USB 3.0 Hub
Operating Instructions
Package Contents
- USB 3.0 hub
- Power supply unit 5V 2,5A
- USB cable
- These operating instructions
Safety Notes
- The product is intended for private, non-commercial use only.
- Do not attempt to service or repair the product yourself. Leave any and all service work to qualified experts.
- Do not open the device or continue to operate it if it becomes damaged.
- Do not operate the product outside the power limits given in the specifications.
- Do not modify the product in any way. Doing so voids the warranty.
- Keep this product, like all electrical products, out of the reach of children!
Warning
Warning- Ensure that the total power consumption of all connected terminal devices does not exceed 2500 mA.
- Bus-powered operation (without power supply unit) USB 2.0 → max. 500 mA /USB 3.0→ max. 900 mA /USB Type-C→ 3000 mA
- Consult the operating instructions or the technical specifications of the connected devices and your computer.
- It is essential that you observe these specifications and the safety instructions regarding the power supply of your devices.
Startup and Operation
- Switch on your computer and boot the system.
- First, connect the enclosed power supply unit to a socket and then to the hub.
- Connect the product to a free USB port on your computer.
- You do not have to install drivers; the computer will automatically recognize the product.
- If necessary, follow the instructions for your operating system.
- In order to use your USB devices or storage devices, plug them into the product one after the other.
Warranty Disclaimer
Hama GmbH &CoKGassumes no liability and provides no warranty for damage resulting from improper installation/mounting, improper use of the product, or from failure to observe the operating instructions and/ or safety notes.
Service and Support
Please contact Hama Product Consulting if you have any questions about this product.
Hotline: +49 9091 502-115 (German/English)
Further support information can be found here:www.hama.com
Technical Data
| Compatibility | USB-A-port |
| System requirements | Windows 10 /8/7 Mac OS 10.8 ≥ |
| USB specification | USB 3.0 |
Specifications in accordance with Regulation (EU) 2019/1782
| Manufacturer’sname or trademark, commercial registration number, and address | Hama, HRA12159, Dresdner Str. 9, 86653 Monheim |
| Model identifier | K15V050250G |
| Input voltage | 100-240 V |
| Input AC frequency | 50/60 Hz |
| Output voltage /output current /output power | 5.0 VDC/ 2.5 A/ 12.5 W |
| Average active efficiency | 80.9 % |
| Efficiency at low load (10 %) | 79.8 % |
| No-load power consumption | 0.05 W |
Note
- Ifthereisinterference or the product no longer responds, unplug the product, wait a few seconds, and then plug it in again.
HamaGmbH&C oK G
86652Monheim/G Germany
www.hama.com
All listed brands are trademarks ft corresponding companies.
Errors and omissions excepted, and subject to technical changes.
Our general terms of delivery payment reapplied.
00054544/04.20
