FRT300 Folding Platform Trolley
Folding Platform Trolley
Product Information:
- Stock No.: 04692
- Part No.: FRT300
- Max. static load: 300kg
- Max. dynamic load: 200kg approx.
- Wheel diameter: approximately 127mm
- Dimensions: L 910 x W 610 x H 870mm
- Net weight: 12.5kg
Usage Instructions:
- Before using the Folding Platform Trolley, read the user manual
in full and keep it for future reference. - Check for the latest version of the manual by visiting
drapertools.com/manuals. - Remove the product from the packaging and inspect it for any
signs of damage. - Check all parts against the list provided in the manual. Do not
attempt to use the product if any part is missing or damaged. - To assemble the trolley, position the trolley platform (A)
upside down with the folded handle against the floor. - Attach the swivel castors (B) to the back of the trolley
platform using the M10 x 15mm hex bolts (D) and M10 spring washers
(E). The swivel castors must be installed at the back of the
trolley (beneath the handle). - Attach the fixed castors (C) to the front end of the trolley
platform using the same bolts and washers. - Tighten all bolts and turn the trolley over onto the
castors. - Open the trolley handle and use the product as required.
- Dispose of packaging materials responsibly and in accordance
with local regulations. Keep packaging for the duration of the
warranty period in case the product needs to be returned for
repair.
Health and Safety Information:
- Read all instructions before attempting to assemble, use, or
maintain the product. - Non-compliance may result in injury or damage to the user, the
product, or the load. - Do not modify the product in any way.
- Keep packaging materials out of reach of children.
Maintenance and Disposal:
- If the product develops a fault, return it to your nearest
distributor or contact Draper Tools directly. Proof of purchase
must be provided. - If the fault is due to defective materials or workmanship,
repairs will be carried out free of charge within the warranty
period. - The warranty covers parts and labor for 12 months from the date
of purchase, or 90 days if the product is hired out. - The warranty does not cover consumable parts, batteries, normal
wear and tear, misuse, careless or unsafe handling, alterations,
accidents, or repairs attempted or made by any personnel other than
the authorized Draper Tools repair agent.
Explanation of Symbols:
The manual contains symbols that indicate important information.
These symbols are explained in the manual.
FOLDING PLATFORM TROLLEY
EN
Original Instructions Version 1 January 2023
04692 FRT300 ASSEMBLY INSTRUCTIONS
Read this manual in full before using this product and retain it for future use. Always use the latest version of the manual. For the latest version of this manual please visit drapertools.com/manuals
1. Specification
Stock No. Part No. Max. static load: Max. dynamic load: Wheel diameter: Dimensions: Net weight:
04692 FRT300 300kg 200kg approx. 127mm L 910 x W 610 x H 870mmm 12.5kg
2. Health and Safety Information
Important: Read these instructions before attempting to assemble, use or maintain this product. Non-compliance may result in injury or damage to the user, the product or the load.
·Keep your work area well lit, with bystanders at a safe distance. ·Assemble this product only in the manner depicted and do not modify the
product in any way.
·Before every use, inspect the trolley for broken or cracked parts and loose fixtures.
WARNING! DO NOT use this product if its structural integrity is compromised. Tighten, replace or repair all affected parts before use. ·Only use this product on firm, level surfaces capable of supporting both the trolley and its load. -DO NOT use this product on sloped or slippery surfaces. -Where available, use ramps to mount kerbs and other raised edges.
·DO NOT ride on or allow others to ride on this product.
·DO NOT exceed the maximum rated capacities of this product.
·When in use, ensure that the load is distributed evenly and that the trolley is not overbalanced. -Be mindful of changes to the weight distribution when loading and unloading.
·ALWAYS ensure that the heaviest part of the load is flat against the trolley platform.
·Ensure that the load is stable and secure before transporting it.
·Manoeuvre the product using the handle ONLY and maintain full control of the trolley at all times. -This product is intended to be pushed; only pull if absolutely necessary.
·Plan your route and ensure that the castors are not obstructed before moving the trolley.
·DO NOT leave the trolley unattended while under load.
3. What’s in the Box?
Carefully remove the product from the packaging and examine it for any signs of damage that may have occurred during shipment.
Before assembling the product, lay the contents out and check them against the parts shown below. If any part is damaged or missing, do not attempt to use the product. Please contact the Draper Helpline; contact details can be found at the back of this manual.
Please visit drapertools.com for our full range of accessories and consumables.
Keep the product packaging for the duration of the warranty period in case the product needs to be returned for repair.
WARNING! Keep packaging materials out of reach of children. Dispose of packaging correctly and responsibly and in accordance with local regulations.
A. 1 x Trolley platform B. 2 x Swivel castors
(B)
(D) (A)
(C) (E)
C. 2 x Fixed castors D. 16 x M10 x 15mm hex bolts
E. 16 x M10 spring washers
4. Assembly Instructions
Important: Before assembling this product, read and understand all the safety instructions listed in this manual. Screw all bolts finger-tight and tighten when assembly is complete.
(A)
6. Maintenance and Disposal
·Periodically check that all bolts are tightly secured and lubricate all moving parts.
·Store this product in a clean and dry environment, out of direct sunlight and out of reach of children.
·At the end of its working life, dispose of the product responsibly and in line with local regulations.
·Recycle where possible.
7. Warranty
(B)
Should the tool develop a fault, return the complete tool to your nearest distributor or contact Draper Tools directly. Proof of purchase
(C)
must be provided.
If, upon inspection, it is found that the fault occurring is due to defective
materials or workmanship, repairs will be carried out free of charge.
This warranty covers parts and labour for 12 months from the date of
(E)
purchase. However, if the tools are hired out, the warranty period is
90 days from the date of purchase.
This warranty does not apply to any consumable parts, batteries or normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs attempted or made by any personnel other than the authorised Draper Tools repair agent.
For full details, visit drapertools.com/warranty
(D)
8. Explanation of Symbols
1. Position the trolley platform (A) upside down with the folded handle against the floor.
2. Use the M10 x 15mm hex bolts (D) and M10 spring washers (E) to attach the swivel castors (B) to the back of the trolley platform (where the handle is attached) and the fixed castors (C) to the front end.
3. Tighten all bolts, then turn the trolley over onto the castors and open the trolley handle.
Important: To prevent warping of the wheels, the swivel castors MUST be installed at the back of the trolley (beneath the handle).
Read the instruction manual Overall body length Overall body width
5. Opening and Folding the Handle
Overall body height
Folded body height
Max. capacity on level ground
Fig.1
To open or fold the handle, press down on the locking bar with your foot and manoeuvre the handle to the desired position. Carefully release the locking bar when the desired position has been reached.
Important: The handle is not locked in position when folded away. Take care when transporting the trolley as the handle may swing open and cause injury.
Helpline: +44 (0) 23 8049 4344 Sales Desk: +44 (0) 23 8049 4333 General Enquiries: +44 (0) 23 8026 6355 Website: drapertools.com Email: [email protected]
Draper Tools Limited, Hursley Road, Chandler’s Ford, Eastleigh, Hampshire, SO53 1YF, UK
