Sloan Esd-410 Esd Series Foam Soap Dispensers Installation Guide

ESD-410 ESD Series Foam Soap Dispensers

ESD-Series Foam Soap Dispensers

The ESD-Series Foam Soap Dispensers come in eight different
models – ESD-410, ESD-2100, ESD-420, ESD-500, ESD-600, ESD-700,
ESD-800, ESD-1500, and ESD-2000. They are designed to dispense
green certified foam soap and operate on four D cell batteries.
They can also be powered by a 6 VDC plug-in adapter (100-240 VAC)
which is sold separately.

Repair Parts and Maintenance Guide

The following repair parts are available for the ESD-Series Foam
Soap Dispensers:

• ESD218: Alternate mounting flange
• ESD320: Soap dispensing motor (includes
  battery box #8)
• ESD321: Green certified foam soap refills 1500
  ml (2 per box)
• ESD324: 6 VDC plug-in adapter (100-240
  VAC)
• ESD340A: Straw asm for soap bottle

Item Description

The following items are included with the ESD-Series Foam Soap
Dispensers:

Spout List

The following replacement spouts are available for the
ESD-Series Foam Soap Dispensers:

1. ESD-1502A CP spout assembly-EAF100/150 style
2. ESD-2002A CP spout assembly-EAF200/250/275 style
3. ESD-2102A CP spout assembly-SF-2100/2150 style
4. ESD-502A CP spout assembly BASYS style
5. ESD-602A CP spout assembly ETF-600/650 style (610/615)
6. ESD702A CP spout assembly EAF-700/750 style
7. EAF802A CP spout assembly ETF80/EBF-85

Usage Instructions

1. Open the battery box and insert four D cell batteries
   (provided) or plug in the 6 VDC plug-in adapter (sold
   separately).
2. Remove the soap bottle from its packaging and remove the
   cap.
3. Insert the tube into the soap bottle and attach the spout
   assembly to the dispenser assembly.
4. Secure the dispenser assembly to the wall using the screws and
   anchors provided.
5. Press the button on the front of the dispenser to dispense
   soap.

Note: When refilling the soap bottle, be sure to use green
certified foam soap refills that are compatible with the ESD-Series
Foam Soap Dispensers.

Repair Parts and Maintenance Guide
ESD-Series Foam Soap Dispensers

ESD-410 ESD-2100

ESD-420

ESD-500

ESD-600

ESD-700

ESD-800

ESD-1500

ESD-2000

ITEM DESCRIPTION

QTY.

1.

DISPENSER ASSEMBLY

1

(SEE SPOUT LIST BELOW)

2.

FLAT WASHER

1

3.

NUT

1

4.

MOTOR ASSEMBLY (BOTTLE SUPPORT)

1

5.

BATTERY BOX

1

(USES 4 “D” CELL BATTERIES)

6.

SOAP BOTTLE (2 BOTTLES SHIP WITH

1 BOX

DISPENSER/ADDITIONAL SOLD SEPARATELY) (2 BOTTLES)

7.

SCREWS & ANCHORS FOR BATTERY BOX 1

MOUNTING

8.

RETAINING CLIP

1

9.

“D” CELL BATTERIES (PROVIDED)

1

10.

SOAP BOTTLE TUBE

1

NOT ESD-324 6 VDC PLUG-IN ADAPTER SHOWN (100-240 VAC) (SOLD SEPARATELY)

REPAIR PARTS (IN KIT FORM- TAKEN FROM ITEM NUMBERS ABOVE)

ITEM REPAIR PARTS DESCRIPTION AVAILABLE TO ORDER

MATERIAL NUMBER

ESD218

*ALTERNATE MOUNTING FLANGE *0346002 NUT

ESD320

SOAP DISPENSING MOTOR (INCLUDES BATTERY BOX #8)

0346081

ESD321

GREEN CERTIFIED FOAM SOAP 3346044 REFILLS 1500 ML (2 PER BOX)

ESD324

6 VDC PLUG-IN ADAPTER (100-240 VAC)

0346090)

ESD340A

STRAW ASM FOR SOAP BOTTLE 0346102

REPLACEMENT SPOUTS ONLY (INCLUDES NUT & WASHER)

ITEM DESCRIPTION

QTY.

1. ESD-1502A CP SPOUT ASSEMBLY-EAF100/150 STYLE

1

1. ESD-2002A CP SPOUT ASSEMBLY-EAF200/250/275 STYLE

1

1. ESD-2102A CP SPOUT ASSEMBLY-SF-2100/2150 STYLE

1

1. ESD-502A CP SPOUT ASSEMBLY BASYS STYLE

1

1. ESD-602A CP SPOUT ASSEMBLY ETF-600/650 STYLE (610/615)

1

1. ESD702A CP SPOUT ASSEMBLY EAF-700/750 STYLE

1

1. EAF802A CP SPOUT ASSEMBLY ETF80/EBF-85

1

The information contained in this document is subject to change without notice.
