MGD5030MW1 Gas Dryer
Product Information: Product Name: Gas Dryer Model:
MGD5030MW1 (White) Part Number: W11643287 Rev. A Date of
Manufacture: 10/05/2022 Top and Console Parts: 1. Literature
Parts: – Owners Manual: W11361424 – Tech Sheet: W11495041 – Quick
Start Guide: W11466172 2. Connector, Service Standalone: W11438904
3. Appliance Control Unit (ACU): W11625656 4. Rear Panel: W10775189
5. Main Harness: W11437794 6. Clip, Console: 8312709 7. Screw:
3390663 8. Lint Screen – White: W11538108 9. Rotary Encoder Switch
(2 Position): W10414381 10. Screw: 688983 11. Screw: 3348629 12.
Top – White: W10613389 13. Nut, U: W10298336 14. Knob, Large:
W11328381 15. Knob, Small: W11398762 16. Console Assembly – White:
W11576588 17. Clip, Spring: 688805 18. Badge: W10612925 19. Collar,
Lint Chute: W10662472 20. Rotary Encoder Switch (3 Position):
W10414397 21. Screw: 9740848 22. Screw: 343641 23. Seal, Console:
W10726632 24. Upper Encoder RS Harness: W11486550 25. Upper Encoder
Harness: W11437795 Cabinet Parts: 1. Screw: 3390631 2.
Screw: 343641 3. Screw: 693995 4. Seal, Spill Guard: W10841728 5.
Cover, Terminal Block: 8558833 6. Clamp, Motor Mount: W10121316 7.
Rear Panel: W11598681 8. Plug, Strike: W10567345 9. Cover, Door
Catch: W10529198 10. Door Switch: W10569603 11. Screw: 697773 12.
Power Cord: W10869141 13. Clamp, Pipe: 341029 14. Hinge Hole Cover
– White: W11308618 15. Clip, Front Panel: W10775448 16. Dryer Foot:
W10779369 17. Motor Clamp (With Shield): 3404162 18. Cabinet –
White: 8530603 19. Clip, Ground: 98234 20. Lock, Front Top: 8066092
21. Front Panel – White: W10664698 22. Top Hinge: W10641296 23.
Clip, Felt Pad: 685203 24. Door Catch Assembly: W11224630 25. Door
Seal: W10730752 26. Idler Assembly: 691366 27. Screw: 342055 28.
Hinge and Pin Assembly – White: W10362431 29. Motor Assembly:
W10396029 30. Motor Pulley: 8066184 31. Drive Belt: W10131364 32.
Bolt: 3400500 33. Door Strike: W11224633 34. Motor Base: 348780 35.
Inner Door: W10463967 36. Outer Door – White: W10714510 37. Door
Handle – White: W10714516 38. Seal and Bearing Assembly: W10803476
39. Front Panel Plug: 8564457 40. Burner Assembly (60 Hz) (Type 1):
W11564940 41. Foam Seal: W10316529 42. Spill Guard Seal: W10316619
43. Door Catch Bezel: W10529197 44. Pipe Clamp: W10727507 45. Rear
Bracket: W10641295 Bulkhead Parts: 1. Lint Chute Assembly:
W10798023 2. Screw: 489463 3. Washer: 3388703 4. Lint Chute Seal:
347139 5. Screw: 90767 6. Exhaust Shield: W10389567 7. Thermal Fuse
(91C): 3392519 8. Drum Light Lens: 3402841 9. Thermistor: 8577274
10. Blower Wheel: 694089 11. Blower Housing: 8577230 12. Heater Box
Clip: 3398161 13. Screw: 343641 14. Heater Box (96C): 8530285 15.
High Limit Thermostat SPST (180F): W10754607 16. Thermal Cut-Off
Kit (Includes Thermostat): W11050897 17. Screw: 3390647 18. Burner
Funnel: 8066049 19. Seal: 339956 20. Drum Baffle (Short): 3403636
Product Usage Instructions: 1. Refer to the “Owners Manual”
(W11361424) for detailed instructions on using the gas dryer. 2.
Before using the gas dryer, ensure that it is properly connected to
a gas supply and electrical power source. 3. Open the dryer door
and load the clothes into the drum, making sure not to overload it.
4. Close the door securely. 5. Set the desired drying cycle and
options using the knobs and buttons on the console assembly (refer
to the “Tech Sheet” – W11495041 for cycle and option details). 6.
Press the power button or turn the rotary encoder switch to start
the dryer. 7. The dryer will automatically adjust the drying time
based on the selected cycle and the moisture level of the clothes.
8. Monitor the drying progress through the door window or by
checking the control panel display. 9. Once the drying cycle is
complete, remove the dry clothes from the drum. 10. Clean the lint
screen (W11538108) after each use to ensure optimal performance and
prevent lint buildup. 11. If any issues or errors occur during
operation, refer to the “Tech Sheet” (W11495041) or contact
customer support for troubleshooting assistance. Please note that
these instructions are a general overview and it is important to
consult the specific user manual for your model (W11361424) for
complete and accurate usage instructions.
GAS DRYER MODELS:
MGD5030MW1 (White)
10/05/2022
© 2022 Maytag
Part No. W11643287 Rev. A
TOP AND CONSOLE PARTS
10/05/2022
2
Part No. W11643287 Rev. A
TOP AND CONSOLE PARTS
Illus. No. Part No. Description
Illus. No. Part No. Description
1
Literature Parts
W11361424 Owners Manual
W11495041 Tech Sheet
W11466172 Quick Start Guide
2 W11438904 Connector, Service Standalone
3 W11625656 Appliance Control Unit (ACU)
4 W10775189 Panel, Rear
5 W11437794 Harness, Main
6 8312709 Clip, Console
7 3390663 Screw
8
Lint Screen
W11538108 White
9 W10414381 Switch, Rotary Encoder (2 Position)
10
688983 Screw
11 3348629 Screw
12
Top
W10613389 White
13 W10298336 Nut, “U”
14 W11328381 Knob, Large
15 W11398762 Knob, Small
16
Assembly, Console
W11576588 White
17
688805 Clip, Spring
18 W10612925 Badge
19 W10662472 Collar, Lint Chute
Illus. No. Part No. Description
20 W10414397 Switch, Rotary Encoder (3 Position)
21 9740848 Screw
22
343641 Screw
23 W10726632 Seal, Console
24 W11486550 Harness, Upper Encoder RS
25 W11437795 Harness, Upper Encoder
10/05/2022
3
Part No. W11643287 Rev. A
CABINET PARTS
10/05/2022
4
Part No. W11643287 Rev. A
CABINET PARTS
Illus. No. Part No. Description
Illus. No. Part No. Description
Illus. No. Part No. Description
1 3390631 Screw
2
343641 Screw
3
693995 Screw
4 W10841728 Seal, Spill Guard
5 8558833 Cover, Terminal Block
6 W10121316 Clamp, Motor Mount
7 W11598681 Panel, Rear 8 W10567345 Plug, Strike 9 W10529198 Cover, Door Catch
10 W10569603 Switch, Door
11
697773 Screw
12 W10869141 Cord, Power
13
341029 Clamp, Pipe
14
Hinge Hole Cover
W11308618 White
15 W10775448 Clip, Front Panel
16 W10779369 Foot, Dryer 17 3404162 Clamp, Motor (With
Shield)
18
Cabinet
8530603 White
19
98234 Clip, Ground
20 8066092 Lock, Front Top
21
Panel, Front
W10664698 White
22 W10641296 Hinge, Top
23
685203 Clip, Felt Pad
24 W11224630 Assembly, Door Catch
25 W10730752 Seal, Door
26
691366 Idler Assembly
27
342055 Screw
28
Assembly, Hinge and
Pin
W10362431 White 29 W10396029 Assembly, Motor 30 8066184 Pulley, Motor 31 W10131364 Belt, Drive 32 3400500 Bolt 33 W11224633 Strike, Door
34
348780 Base, Motor
35 W10463967 Door, Inner
36
Door, Outer
W10714510 White
37
Handle, Door
W10714516 White
38 W10803476 Assembly, Seal and Bearing
39
Plug, Front Panel
8564457 White 40 W11564940 Burner Assembly (60
Hz) (Type 1)
41 W10316529 Seal, Foam 42 W10316619 Seal, Spill Guard
43 W10529197 Bezel, Door Catch
44 W10727507 Clamp, Pipe 45 W10641295 Bracket, Rear
10/05/2022
5
Part No. W11643287 Rev. A
BULKHEAD PARTS
10/05/2022
6
Part No. W11643287 Rev. A
BULKHEAD PARTS
Illus. No. Part No. Description
Illus. No. Part No. Description
1 W10798023 Assembly, Lint Chute
2
489463 Screw
3 3388703 Washer
4
347139 Seal, Lint Chute
5
90767 Screw
6 W10389567 Shield, Exhaust
7 3392519 Fuse, Thermal (91C)
8 3402841 Lens, Drum Light
9 8577274 Thermistor
10
694089 Wheel, Blower
11 8577230 Housing, Blower
12 3398161 Clip, Heater Box
13
343641 Screw
14 8530285 Box, Heater (96C)
15 W10754607 Thermostat, High Limit SPST (180F)
16 W11050897 Kit, Thermal Cut-Off (Includes Thermostat)
17 3390647 Screw
18 8066049 Funnel, Burner
19
339956 Seal
20 3403636 Baffle, Drum (Short)
21 8578825 Bracket, Drum Light
22
90296 Nut, Push On
23 W11398682 Bracket, Bulkhead Chute
24 W11032820 Bracket, Support 25 W10512946 Washer, Tri Ring 26 W10359270 Shaft, Drum Roller –
Left Hand Thread
27 W10359269 Shaft, Drum Roller Right Hand Thread
28 3397590 Roller, Support
29
348197 Washer
30 W10298789 Nut, Hex
31 W10714469 Bulkhead
Illus. No. Part No. Description
32
338906 Sensor, Radiant
33
692490 Baffle, Drum (Long)
34
692526 Bearing, Ring
35 W10219342 Screw
36 W10856781 Seal, Rear Drum
37 W10757750 Assembly, Drum (Complete)
38 3406124 Bulb, Light 39 W10214261 Socket, Light 40 W11424720 Pad, Sensor
10/05/2022
7
Part No. W11643287 Rev. A
BURNER ASSEMBLY PARTS
10/05/2022
8
Part No. W11643287 Rev. A
BURNER ASSEMBLY PARTS
Illus. No. Part No. Description
1 W11564940 Burner Assembly (60 Hz) (Type 1)
2
688617 Tube, Burner
3
694298 Bracket, Ignitor
4
686590 Ignitor
5 W10366705 Screw
6
343641 Screw
Illus. No. Part No. Description
7
693986 Base, Burner
8 3387057 Screw
9
Orifice, Burner
234826 Type 1 (Natural)
10 W11564943 Valve, Gas (60 Hz)
11 W10295523 Pipe Plug 12 W10328463 Coil (60 Hz)
Illus. No. Part No. Description
13 326049536 Screw Following Parts Not Illustrated
W11581316 Kit, LP Conversion
10/05/2022
9
Part No. W11643287 Rev. A
OPTIONAL PARTS (NOT INCLUDED)
ACCESSORY PARTS Illus. No. Part No. Description
PAINT, TOUCH-UP (1/2OZ.) Illus. No. Part No. Description
PAINT, BULK (1 QT.) Illus. No. Part No. Description
279948 Kit, Dryer Repair
346764 Kit, Hold Down W10242307 Washer, Hose
3976300 Washer, Inlet Hose
W10336486 Connector, Hose -“Y”
W10636192 Dry Rack
72017 White
PAINT, PRESSURIZED SPRAY (12 OZ.)
Illus. No. Part No. Description
350930 White 350938 Gray Primer
799344 White (Uncut)
10/05/2022
10
Part No. W11643287 Rev. A
