P-ORGH-MN Orion Mini Camera Geared Head
Product Information: Orion Mini Camera Geared Head
(P-ORGH-MN)
The Orion Mini Camera Geared Head is a compact and sturdy camera
accessory that is designed to work with most DSLR video cameras
with a payload of up to 15kg/33lb. It comes with a 100mm bowl base,
an Allen Key T-Type (Size:-4mm), three washers and screws, three
crank handles, and a bag packing for easy transportation. The
geared head has a sturdy tilting crank and panning tilting crank
for smooth and precise camera movements.
Product Usage Instructions: Orion Mini Geared Head Setup
- Step 1: Inspect the contents of your shipped package to ensure
you have received everything that is listed in the “What’s In The
Box” section of the manual. - Step 2: Attach the 100mm bowl base to your tripod or other
support system using the provided Allen Key T-Type
(Size:-4mm). - Step 3: Place the Orion Mini Geared Head on top of the bowl
base and secure it in place using the provided washers and
screws. - Step 4: Attach your DSLR video camera to the geared head using
a compatible camera mounting plate or screw. - Step 5: Use the sturdy tilting crank and panning tilting crank
to adjust the position of your camera for smooth and precise
movements.
Note: Optional accessories can be added to the Orion Mini Geared
Head for additional functionality or customization. Please refer to
the product manual for more information on compatible accessories
and their usage instructions.
1
Orion Mini Camera Geared Head (P-ORGH-MN)
Assembly Manual
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
100mm Bowl Base Allen Key T-Type (Size:-4mm)
Proaim Orion Mini Geared Head
3 x Washers & Screws
3 x Cranks Handles
Bag Packing
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
2
Orion Mini Geared Head Setup
· Detach half bowl from 100mm bowl base.
· Now attach half bowl to the bottom of Orion mini and secure it with the help of Rench (Not-Included).
· Here is the final view of bowl attaching.
· Loose screw and washer from the side ends of Orion mini with the help of provided Allen key.
· Now attach crank handle after removing screw & washer.
· Secure it by attaching screw and washer with the help of provided Allen key.
3
· Similarly attach other two handles.
· Insert the thread of the Orion Mini Geared Head into the 100mm bowl tripod stand (Not-Included).
· Secure the thread from the bottom with the tightening knob.
· Loosen the ratchet knob on the top plate of the Geared Head and press the push button on the other side.
· Slide out the top plate.
· Attach the plate to the camera base (Not-Included) and tighten its bolt with a screwdriver (Not-Included). Then, slide the plate on the top of the Geared Head.
NOTE: Orion Mini Gear Head works with most of the DSLR Video Cameras with payload up to 15kg/33lb.
· Tighten the ratchet knob on the plate to secure the camera setup.
NOTE: The Geared Head has sturdy cranks for Panning & Tilting. The tilting crank offers one-axis movement and allows 45° tilting on each side. The panning crank offers 360° panning for accurate panoramic shots.
Sturdy Tilting Crank
· There’s a Backlash Control Knob present on the geared head. Tightening the knob will make the panning crank handles tight, and the handles will move smoothly when the knob is loosened.
· Orion Mini Geared Head Setup is ready to use.
4
Panning Tilting Crank
5
YOUR PROAIM ORION MINI CAMERA GEARED HEAD ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspection and evaluation by us. Liability: We are not liable for damage caused by products that we do not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company. Contact Us: In case of any kind of dissatisfaction, please Contact us immediately and we promise our utmost support and care until you use our product.
