Mastech Ms2101 Ac And Dc Clamp Meter User Guide

MASTECH MS2101 AC and DC Clamp Meter

• MGL GROUP U.K. LIMITED
• 14 Weller St, London, SE1 1QU, UK
• Tel: +34 985-08-18-70
• Email: [email protected]

Special attention should be paid when using the test and measurement instrument because the improper usage may cause electric shock and damage the equipment.

• Use proper measurement category (CAT), voltage, and amperage rated probes, test leads, and adapters for the measurement.
• Do not use or store the device around explosive gas, vapor, or under high temperature and humidity.
• When handling the test probes and crocodile clips, keep your fingers behind the physical guard.
• Examine the measuring test leads (if present) before use. Any element of which the insulation is deteriorated (even partially), replace them with proper functional test leads.
• Connect the common test lead before the live test lead and remove the live test lead before the common test lead.
• Before measuring current, make sure the instrument fuses available and disconnect the power supply to the circuit test
• Remove the batteries if the device is not used for an extended period of time, or if stored in temperatures above 45 °C. If the batteries are not removed, battery leakage can damage the device.

Contents

Specifications
