9621500 Spotting Scope
Product Information:
The product is a spotting scope that includes a tripod with a
quick release plate and a backpack. The spotting scope has an Art.
No. of 9621500 and comes with an eyepiece with TwistUp eyecups, a
zoom adjustment wheel, a focus wheel, an optical tube, a sun
shield, and a tripod adapter thread. It is designed for earth
observation and is rainwater protected. The spotting scope can be
mounted on any tripod with a correspondingly standardized counter
screw.
Product Usage Instructions:
- Remove the protective caps from the tube and eyepiece before
use. Be sure to replace the protective caps on the lenses each time
after using the spotting scope. - Ideally, the spotting scope should be mounted on the supplied
tripod with the quick release plate. Use the tripod connection
thread according to DIN standard (6) for this purpose. - When using the spotting scope for earth observation, look
through the heat waves that form over the Earth’s surface. If heat
waves are affecting your vision, try focusing out a bit to get a
smoother, better quality image. Use the early morning hours for
your observations, before the earth’s surface has heated up too
much. - To clean the spotting scope, avoid cleaning the lenses unless
absolutely necessary. If dust needs to be removed, use a camel hair
brush or an ear syringe to blow it away. Fingerprints and organic
materials on the front lens can be removed with a solution of 3
parts distilled water and 1 part isopropyl alcohol. Add 1 drop of
biodegradable dishwashing liquid per half liter of solution. Use
soft, white face wipes and make short, gentle movements. Change the
wipes frequently. Do not use perfumed cloths or cloths with lotions
as they could damage the optics. - The spotting scope is rainwater protected and can be used near
water. However, water on the lens will cause distortion of the
images. Wipe the water off the entire unit with a soft cloth when
you move away from the water again. - Dispose of the packaging materials by type. Contact your local
waste-disposal service or environmental authority for information
about the proper disposal. Observe the current legal regulations
when disposing of the device! Information on proper disposal can be
obtained from municipal waste disposal service providers or the
Environmental Agency.
WARNING: Never look directly at, or near to the
sun with this device. There is a RISK OF BLINDNESS!
Spolux 20-60×80
Art. No. 9621500
EN Instruction manual
Device overview
Delivery content
> Spotting scope > Tripod with quick release plate > Backpack
2
Spolux 20-60×80 · www.bresser.de
WARNING Never look directly at, or near to the sun with this device. There is a RISK OF BLINDNESS!
Parts Eyepiece with TwistUp eyecups
Zoom adjustment (zoom wheel) Fine adjustment (focus wheel) Optical Tube Sun shield Tripod adapter thread
Setting up the spotting scope
Ideally, the spotting scope should be mounted on the supplied tripod with the quick release plate. Your spotting scope has a tripod connection thread according to DIN standard (6) for this purpose. This allows the spotting scope to be mounted on any tripod with a correspondingly standardized counter screw.
IMPORTANT:
Remove the protective caps from the tube and eyepiece. Be sure to replace the protective caps on the lenses each time after using the spotting scope.
Operation
· Focus wheel: Look into the eyepiece (1) and turn the focus wheel (3) in either direction to focus on an object.
· Zoom: Rotate the zoom wheel (2) to zoom in or out of an object. Then use the focus wheel (3) to focus.
· Indoor use and outdoor use: Even if you should occasionally observe objects through an open or closed window, the best results are still achieved outside. Temperature differences between the indoor and outdoor air as well as the low quality of window glass can cause images through the spotting scope to become blurred.
· Sun shield: You can extend the sun shield (5) in poor visibility conditions caused by strong sunshine. To do this, enclose the ring at the spotting scope opening with your hand and turn it to the right while facing the observation objective. On some models, the sun shield can also be extended by simply sliding it.
www.bresser.de · Spolux 20-60×80
3
Earth Observation
When viewing terrestrial objects, look through the heat waves that form over the Earth’s surface. You may have seen these heat waves shimmering across the asphalt in the summer. Heat waves cause a loss of image quality.
If heat waves are affecting their vision, try focusing out a bit to get a smoother, better quality image. Use the early morning hours for your observations, before the earth’s surface has heated up too much.
Cleaning and maintenance
Your spotting scope is a precision optical instrument built to provide a lifetime of observing experience. (It will rarely, if ever, require repair or maintenance by the manufacturer.) Follow this guideline to keep your spotting scope in the best condition:
> Avoid cleaning the lenses of the spotting scope. A little dust on the surface of the corrective lens will not result in any loss of image quality.
> If absolutely necessary, dust should be removed from the front lens very carefully with a camel hair brush or blown away with an ear syringe (available at most pharmacies).
> Fingerprints and organic materials on the front lens can be removed with a solution of 3 parts distilled water and 1 part isopropyl alcohol. You can also add 1 drop of biodegradable dishwashing liquid per half liter of solution. Use soft, white face wipes and make short, gentle movements. Change the wipes frequently.
4
Spolux 20-60×80 · www.bresser.de
ATTENTION: Do not use perfumed cloths or cloths with lotions. These could damage the optics.
> Your spotting scope is rainwater protected: This means that it is suitable to be used by a sportsman, a sailor or an occasional user in an environment where the spotting scope may be exposed to water, e.g. rain, fog, spray, etc. It is designed to be resistant if accidentally exposed to water, but it is not suitable for diving or extensive use in water. If your spotting scope is intentionally submerged in water for a long period of time, you risk voiding your warranty.
Also note that although your spotting scope can be used near water, water on the lens will cause distortion of the images. Wipe the water off the entire unit with a soft cloth when you move away from the water again.
Notes
Expand your horizon
www.bresser.de · Spolux 20-60×80
5
Disposal
Dispose of the packaging materials by type. Contact your local waste-disposal service or environmental authority for information about the proper disposal. Observe the current legal regulations when disposing of the device! Information on proper disposal can be obtained from municipal waste disposal service providers or the Environmental Agency.
Warranty
The regular warranty period is 2 years and begins on the day of purchase. To benefit from an extended voluntary warranty period as stated on the gift box, registration on our website is required.
You can consult the full warranty terms as well as information on extending the warranty period and details of our services at www.bresser.de/warranty_terms.
6
Spolux 20-60×80 · www.bresser.de
Service
GB AT CH BE
For questions about the product and any complaints, please contact the Service Centre first, preferably by e-mail.
E-Mail: Phone:
[email protected] +49 28 72 80 74 210
Bresser GmbH Kundenservice Gutenbergstr. 2 46414 Rhede, Germany.
*Lokale Rufnummer in Deutschland (Die Höhe der Gebühren je Telefonat ist abhängig vom Tarif Ihres Telefonanbieters); Anrufe aus dem Ausland sind mit höheren Kosten verbunden.
GB IE
Please contact the service centre first for any questions regarding the product or claims, preferably by e-mail.
E-Mail:
[email protected] Telephone*:+44 1342 837 098
Bresser UK Ltd. Suite 3G, Eden House Enterprise Way Edenbridge, Kent TN8 6HF United Kingdom
*Number charged at local rates in the UK (the
amount you will be charged per phone call will
depend on the tariff of your phone provider); calls from abroad will involve higher costs.
FR BE
Si vous avez des questions concernant ce produit ou en cas de réclamations, veuillez prendre contact avec notre centre de services (de préférence via e-mail).
E-Mail:
Téléphone*: 00 800 6343 7000
BRESSER France SARL Pôle d’Activités de Nicopolis 314 Avenue des Chênes Verts 83170 Brignoles France
*Prix d’un appel local depuis la France ou Belgique
NL BE
Als u met betrekking tot het product vragen of eventuele klachten heeft kunt u contact opnemen met het service centrum (bij voorkeur per e-mail).
E-Mail: Telefoon*:
[email protected] +31 528 23 24 76
BRESSER Benelux
Smirnoffstraat 8 7903 AX Hoogeveen
The Netherlands
*Het telefoonnummer wordt in het Nederland tegen lokaal tarief in rekening gebracht. Het bedrag dat u per gesprek in rekening gebracht zal worden, is afhankelijk van het tarief van uw telefoon provider; gesprekken vanuit het buitenland zullen hogere kosten met zich meebrengen.
ES IT PT
Si desea formular alguna pregunta sobre el producto o alguna eventual reclamación, le rogamos que se ponga en contacto con el centro de servicio técnico (de preferencia por e-mail).
E-Mail: Teléfono*:
[email protected] +34 91 67972 69
BRESSER Iberia SLU c/Valdemorillo,1 Nave B P.I. Ventorro del Cano 28925 Alcorcón Madrid España
*Número local de España (el importe de cada llamada telefónica dependen de las tarifas de los distribuidores); Las llamadas des del extranjero están ligadas a costes suplementarios..
www.bresser.de · Spolux 20-60×80
7
Contact
Bresser GmbH Gutenbergstraße 2 46414 Rhede – Germany www.bresser.de
@BresserEurope
© 2021 Bresser GmbH, 46414 Rhede, Germany. No part of this manual may be reproduced, transmitted, transcribed or translated into any language in any form without the written permission of Bresser GmbH. Errors and technical changes excepted.
Manual_9621500_Spolux-20-60×80-Spotting-Scope_en_BRESSER_v012023a
