RCL4 4V USB Lithium Compact LED Light
Product Information
The 4V USB Lithium Compact LED Light (Model RCL4) is a
flashlight intended for general illumination. It is protected
against water splashed from all directions, with limited ingress
permitted. The flashlight has a high brightness level of 550 Lumens
and a low brightness level of 100 Lumens. It has a colour rendering
index (CRI) of 70 and a correlated colour temperature (CCT) of 5000
K. The product weighs 0.11 kg (excluding battery pack) and has a
voltage of 4V and wattage of 6.5W.
Product Usage Instructions
- Read the instructions carefully before assembling, operating,
and maintaining the product. - Do not submerge the product in water or other liquids.
- Use the flashlight only for its intended purpose of general
illumination. - Avoid using solvents when cleaning plastic parts.
- Do not let brake fluids, gasoline, petroleum-based products,
penetrating oils, etc., come in contact with plastic parts. - Charge the battery pack using the USB charging cable and USB
power adaptor provided. - Do not immerse the tool, battery pack, or charger in fluid or
allow fluid to flow inside them. Corrosive or conductive fluids can
cause a short circuit. - Transport the battery in accordance with local and national
provisions and regulations. Protect exposed connectors with
insulating, nonconductive caps or tape. - Use only original accessories and spare parts. All repairs
should be performed by an authorized service centre. - Do not stare at the light source.
ORIGINAL INSTRUCTIONS
4V USB Lithium Compact LED Light
RCL4
IMPORTANT!
It is essential that you read the instructions in this manual before assembling, operating, and maintaining the product. Subject to technical modifications.
Safety, performance, and dependability have been given top priority in the design of your flashlight.
INTENDED USE The flashlight is intended for general illumination. The product is protected against water splashed from all directions, limited ingress permitted. Do not submerge the product in water or other liquids. Do not use the product for any other purpose. Use of the product for operations different from intended could result in a hazardous situation.
FLASHLIGHT SAFETY WARNINGS The light source contained in this luminaire shall
only be replaced by the manufacturer or his service agent or a similar qualified person. Use only with recommended battery pack. Any attempt to use another battery pack will cause damage to the product and could possibly explode, cause a fire, or personal injury. Do not disassemble the product. If wrapped or in contact with fabrics, the lens can produce sufficient heat to melt some fabrics. To avoid serious personal injury, never allow the lens to come in contact with anything. Do not place the product or battery pack near fire or heat. This will reduce the risk of explosion and possible injury. Remove the battery pack or disconnect the mains power before starting any work on the product. Do not store the product in a damp or wet location, or in a location where the temperature may reach or exceed 40°C. For example, inside sheds, vehicles, or metal buildings in the summer. Do not direct the light beam at persons or animals and do not stare into the light beam yourself (not even from a distance). Staring into the light beam may result in serious injury or vision loss. Charge the product/battery indoors.
BATTERY SAFETY WARNINGS
To reduce the risk of fire, personal injury, and product damage due to a short circuit, never immerse your tool, battery pack or charger in fluid or allow a fluid to flow inside them. Corrosive or conductive fluids, such as seawater, certain industrial chemicals, and bleach or bleachcontaining products, etc., can cause a short circuit.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national provisions and regulations.
Follow all special requirements on packaging and labelling when transporting batteries by a third party. Ensure that no batteries can come in contact with other batteries or conductive materials while in transport by protecting exposed connectors with insulating, nonconductive caps or tape. Do not transport batteries that are cracked or leaking. Check with the forwarding company for further advice.
MAINTENANCE
Use only original accessories and spare parts. Should components need to be replaced which have not been described, please contact an authorised service centre. All repairs should be performed by an authorised service centre.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to various types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, carbon dust, etc.
Do not at any time let brake fluids, gasoline, petroleum-based products, penetrating oils, etc., come in contact with plastic parts. Chemicals can damage, weaken or destroy plastic which may result in serious personal injury.
SYMBOLS ON THE PRODUCT
V
Volts
Direct current
The rated maximum ambient temperature
Regulatory Compliance Mark (RCM). Product meets applicable regulatory requirements.
Please read the instructions carefully before starting the machine.
Class III protection
IP54 Ingress protection rating Do not stare at light source.
Do not dispose of waste batteries, waste electrical and electronic equipment as unsorted municipal waste. Waste batteries and waste electrical and electronic equipment must be collected separately. Waste batteries, waste accumulators, and light sources have to be removed from the equipment. Check with your local authority or retailer for recycling advice and collection point. According to local regulations, retailers may have an obligation to take back waste batteries and waste electrical and electronic equipment free of charge. Your contribution to the reuse and recycling of waste batteries and waste electrical and electronic equipment helps to reduce the demand of raw materials. Waste batteries, in particular containing lithium, and waste electrical and electronic equipment contain valuable and recyclable materials, which can adversely impact the environment and the human health if not disposed of in an environmentally compatible manner. Delete personal data from waste equipment, if any.
SYMBOLS IN THIS MANUAL
Safety Alert
Note
Parts or accessories sold separately
Charging time
PRODUCT SPECIFICATIONS
4V USB Lithium Compact LED Light Model Voltage Wattage Light output (Lumens)
High brightness level Low brightness level Colour rendering index (CRI) Correlated colour temperature (CCT) Weight – excluding battery pack
RCL4 4 V 6.5 W
550 Lum 100 Lum 70 5000 K 0.11 kg
BATTERY
Compatible battery pack
RB420
KNOW YOUR PRODUCT
Power button Battery cap
1
2 1
Belt clip LED lens
2
100%
Battery pack USB charging cable Operator’s manual USB power adaptor
18% 0%
4
3
Besides high and low modes, the light has a “strobe” mode. Press and hold the power button for 3 seconds to activate strobe mode. If any mode is constant for 5 seconds, pressing the power button will turn the product off.
1 3 4
2
5 6
Imported by: Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149 Melbourne, Australia
Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand
0-5 hrs
RYOBI is a trade mark of Ryobi Limited, and is used under license.
20221130v1
