven door open to prevent oven from accidentally turning on. 7. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may occur when the microwave oven is operated under high humidity condition, and it is normal. 8. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm soapy water or put in a dishwasher. 9. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the bottom surface of the oven with mild detergent. The roller ring may be washed in mild, soapy water or in a dishwasher. When removing the roller ring, be sure to replace it in the correct position. 10. Remove odours from your oven by combining a cup of water with the juice and skin of one lemon in a microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth. 11. If the light bulb burns out, please contact customer service to have it replaced. 12. The oven should be cleaned regularly, and any food deposits should be removed. Failure to maintain the oven in a clean condition could lead to deterioration of surfaces that could adversely affect the life of the unit and could possibly result in a hazardous situation.
13

TROUBLE SHOOTING GUIDE
If you experience difficulties with the appliance, please check the suggestions below before contacting customer services on 01473 277 508:

Microwave oven interfering with TV reception
Dim oven light
Steam accumulating on door, hot air out of vents
Oven started accidentally with no food inside

Normal
Radio and TV reception may be interfered with when the microwave oven is operating. It is similar to the interference of small electrical appliances, like food mixers, vacuum cleaners and electric fans. It is normal
In low power microwave cooking, the oven light may become dim. It is normal
In cooking, steam may come out of food. Most will escape through the vents, but some may accumulate on cooler surfaces like the oven door. It is normal
It is forbidden to run the microwave without any food inside as it is very dangerous. Turn off immediately.

Problem

Possible Cause
Power cord not plugged in tightly

Possible Solution
Unplug, then plug in again after 10 seconds

Oven cannot be started
Oven does not heat

Fuse blown
Trouble with outlet Door not closed properly

Replace fuse or reset circuit breaker (the oven should not be repaired by anyone except qualified service personnel)
Test outlet with other electrical appliances
Close door properly

14

MAINS PLUG FUSE REPLACEMENT
Fuse Replacement (Class I) This appliance must be earthed. Remove the fuse cover with a small flat head screw driver. Take out the fuse and replace with a new fuse of the same Amp. Replace the fuse cover and push back into place.

Fuse Cover

DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in normal unsorted municipal waste. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance it must be separately collected. Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.

15

STATESMAN WARRANTY/GUARANTEE TERMS & CONDITIONS
THANK YOU FOR CHOOSING STATESMAN
As a valued customer we would like to offer you a FREE 2-year warranty to cover your product against any electrical or mechanical defects.
This means that in the unlikely event you develop a fault or problem with your product we will happily repair or replace the item free of charge.
To qualify for the guarantee, the product must be used for domestic household use only and in accordance with the instructions in the user manual. Any misuse of the product will result in the warranty being void.
The guarantee does not cover accidental damage, misuse, neglect, tampering or incorrect adjustment or installation.
The guarantee will be rendered invalid if the product is resold, has had its serial number or rating label removed (or has an invalid serial number or rating label), or if an unauthorised person has carried out any repairs or alterations.
The warranty does not cover accessories or consumable parts that require replacement under normal use. This includes shelving, dials, filters, belts and trays etc. In the unlikely event of a breakdown please refer to the Troubleshooting Guide in your user manual and check all plugs, fuses and the electricity supply.
If you still require assistance, please contact our Customer Service Department on 01473 277 508 or write to us at the following address:
Customer Service Department 38 Bluestem Road, Ransomes Industrial Estate, Ipswich, IP3 9RR
Please quote the Product Code and the PO number on the rating label and give details of the exact fault. We will then decide whether to replace the item.
IMPORTANT NOTE: Before we arrange the replacement, you will be required to return a copy of your proof of purchase. Please retain your original.
If an item is replaced within the agreed warranty period, the warranty for the replacement item will be calculated from the purchase date of the original.
In the event that the product is inspected, and no fault is found, or the product is not within the guarantee period you will be charged for the repair and any carriage costs.
