485UF 485 High Efficiency Softeners
Product Information: Canature WaterGroup Softener
The Canature WaterGroup Softener is a water treatment system
designed for upflow and downflow installations. The system comes
with an automatic resin cleaner solution feeder (optional), which
helps to maintain the softener’s performance and prolongs its
lifespan. The system is not meant for treating water that is
microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system.
Feed Water Parameters
The maximum iron concentration should be 2.0 ppm ferrous (clear
water iron), and the maximum hydrogen sulfide should be 0.0 ppm.
The maximum manganese concentration should be 0.75 ppm ferrous
(clear water). The pH level should range between 6.5 to 8.5 with no
iron or manganese present, and between 6.5 to 7.5 with iron or
manganese present.
Troubleshooting Guide
The troubleshooting guide provides solutions to common problems
that users may encounter with the Canature WaterGroup Softener
system. These include untreated water delivery, excessive water in
the salt tank, failure to regenerate automatically, failure to use
salt, discolored water, and excessive pressure loss. Users are
advised to test their water before attempting any troubleshooting
and refer to the maintenance section for injector cleaning, salt
tank cleaning, and resin cleaning.
Product Usage Instructions
Before installation, apply IAPMO certified lubricant to all
seals to avoid pinched o-rings during installation.
To ensure optimal performance, users should adhere to the feed
water parameters mentioned in the user manual. The Canature
WaterGroup Softener is not intended for treating water that is
microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system.
If the system fails to regenerate automatically, users should
verify the programming and correct the hardness level and amount of
people in the home if necessary. Users should also check for low
salt levels and fill salt to above the water level in the salt
tank. If the injectors or injector screens are plugged, users
should clean and/or replace them according to the maintenance
instructions.
If necessary, users can clean the resin using an approved resin
cleaner obtained from an authorized dealer or local plumbing supply
store. For permanent maintenance, users can add an automatic resin
cleaner solution feeder to the system.
Service Manual
485UF/DF
Upflow & Downflow Softener Manual
/WDKZd
E^&E^/
^
1. Avoid pinched o-rings during installation by applying IAPMO certified lubricant to all seals (provided with install kit).
2. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system.
Canature WaterGroup Canada Inc.
855 Park St., Unit 1 Regina, SK, S4N 6M1 Toll Free: (877) 288-9888
Canature WaterGroup U.S.A. Inc.
6353 Commerce Drive Whitestown, IN, 4607
Toll Free: (877) 288-9888
Table of Contents
FEED WATER PARAMETERS
4
TROUBLE SHOOTING GUIDE
4
AUTOMATIC RESIN CLEANER SOLUTION FEEDER
INSTALLATION INSTRUCTIONS (OPTIONAL)
6
PROBLEM WATER INJECTOR KIT
7
REPLACEMENT/SERVICE
10
PARTS BREAKDOWN
15
LEVEL 2 PROGRAMMING (OPTIONAL SETTINGS)
22
MASTER PROGRAMMING
23
FEED WATER PARAMETERS
Maximum Iron** = 2.0 ppm ferrous (clear water iron) Maximum Hydrogen Sulfide = 0.0 ppm Maximum Manganese = 0.75 ppm ferrous (clear water) pH = 6.5 to 8.5 with no iron or manganese present pH = 6.5 to 7.5 with iron or manganese present **See System Maintenance Section – Resin Cleaner
TROUBLE SHOOTING GUIDE
Problem LEVEL 1 — SEE HOME OWNERS MANUAL Recommended for the home owner
Delivers untreated water
Excessive water in the salt tank Not regenerating automatically, not metering water flow Not using salt Not regenerating automatically – Alarms Unit regenerates but does not use salt Using too much salt or more salt than expected Alarms after regeneration
Discolored water
4Excessive pressure loss
Possible Solutions
** IMPORTANT ** before attempting any trouble shooting be sure to test the water or have the water tested. The tests should include the raw water, the hot treated water, and the cold treated water.
Bypass is closed bypassing raw water past the unit – Return bypass valve to the open position to service the home – See `Manual Water Bypass’
Bypass loop in the homes plumbing – Close outlet valve only on conditioner bypass, open nearest conditioned water line. If no water flow then there is not a bypass in the plumbing. If there is water flow then there is a hidden bypass in the plumbing (contact plumber).
No salt or low salt level – Fill salt to above the water level in the salt tank. Low salt will affect the conditioners capacity. – See `Maintenance’
Not programmed correctly for current application – Verify programming. Correct hardness level and amount of people in the home if necessary. – See `Start Up and Programming’
Refer to Maintenance, Cleaning the Injectors and Cleaning the Salt Tank
Check diagnostics for last regeneration – See How Your Conditioner Works Open nearest conditioned water outlet and check if gallons is counting down, if not metering Contact authorized service representative
Injectors or injector screen plugged. Clean and or replace injectors and screen – See `Maintenance’ Salt Bridged in salt tank – See `Maintenance’
Caused by a power outage or brown out during regeneration unplug power for 30 seconds then re-connect. If alarm continues – Contact your authorized service representative, if necessary.
Clean and or replace injectors – See `Maintenance’
Drain line flow control is plugged clean drain line flow control to ensure there are no kinks, or restrictions in the drain line.
Check programming is the unit set properly for salt efficiency, is the programming correct for hardness and people – See `Start Up and Programming’
Caused by a power outage or brown out during regeneration unplug power for 30 seconds then reconnect if alarm continues – Contact your authorized service representative, if necessary.
Corroded or damaged rear circuit replace circuit Contact your authorized service representative, if necessary.
Result of city / town supply being contaminated check with local authority to see if there has been water main activity in your area. If there has been, manually regenerate the unit a couple of times in a row to clear the color. If there hasn’t been, Contact your authorized service representative if necessary.
Iron Bleed through if there are small amounts of iron in your raw water supply eventually it will build up in the resin and could result in bleed through. review settings to compensate for iron in the water – See `Start Up and Programming’
– Contact your dealer or local plumbing supply store to obtain an approved resin cleaner. Use resin cleaner to clean the resin as directed. For permanent maintenance if required add in an automatic feeder – See Automatic Resin Cleaner Solution Feeder
Check unit specifications – peak or continuous service flow rates maybe exceeding capacity causing the unit to be restrictive due to size – See `Unit Specifications’ – Contact your dealer if necessary.
TROUBLE SHOOTING GUIDE
Problem LEVEL 2 recommended for qualified service technician only
Not drawing brine solution
No water in salt tank
Problem
** Not regenerating automatically Alarms ** Conditioner initiates regeneration but alarms after a few seconds Internal valve leak – Running to the drain constantly Not drawing brine no problem with injectors or drain
**Meter not counting down **
Leaking past distributor tube Alarms after regeneration or after manual regeneration
Excessive pressure loss
Possible Solutions
Injectors or injector screen plugged. Clean and or replace injectors and screen – See Replacement/ Service Section Drain line flow control plugged or drain line restricted – See Replacement/Service Section Safety float assembly seating prematurely clean or replace safety float and clean brine tank – See Parts Section Loose connections between control valve and safety float allowing unit to draw air – See Replacement/Service Section Loose connections between control valve and safety float allowing unit to draw air See Replacement/Service Section Refill time not set correctly for unit size; water not coming above the grid plate. Refill control button plugged causing no refill clean and or replace refill control button. Check size of BLFC noted on silver label of valve and be sure valve is programmed to correspond to the correct size used.
Possible Solutions
Jammed piston – replace piston and seal assembly – See Replacement/Service Section Defective or damaged circuit – replace circuit See Replacement/Service Section Loose or corroded connections between the 2 circuits reconnect securely or replace – See Replacement/Service Section Drive motor defective replace motor – See Replacement/Service Section Drive motor defective replace motor – See Replacement/Service Section Defective transformer replace transformer. Replace piston and seal assemblies – See Replacement/Service Section Replace piston and seal assemblies – See Replacement/Service Section Check diagnostics for last regeneration . Check that meter cable is plugged into the meter assembly – See Replacement/Service Section Check that meter cable is reading the meter by moving a fridge magnet (or similar magnet) across it rapidly for a few seconds you should be able to see the gallons change. Be sure there is no debris caught in the the turbine If the meter cable is good, and no debris caught then replace the meter assembly – See Replacement/Service Section Contact Technical services for additional trouble shooting information: 877-288-9888 Damaged or missing sensor magnet on brine gear replace as required, or send in for repair to nearest office. Corroded or damaged rear circuit replace as required. Check unit specifications – peak or continuous service flow rates may be exceeding capacity causing the unit to be restrictive due to size – See product specific information on warranty sheets suplied with the unit. Contact Customer Service for clarification if this is suspected 877-288-9888.
Upper distributor cone plugged with foreign material remove valve, remove upper distributor cone and clean then replace and put valve back on unit. Chlorine degradation of resin excessive amounts of chlorine or chloramine can damage softening resin and break it down causing excessive pressure loss replace media bed and add in chlorine removal system to protect softener.
5
AUTOMATIC RESIN CLEANER SOLUTION FEEDER INSTALLATION INSTRUCTIONS (OPTIONAL)
Resin Cleaner
An approved resin cleaner MUST be used on a regular basis if your water supply contains iron. The amount of resin cleaner and frequency of use is determined by the quantity of iron in your water (consult your local representative or follow the directions on the resin cleaner package).
Res-Up Feeders attach to your brine tank and automatically dispense the Res-Up cleaner into the brine solution where it cleans the resin during the regeneration cycle.
The feeder hooks onto the tube inside your brine tank and you just pour some chemical in it and your water conditioner should last significanly longer. A res-up feeder is essential if your raw water contains measurable amounts of iron.
Res-Up Feeder Bottle (Chemical sold Separately) The 12 cc feeder (Part # 33010) is for conditioners up to 64,000 grains (2 ft3 of
resin). The 30 cc feeder (Part # 33018) is for larger conditioners over 64,000 grains.
Pro-Res Care Chemicals Item #45147 Pro-ResCare – Gallon Item #45148 Pro-ResCare – Quart
Install Res-Up Feeder
Res-up feeder 5/8″ hole in brine well cap
1/4″ Holes
1. Install the grid and brine well inside 2. Measure 2 inches from the top of the 3. Mark the location of the holder and 4. IInstall the holder and the Res Care
the tank.
tank beside the oblong molding.
drill.
Solution
6
5. Take off the small hole cover on the Brine Well lid.
6. Take off the cover of the Res Care bottle . Insert the wick, making sure it touches the bottom of the bottle. Insert the other end of the tube completely into the hole in the brine well cap. Automatic feeding will start in a few hours.
PROBLEM WATER INJECTOR KIT
For use on upflow softeners only.
IMPORTANT!: If the water source this water softener is being applied on is not municipal water and contains up to 2.0 mg/l/ppm of ferrous (Clear Water) iron and/or up to .75 mg/l/ppm of manganese, the enclosed Problem Water Injector Kit needs to be installed into the control valve following these instructions. FAILURE TO DO THIS WILL RESULT IN UNSATISFACTORY OPERATION OF THIS EQUIPMENT AND VOID ANY IMPLIED PERFORMANCE WARRANTY.
85UF Valve Before June 2022
Upflow Injector Configuration
85UF Valve After June 2022
Upflow Injector Configuration
Plug
Injectors
Injectors
Size Ft3 75 100 150 200 250 300
Color #1 WHITE #1 WHITE #1 WHITE #2 BLUE #2 BLUE #3 YELLOW
IMPORTANT
The injector cage must be lined up and
inserted properly to avoid crushing when
the injector cap is re-installed. Markings on the cage and valve
body must line up.
Replace injectors with correct number and color corresponding to your equipment size. *NOTE: Remember to properly lubricate ALL O-Rings with the silicone lubricant supplied.
NOTICE
Do NOT over tighten injectors. Snug-tight only.
Failure to make these changes will result in unsatisfactory operation of this equipment and void any implied performance warranty.
