SL-232A Neck and Back Massager
Product Information:
The SNAILAX Neck and Back Massager (model SL-232A) is an
electric massage device designed to provide a soothing and relaxing
massage experience. It offers various features and functions to
customize the massage according to individual preferences. The
massager is equipped with Shiatsu neck massage, rolling massage
with adjustable width control, a customized area back massage, and
an optional heat function for both neck and back massages. It also
includes seat vibration massage and compression on the back and
seat. The product is made with PU leather and breathable mesh for
comfort.
The massager comes with a removable and washable cover/flap for
easy maintenance. It has the following technical
specifications:
- Measurements: 30 x 18 inches (Back), 22 x 15 inches (Seat)
- Weight: 18 lbs
- Voltage: Input – AC 100-240V ~50/60Hz, Output – 12VDC 5.0A
- Rated Power: 60W
- Default Automatic Runtime: 15 minutes
Product Usage Instructions:
- Attach the massager to a chair using elastic straps or place it
on another support surface. - Connect the adapter cable to the corresponding cable on the
cushion. - Plug the home adapter into an electric outlet.
- Turn on the device using the controller (refer to instructions
on page 5). - After use, place the controller in the pouch at the side of the
cushion. - The intensity of the back massage can be adjusted by attaching
or detaching the intensity control flap. - The intensity of the neck massage can be adjusted by attaching
or detaching the neck cover. - If the Shiatsu massage feels too strong, install the neck cover
or back flap onto the cushion for a softer massage. Alternatively,
place a blanket or towel between yourself and the massager to
reduce the intensity further. - If the Shiatsu nodes cannot reach your desired areas (neck,
shoulder, lower back), adjust the height of your back by using a
seat cushion or pillow on the seating part. - It is recommended not to exceed a continuous massage of 15
minutes per session and not to exceed three sessions in a day.
Controller Instructions:
1. NECK massage height adjustment: Long press the respective
buttons to manually adjust the height of the neck massage.
2. NECK massage Direction: Press once to turn on neck massage,
press again to change the rotation direction. In auto program mode,
pressing once will turn on neck Shiatsu with automatic rotation
direction change every 1 minute. Press again to turn off neck
massage.
3. AUTO: Press to activate all functions, press again to turn
off.
4. Upper/Lower: Select Upper or Lower back to designate the area
covered by the Shiatsu massage.
5. Shiatsu Button: Press to turn on/off a full back Shiatsu
massage.
Use & care manual
NECK AND BACK MASSAGER
SL-232A
Safety Instrucons
Please read the following instrucons carefully before pung your massage device into use to ensure trouble-free operaon and opmum efficiency. Please retain these operang instrucons for further use!
· The massage device conforms to recognized technical principles and the latest safety regulaons.
· Do not wet,do not use pins, never remove cover. · This items is NOT A TOY. Close supervision is necessary when this appliance is used by , on,
or near children or disabled persons. · This appliance should never be le unaended when plugged in. · Never use any power sources other than the home adapter provided as original equipment
with this unit. · Any possible repairs may only be carried out by authorized expert staff. Improper use and
unauthorized repairs are not permied for safety reasons and lead to loss of warranty. · Never touch the power plug with wet hands. · Please avoid contact of the device with water, high temperatures and direct sunlight. · Do not use any damaged cables, plugs or loose sockets. · Never operate under blankets where the air openingmay be blocked. · If plugs or cords are damaged, they must be replaced by the manufacturer, a service
representave or by qualified personnel. · In case of malfuncon, disconnect immediately from the mains. · Do not use if you have skin disorders, open wounds,or swollen or inflamed areas. · Misuse or incorrect use excludes any liability for damage. · Do not use this device while driving. · Do not use while you sleep. · Do not use with infants,a helpless person or a person insensive to heat. · Overlong applicaon can result in skin burns. · Do not use this product for medical treatment. · In order to avoid excessively smulang the muscles and nerves, the recommended
massage me should not be exceeded 15 minutes at a me. · We equip the massager with a protecon against over-heang for safe use. · Each massage even a hand massage must be refrained from during pregnancy or if
one or more of the following complaints are present in the massage area: recent injuries, thromboc diseases, all kinds of in flammaons and swellings, and cancer. It is recommended to consult a doctor before having a massage for the treatment of ailments and illnesses. · If you are dependent on electrical aids e.g. pacemakers, please be sure to consult your doctor for medical advice before taking a massage. · The packaging material supplied should not be used as a toy. · For indoor use only
Failure to observe the above instrucons may constute misuse of the product and can cause serious injury or burns.
Instrucon
Thank you for purchasing SNAILAX Neck and Back Massager . With normal care and proper treatment, it will provide years of reliable service. Please read all instrucons carefully before using this product. Please retain this manual for future reference.
FEATURES
– Electrically height-adjustable Shiatsu neck massage – Rolling massage with adjustable width control – Customized Area back Massage – With oponal heat funcon on neck and back massage – Massage areas can be selected (upper, lower, Full) – Seat vibraon massage (3 intensity levels for opons) – Compression on back and seat (3 intensity levels for opons) – Opcs PU leather and breathable mesh
CONTENTS
· SL-232A Neck and Back Massager · 12V home adpater
Removeable & Washable Cover/Flap
TECHNICAL DATA
Measurements:
30 x 18 inches (Back) 22 x15 inches (Seat)
Weight:
18 lbs
Voltage:
Input: AC 100-240V ~50/60Hz
Output:12VDC 5.0A
Rated Power:
60Wa
Default Automac runme: 15 minutes
Setup and Operaon
1. Aach the massager to a chair with elasc straps or place it on other support. 2. Connect the adapter cable to the corresponding cable on the cushion.
3. Plug the home adapter into an electric outlet. 4. Turn on the device using the controller ( instrucons on page 5 ). 5. When finished place the controller in the pouch at the side of the cushion. 6. Detachable intensity control flap for back lets you choose a soer or more intense massage. 7. Detachable cover for neck lets you choose a soer or more intense massage.
Note : If the Shiatsu is too strong,
Install the neck cover / back flap onto the cushion to get a soer massage. Place a blanket or towel between you and the massager to achieve a far
soer massage intensity if you sll feel too strong shiatsu aer installing the flap onto the cushion.
If the shiatsu can’t reach your neck,shoulder,lower back area
If you want to massage your neck, shoulder,lower back, but the shiatsu nodes can not reach the area in need. You may adjust the height of your back when sing, by placing a seat cushion or a pillow on the sing part.
Removable cover / flap
Blanket /Towel
Seat cushion
· The device will automacally switch off aer 15 minutes mer run out · Remove the adapter from the outlet when not in use. · Do not setup or use the massager in a bathroom or similary wet / damp areas.
!Aenon · You should allow your body some rest periods. To avoid straining your muscles
too much, we recommend to not exceed a connuous massage of 15 Minutes per me and not exceed 3 mes use one day.
Controller Instrucons
1. / NECK massage height adjustment Long Press these buons to manually adjust
Neck Massage height.
2. / NECK massage Direcon Manual programme: Press once to turn on neck massage, press again to shi rotaon direcon,
AUTO
SHIATSU
press once again to turn off. Auto programme: press to turn on neck shiatsu and automacally shi rotaon direcon per 1min,
UPPER LOWER
ROLLING TARGET
press again to turn off.
3. AUTO: press to acvate all funcons, press again to turn off.
Upper/Lower: Select Upper or Lower back to designate the area covered by the shiatsu massage.
4. Shiatsu Buon To turn on/off a full back shiatsu massage.
Note: Does not work with Adjust Buon.
5. Adjust Buon
To adjust the width of the massage nodes
during the rolling massage.
6. Rolling Buon Press to acvate Rolling funcon, the massage nodes travel up & down across the
muscle gently.
7. Heat Therapy: Press to acvate heat funcon on neck and back Simultaneously.
The heat can be turned on independently.
8. Target Buon Press to focus traveling massage nodes at desired posion.
9. Air Compression Buon Press to turn on/off the seat and lumbar compression massage funcon on thighs,
seat and waist. Three compression intensity are selectable.
10. SEAT Buon To turn on/off seat vibraon Massage, Low, Medium, High three intensity for opon.
11. Power Buon Press to acvate standby mode, it must be on for any funcon to work,
press again to turn off.
Note: Switching off the power while in operaon will cause the rollers to return to their storage posion.
Care and Cleaning Instrucons
1. Do not wash in washing machine or immerse the product or the adapter in water. 2. Always switch off before cleaning and remove the adapter from the socket with clean, dry hands. 3. The massager should be wiped with a slightly moist cloth and dried thoroughly. Do not wipe the
product with alcohol or harsh chemicals such as thinner or bleach. 4. The Cover for neck is detachable and washable. 5. Do not overstretch the elasc back straps. 6. Keep away from heat, fire or exposure to direct sunlight. 7. Do not apply excessive pressure or impact onto massager/massage heads. Applicaon of a direct
force in excess of 110 lbs. may damage your massager and invalidate your warranty. Refrain from over usage of the device. 8. Store the massager in a cool, dry place out of reach of children. 9. Avoid contact with sharp edges or pointed objects which might cut or puncture the cover of massager.
TROUBLESHOOTING GUIDE
Fault
Massage heads rotang at reduced speed.
The massager rollers stop during the massage session.
Device switches off suddenly
Device fail to start
Jerky moon of massage heads / Vibraons from device Infra-red lights are on but no moon from massage heads
Solutions
The load on the massage heads is excessive. Reduce load and try again. The roller mechanism may be stalled when subjected to excessive force. Release excessive force on the rollers. Device may have been in use for 15mins. Auto-shutoff funcon acvated. Connue using by pressing the `power’ buon aer resng the unit for 15mins. Over-heat protecon funcon acvated. Device is switched off for your safety. Please rest device for 1530mins before restarng. Check if device has been used for more than 15mins. If so, let device rest for 15mins before connuing. Device may require longer me to cool in warmer environments. Check if adapter is plugged into socket. Check if adapter output is connected to device power inlet wire. Excessive pressure may have been applied onto the device. Reduce the load and try again.
Device may be jammed. Remove pressure / load from the device and press the ‘Full Back’ buon to try again.
Warranty
If you have any issue about the product, please feel free to contact us by sending email to [email protected] We will strive to provide the best service possible within 24 hours. 30 days uncondionally Return Snailax product can be returned to receive a full refund for any reason within 30 days. Please contact our customers service ([email protected]), our staff will contact you within 24 hours. 90 days refund/replace Snailax product can be returned / replaced within 90 days if the product break down in the period of proper use. 12 months Warranty If the product break down within 12 months in the period of proper use, customers can enjoy the relevant warranty to get them replaced. Aenon! No warranty will be given to any force majeure and man-made causes to a defecve product, such as improper care, personal tear down and willful damage,etc.
Extend Warranty for Free
1) Enter the following URL or scan the QR code below to find Snailax facebook page and like it, enter”Warranty” to messenger to extend your warranty from 1 year to 3 years.
hps://www.facebook.com/snailax OR 2) Send message”Warranty” and email us [email protected] to extend your
warranty from 1 year to 3 years.
Have question ?
Tel: 734-709-6982 Monday-Friday 9:00AM-4:30PM
Email: [email protected]
FCC STATEMENT
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful interference in a residenal installaon. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instrucons, may cause harmful interference to radio communicaons.However, there is no guarantee that interference will not occur in a parcular installaon. If this equipment does cause harmful interference to radio or television recepon, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separaon between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio / TV technician for help. This device complies with Part 15 of the FCC Rules. Operaon is subject to the following two condions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operaon. WARNING: Changes or modificaons to this unit is not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
2750 Carpenter Road, Suite 1 B, Ann Arbor, 48108
Tel:734-709-6982 [email protected]
