Sony Str-dn1080 7.2ch Home Theatre Av Receiver Owner's Manual

STR-DN1080 7.2ch Home Theatre AV Receiver

Product Information

Product Usage Instructions

To ensure the optimal usage and performance of the
STR-DN1080/ZA810ES, please follow these instructions:

1. Keep your PC used for service and checking of this unit always
   updated with the latest version of your anti-virus software to
   prevent any virus affecting the unit during service.
2. In case you find a virus affected unit during service, contact
   your Service Headquarters for further assistance.
3. Connect the appropriate speakers to the front, center,
   surround, and surround back speaker terminals of the receiver.
4. Make sure the power requirements match your region: USA,
   Canada, Taiwan – 120 V AC, 60 Hz | Oceania, Europe – 230 V AC, 50
   Hz.
5. Adjust the analog input sensitivity and digital input impedance
   settings based on your audio source’s specifications.
6. Connect your video devices to the designated video
   inputs/outputs using standard RCA cables.
7. Set the HDMI video resolution according to your display
   device’s capabilities and preferences.
8. Ensure Bluetooth compatibility with your iPhone, iPad, iPod
   touch, and other devices as specified in the manual. Use the
   SongPal app for enhanced control and functionality.
9. When using the USB port, connect a USB flash drive for media
   playback. Note that iPhone/iPad/iPod playback via USB is not
   supported.
10. For network connectivity, use the Ethernet LAN or wireless LAN
    (IEEE 802.11 a/b/g/n) based on your network configuration. Ensure
    proper security settings (WPA/WPA2-PSK, WEP) and select the
    appropriate radio frequency (2.4 GHz, 5 GHz).
11. Pair your Bluetooth-enabled devices with the receiver using
    Bluetooth Specification version 4.1. Ensure line-of-sight
    communication within approximately 30 meters (98.4 feet) for
    optimal signal strength.

STR-DN1080/ZA810ES

SERVICE MANUAL
Ver. 1.3 2020.11

Note: Be sure to keep your PC used for service and checking of this unit always updated with the latest version of your anti-virus software. In case a virus affected unit was found during service, contact your Service Headquarters.

Photo: STR-DN1080

US Model Canadian Model
STR-DN1080/ZA810ES
AEP Model UK Model
Australian Model Taiwan Model
STR-DN1080

(STR-DN1080)

AUDIO POWER SPECIFICATIONS

POWER OUTPUT AND TOTAL HARMONIC DISTORTION: (USA models only)
With 6 ohm loads, both channels driven, from 20 Hz ­ 20,000 Hz; rated 100 watts per channel minimum RMS power, with no more than 0.09% total harmonic distortion from 250 milliwatts to rated output.

Amplifier section1)
Minimum RMS Output Power (6 ohms, 20 Hz ­ 20 kHz, THD 0.09%)
100 W + 100 W
Stereo Mode Output Power (6 ohms, 1 kHz, THD 0.9%)
120 W + 120 W Surround Mode Output Power 2) (6 ohms, 1 kHz, THD 0.9%)
165 W per channel

1) Measured under the following conditions:

Area

Power requirements

USA, Canada, Taiwan

120 V AC, 60 Hz

Oceania, Europe

230 V AC, 50 Hz

2) Reference power output for front, center, surround and surround back speakers. Depending on the sound field settings and the source, there may be no sound output.

Frequency response Analog 10 Hz ­ 100 kHz, +0.5/­2 dB (with sound field and equalizer bypassed)
Input Analog Sensitivity: 500 mV/50 kilohms S/N 3): 105 dB (A, 500 mV 4)) Digital (Coaxial) Impedance: 75 ohms S/N: 100 dB (A, 20 kHz LPF) Digital (Optical) S/N: 100 dB (A, 20 kHz LPF)
Output (Analog) ZONE 2 Voltage: 2 V/1 kilohm SUBWOOFER Voltage: 2 V/1 kilohm
Equalizer Gain levels ±10 dB, 1 dB step
3) INPUT SHORT (with sound field and equalizer bypassed).
4) Weighted network, input level.

SPECIFICATIONS

FM tuner section Tuning range
USA and Canadian models: 87.5 MHz ­ 108.0 MHz (100 kHz step) Other models: 87.5 MHz ­ 108.0 MHz (50 kHz step) Antenna (aerial) FM wire antenna (aerial) Antenna (aerial) terminals 75 ohms, unbalanced
Video section Inputs/Outputs
Video: 1 Vp-p, 75 ohms
HDMI Video Resolution
480p/60 Hz 576p/50 Hz 720p/60 Hz, 50 Hz, 30 Hz, 24 Hz 1080i/60 Hz, 50 Hz 1080p/60 Hz, 50 Hz, 30 Hz, 25 Hz, 24 Hz 4K/60 Hz*, 50 Hz*, 30 Hz, 25 Hz, 24 Hz
* VIDEO 1 supports YCbCr 4:2:0 8 bit only Support
HDCP2.2, HDR (HDR10, Hybrid Log-Gamma, Dolby Vision), 3D, Deep Color, ITU-R BT.2020, eARC/ARC
iPhone/iPad/iPod section BLUETOOTH technology works with iPhone 7, iPhone 7 Plus, iPhone SE, iPhone 6s, iPhone 6s Plus, iPhone 6, iPhone 6 Plus, iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, and iPod touch (5th and 6th generation.)
AirPlay works with iPhone, iPad, and iPod touch with iOS 4.3.3 or later, Mac with OS X Mountain Lion or later, and PC with iTunes 10.2.2 or later.
You can use “SongPal” app with this receiver via BLUETOOTH or network connection.
iPhone/iPad/iPod playback via (USB) port is not possible.
USB section (USB) port: Type A (For connecting USB flash drive)
Maximum current 1 A
Network section Ethernet LAN
100BASE-TX Wireless LAN
Compatible standards: IEEE 802.11 a/b/g/n
Security: WPA/WPA2-PSK, WEP
Radio frequency: 2.4 GHz, 5 GHz

BLUETOOTH section
Communication system BLUETOOTH Specification version 4.1
Output BLUETOOTH Specification Power Class 1
Maximum communication range Line of sight approx. 30 m (98.4 feet)1)
Frequency band 2.4 GHz band (2.4000 GHz ­ 2.4835 GHz)
Modulation method FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles 2) A2DP 1.2 (Advanced Audio Distribution Profile) AVRCP 1.5 (Audio Video Remote Control Profile)
Supported Codecs 3) SBC 4), AAC, LDAC
Transmission range (A2DP) 20 Hz ­ 40,000 Hz (LDAC sampling frequency 96 kHz with 990 kbps transmission) 20 Hz ­ 20,000 Hz (Sampling frequency 44.1 kHz)
1) The actual range will vary depending on factors such as obstacles between devices, magnetic fields around a microwave oven, static electricity, cordless phone, reception sensitivity, antenna’s performance, operating system, software application, etc.
2) BLUETOOTH standard profiles indicate the purpose of BLUETOOTH communication between devices.
3) Codec: Audio signal compression and conversion format
4) Subband Codec

General Power requirements

Area

Power requirements

USA, Canada, Taiwan Oceania Europe

120 V AC, 60 Hz 230 V AC, 50 Hz 230 V AC, 50/60 Hz

Operating frequency and maximum output power (for European models)
Wireless LAN/BLUETOOTH

Operating frequency

Maximum output power

2400 – 2483.5 MHz 20.0 dBm

Wireless LAN
Operating frequency 5150 – 5250 MHz 5250 – 5350 MHz 5470 – 5725 MHz 5725 – 5850 MHz

Maximum output power 23.0 dBm 20.0 dBm 20.0 dBm 14.0 dBm

NFC
Operating frequency 13.56 MHz

Maximum output power
< 60 dBA/m at 10 m

Power consumption 240 W European models Standby mode: 0.4 W (When [Control for HDMI], [Standby Through], [Bluetooth Standby], and all zone power are set to [Off].) Bluetooth Standby mode: 1.5 W (When [Bluetooth Standby] is set to [On], and [Control for HDMI], [Standby Through], and all zone power are set to [Off].) Networked standby (all wired network ports are connected, all wireless network ports are activated): 1.5 W Other models Standby mode: 0.4 W (When [Control for HDMI], [Standby Through], [Remote Start], [Bluetooth Standby], [Network Standby], and all zone power are set to [Off].) Bluetooth Standby mode: 2.5 W (When [Bluetooth Standby] is set to [On], and [Control for HDMI], [Standby Through], [Remote Start], [Network Standby], and all zone power are set to [Off].)
Dimensions (width/height/depth) (Approx.) 430 mm × 156 mm × 331 mm (17 in × 6 1/4 in × 13 1/8 in) including projecting parts and controls
Mass (Approx.) 9.1 kg (20 lb 1 oz) (USA, Canadian and Taiwan models) 9.7 kg (21 lb 6 oz) (European and Oceanian models)
Supplied Accessories
Remote control (1) R03 (size AAA) batteries (2) FM wire antenna (aerial) (1) Calibration microphone (1)
Design and specifications are subject to change without notice.

­ Continued on next page ­

MULTI CHANNEL AV RECEIVER

9-896-382-04 2020K33-1 © 2020.11

Sony Home Entertainment & Sound Products Inc.

SECTION 7 EXPLODED VIEWS

STR-DN1080/ZA810ES
Ver. 1.3

Note: · -XX and -X mean standardized parts, so
they may have some difference from the original one. · Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.

· The mechanical parts with no reference

number in the exploded views are not sup-

plied.

· Color Indication of Appearance Parts Ex-

ample:

KNOB, BALANCE (WHITE) . . . (RED)

Parts Color Cabinet’s Color

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.
Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié.

7-1. CASE, ANTENNA SECTION

#1 #1

#1

#1 #1 #1 #1

The components identified by mark 9 contain confidential information. Strictly follow the instructions whenever the components are repaired and/or replaced.
Les composants identifiés par la marque 9 contiennent des informations confidentielles. Suivre scrupuleusement les instructions chaque fois qu’un composant est remplacé et / ou réparé.

­ Rear view ­ #1
6
2
A
2

#1

B

not supplied

#1

C

D

WIFI1

3

E

not supplied

not supplied

not supplied not supplied

(DN1080: AEP,

#1

UK, AUS, TW)

ANT2

5

not supplied ANT3

D

#1 B

#1

E

C

not

5

supplied

(DN1080: AEP,

UK, AUS, TW)

#1

Note 1: When the WLAN/BT combo card (Ref. No. WIFI1) is replaced, refer to “NOTE OF REPLACING THE MB-1613 BOARD OR WLAN/BT COMBO CARD” on page 7.

Note 2: Refer to “Pasting position of the HI-RES label” on page 96 for

1

more about the pasting position of HI-RES LABEL (Ref. No. 1).

MB-1613 board section A

83

STR-DN1080/ZA810ES
Ver. 1.1

7-2. MB-1613 BOARD SECTION
#1

not supplied

52 #1

(DN1080: AEP, UK, AUS, TW) (See Note 3)
not supplied

#1 N M

#1

#1

#1

#1

53

not supplied

#11

not supplied

(ZA810ES) FFC5
52
T

F #1 I

H

L

G K

J

#1
51

not supplied

(ZA810ES)

supplied with CN202

#1

#1

#1

#2

­ Rear view ­

Note 2: The Ref. No. #11 screw has been changed during production for the AEP, UK, AUS models. Check the shape of this screw before replacing it.

Former type

New type

M N

#11 #1

T

not supplied

CN202

(RS232C board)

(ZA810ES)

#1 #2#2 #2 #2 #2 #2 #2

supplied with CN202 #2

F LK

#1 I HJ

not supplied

G

power supply section

Note 1: When the complete MB-1613 board (Ref. No. 51) is replaced, refer to “NOTE OF REPLACING THE MB-1613 BOARD OR WLAN/BT COMBO CARD” on page 7.

Note 3: These parts have been added during production for the AEP, UK, AUS models of the DN1080. These parts have been attached from the first production lot for the TW model of the DN1080.

84

STR-DN1080/ZA810ES
Ver. 1.3

7-3. POWER SUPPLY SECTION (STR-DN1080)
Note 1: Refer to page 86 for the STR-ZA810ES.

not supplied
102
T901
102

not supplied

#10

102 #1 #1

(US, CND) #1

FC2

O
102

#1 #1
P

105

#1 #1

not supplied

102

Q not supplied
FC1

101
(AEP, UK, AUS) not supplied
F901

101
R

#1
S
101
#1

#1

#11

#1

not supplied #1
#1
OS
103

104

AC1

#1 #1 #1

105 105

­ Rear view ­ (US, CND)

not

101

supplied

not supplied

(STANDBY

board)

R

not supplied
Q

#1 #1
not supplied

#1 #1
#11 #1 102
#10
#1 #1
#1 #1

#1

P

not supplied

not supplied

not supplied not supplied (GND BRACKET board)

not supplied (COAX board)

MAIN board section

Note 2: The Ref. No. #11 screw has been changed during production for the AEP, UK, AUS models. Check the shape of this screw before replacing it.

Former type

New type

85

STR-DN1080/ZA810ES
Ver. 1.3
7-4. POWER SUPPLY SECTION (STR-ZA810ES)
Note: Refer to page 85 for the STR-DN1080.

not supplied

not

152 #1 #1

supplied

#1

#1

#1

152

FC2

T901

O

#1

#1

154 154

152

#1

not supplied

152

P

152

Q not supplied

FC1
151

151 R
F901

S

#1

151

­ Rear view ­

not supplied #1

OS

#1
153

151
not supplied (STANDBY board)

not supplied

R

#1
not supplied Q

not supplied

#1

#1
#1 #1

154
AC2
154
#1
#1 #1 #1 #1 #1 #1 #1
#1 #1 152
#1 #1
#1 #1 #1
#1

P

not supplied

not supplied

not supplied

not supplied (GND BRACKET board)
not supplied (COAX board)

MAIN board section

86

7-5. MAIN BOARD SECTION

STR-DN1080/ZA810ES
Ver. 1.1

not supplied (INSULATION board)
#1 not supplied not supplied not supplied

#1 #1
#1 Y

not supplied (SUPPORT board) #1
heat sink section
#1 #1

V

FFC1

FFC2 not supplied

#1

not supplied

X

(USB INSULATION board)

W

Note: The Ref. No. #11 screw has been changed during production for the AEP, UK, AUS models. Check the shape of this screw before replacing it.

Former type

New type

(DN1080: AEP, UK, AUS, TW) not supplied
not supplied
not supplied not supplied

front side

(DN1080: AEP, UK, AUS, TW)
not supplied
(DN1080: US, CND/ ZA810ES)
not supplied

#1
Y #1
V

202

not supplied

#1 #1
#1 203
X

#11
#1 #1
W front panel section #1

201
rear side

201

203
#1 not supplied (DN1080: AEP, UK, AUS, TW)
not supplied (DN1080: US, CND/ZA810ES)

87

STR-DN1080/ZA810ES
Ver. 1.1
7-6. FRONT PANEL SECTION

253 252
supplied with EN1101

not supplied FFC6

254
supplied with EN1100 front side

not supplied (DISPLAY board) (See Note)
251

FFC4

not supplied (NFC-ICON board)
251 (See Note)

EN1101
251 251
EN1100

251 251

rear side

not

supplied

Z

not

supplied

251

NFC1 Z FFC3
WR1

251

251

251

not supplied (BTW board) (See Note)

251 251
251

251

251

not

not supplied

supplied

(POWERKEY board)

not supplied

251

not supplied (HP SUPPORT board)

not supplied (HP board)

251
251 251

not supplied (FRONTJACK board)

Note: When the DISPLAY board, NFC-ICON board or BTW board is repaired or the NFC module (Ref. No. NFC1) is replaced, refer to “NFC CONNECTION CHECKING METHOD” on page 9.

88

7-7. HEAT SINK SECTION

STR-DN1080/ZA810ES
Ver. 1.1

not supplied
#1 #1

not supplied #1

Mica sheet is included in each transistor.

not supplied #1

Q1850 Q1800
Q1851
301
Q1801 Q1650 Q1651

Q1750

Q1600

Q1751

Q1700

rear side

Q1601

Q1550

Q1701

Q1551

front side not supplied
#1 not supplied

not supplied

89

STR-DN1080/ZA810ES
Ver. 1.3

501
Remote control (RMT-AA320U) (1)

502
Calibration microphone (1)

503
FM wire antenna (aerial) (1)

=$(6
504
AC power cord (mains lead) (1)

505
HI-RES label (1)

3DVWLQJSRVLWLRQRIWKH+,5(6ODEHO 5 ± 1 mm
8 ± 1 mm

OK 2 degrees or less.

NG More than 2 degrees.

96
