XT+ Releasing Control Unit
Product Information
The XT+ Releasing Control Unit is a product manufactured by
Kentec Electronics Ltd. It is designed to provide control and
monitoring capabilities for fire suppression systems. The unit
features various terminals and wiring connections to facilitate the
integration of different components.
Key Features:
- Addressable modules with DIP switches for easy
configuration - Power supply connections for AC input and field
terminations - Standby batteries for backup power
- Alarm terminals for connecting audible loads
- Extinguishing circuits for controlling releasing agents
- Top and bottom terminals for various control and monitoring
functions - CIE serial communication for data transfer
Product Usage Instructions
- Setting the Module Address: Set the address
DIP switches on each module to a unique address between 1 and
15. - Power Supply: Connect 18 to 14 AWG wiring for
all field terminations except the AC input. Connect 14 AWG wiring
for line, neutral, and ground terminations of the AC input. - Standby Batteries: Use two standby batteries
wired in series. The batteries should be 12 VDC, valve-regulated
lead acid type with a maximum amp hour capacity of 60 AH. Connect
the batteries to the unit for standby operation. The battery charge
voltage should be 27.6 VDC. - Alarm Terminals: Use the provided terminals
for connecting nonpulsing audible loads. Each terminal provides a
regulated 24V DC, with a maximum output of 850 mA. Ensure to use a
10k Ohm resistor for the required end-of-line (EOL)
connection. - Extinguishing Circuits: Connect the Exting. 1
(Main) and Exting. 2 (Reserve) circuits to releasing agent control
valves. Each circuit provides regulated 24V DC at a maximum output
of 1A. Use an EOL diode for the required end-of-line
connection. - Top Terminals: The top terminals provide
various power and control outputs. Refer to the product manual for
detailed specifications of each terminal. - Bottom Terminals: Remove the jumper LK1 from
each module, unless it is the last device on the CIE serial bus.
The bottom terminals are designed for different control and
monitoring functions. Refer to the product manual for detailed
specifications of each terminal. - CIE Serial: Use a two-wire RS485 connection
for CIE serial communication. Ensure that the data voltage is 3.3V
and current-limited. The communication is supervised and operates
in a Class B mode.
WIRING DIAGRAM XT+ Releasing Control Unit
CONTENTS
WIRE ROUTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SETTING THE MODULE ADDRESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 POWER SUPPLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 3RD STAGE ALARM / 2ND STAGE ALARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 EXTING. 1 (MAIN) AND EXTING. 2 (RESERVE). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 STANDBY BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 TOP TERMINALS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 BOTTOM TERMINALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 LIST OF APPROVED DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 REFERENCES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
*Man-1255KE*
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
2
WIRE ROUTING
Because the fascia is hinged, route all wiring to the left as shown, so that the fascia can be opened without disconnecting the wiring. Power-limited conductors must be installed using Types FPL, FPLR, FPLP, or equivalent cables. When connecting field wiring, separate high and low voltage wiring in the enclosure with a minimum gap of 0.25″. Do not route low voltage cabling through the same conduit as AC lines. AC power lines should be threaded through a dedicated conduit. Refer to this illustration when connecting any wiring.
SETTING THE MODULE ADDRESS
Set the address DIP switches on each module to a unique address between 1 and 15.
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
POWER SUPPLY
Connect 18 to 14 AWG wiring for all field terminations except the AC input. Connect 14 AWG wiring for line, neutral, and ground terminations of the AC input.
AC SUPPLY CIRCUIT SPECIFICATIONS
L
AC Power
1.83 Amps Max @ 120 V, 50/60 Hz
0.915 Amps Max @ 240 V, 50/60 Hz
N Neutral
G Earth Ground
3
STANDBY BATTERIES
RECHARGABLE BATTERY SPECIFICATIONS
Standby Battery Type
12 VDC, valve-regulated lead acid
Standby Battery Charging
Two standby batteries wired in series
Maximum Amp Hour Capacity 60 AH maximum
Charge Current
1.25 A Max
Output Current
4 A Max
Standby Operating Time
24 Hours
Battery Charge Voltage
27.6 VDC
3RD STAGE ALARM / 2ND STAGE ALARM
Each terminal provides a regulated 24V DC, 850 mA maximum output for nonpulsing audible loads. Required EOL: 10k Ohm Resistor (S2028) Maximum Line Loss: 4V Maximum RMS Current for any Single Appliance: 300 mA
EXTING. 1 (MAIN) AND EXTING. 2 (RESERVE)
The Exting. 1 and Exting. 2 are class B circuits, each providing regulated 24V DC at 1A maximum. They can be connected to a releasing agent control valves as shown. Required EOL: EOL Diode (S2029)
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
4
TOP TERMINALS
TOP TERMINAL SPECIFICATIONS
24V Power
24V Regulated, continuous (power input)
Aux 24V
24V Regulated @ 850mA Max, Power-limited
Trouble
Volt-free contact rated at 30V DC, 1A, Resistive
1st Stage
Volt-free contact rated at 30V DC, 1A, Resistive
2nd Stage
Volt-free contact rated at 30V DC, 1A, Resistive
3rd Stage (Released)
Volt-free contact rated at 30V DC, 1A, Resistive
Supv. / Abort
Volt-free contact rated at 30V DC, 1A, Resistive
Extract
Volt-free contact rated at 30V DC, 1A, Resistive
3rd Stage Alarm
24V Regulated @ 850mA Max, Power-limited
2nd Stage Alarm
24V Regulated @ 850mA Max, Power-limited
Exting. 1 (Main)
24V Regulated @ 1A Max, Power-limited
Exting. 2 (Reserve)
24V Regulated @ 1A Max, Power-limited
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
5
BOTTOM TERMINALS
IMPORTANT! Remove the jumper LK1 from each module unless the module is the last device on the CIE serial bus.
BOTTOM TERMINAL SPECIFICATIONS
Man. Rel Abort Disable Mode Rel P. Sw Low Press.
Class B Supervised for opens, shorts, and grounds End-of-Line device: 6.8K Ohm resistor (S2027) Activation device: 470 Ohm resistor (S2051) Maximum Voltage / Current: 24V DC / 50 mA Maximum Wiring Impedance for Each Circuit: 50 Ohms Power-limited
CIE Serial
Two wire, RS485 connection, Data 3.3 V, current-limited, Class B, supervised
Status Serial
Two wire, RS485 connection, Data 3.3 V, current-limited, Class B, supervised
Status Pow.
24V Regulated @ 850mA Max, Power-limited
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
6
LIST OF APPROVED DEVICES
ACCESSORIES
K1822-10 K1822-40
Ancillary Board with Enclosure
K1823-10 K1823-40
Abort Switch, Suitable for Releasing
K1821-11 K1821-12 K1821-13 K1821-14 K1821-41 K1821-42 K1821-43 K1821-44
K1832-10 K1832-40
XT+ Status Unit Surface mount, Red Flush mount, Red Surface mount with Keyswitch, Red Flush mount with Keyswitch, Red Surface mount, Grey Flush mount, Grey Surface mount with Keyswitch, Grey Flush mount with Keyswitch, Grey
Manual Extinguishant Disablement Switch
K1824-10 K1824-11 K1824-40 K1824-41
Sequential Activator, Suitable for Releasing Standard cabinet, Red Large cabinet, Red Standard cabinet, Gray Large cabinet, Gray
COMPATIBLE RELEASING DEVICES
ASCO
8210G207
ASCO
HV2185328
Fire Eater
305451 Ci IS8B Solenoid and Manual
Fire Eater
305450 Ci IS8B Solenoid
Firetrace, TLX Technologies
Linear Actuator-FTF500125 or 01-501462; TLX Technologies PA0128-5
Firetrace
FTF500024, Solenoid, 24VDC, 11W
Firetrace
FTF501224, Solenoid, 24VDC, 15W
Janus
18481
Kidde
B6793-859: The B6793-859 is equivalent to Kidde-Fenwall 81-100000-001
Kidde
K-45-8017: The K-45-8017 is equivalent to Kidde-Fenwall 486500-01
Safety Hi-Tech
SH21006404
Safety Hi-Tech
SH21006403
Sevo Systems. TLX Technologies SOL EA45: The SOL EA45 is equivalent to Sevo Systems 510006 and TLX Technologies PA0036-3
Snap-Tite, Sevo Systems, Orient 2823A-2NB-A4F6 Chemori, Solenoid Solutions
Victaulic
Series 753-E FireLock
Viking
11596
Viking
11595
Viking
11592
Viking
11602
Viking
11601
Viking
11591
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
7
SPECIAL RELEASING ACCESSORIES
Kentec Electronics Sequential Activator
K1824-10 or -40 (Red or Gray) K1824-11 or -41 (Red or Gray) FP-SA/GEN3.0 (Gray) FP-SA/GEN3.0R (Red) FP-SA/GEN3M8 (Gray) FP-SA/GEN3M8R (Red)
FirePro Fixed Condensed Aerosol FP-20SE (FNX-20S)
Extinguishing System Units
FP-20T (FNX-20T)
FP-40S (FNX-40S)
FP-40T (FNX-40T)
FP-80S (FNX-80S)
FP-80T (FNX-80T)
FP-100S (FNX-100S)
FP-200S (FNX-200S)
FP-500S (FNX-500S)
FP-1200 (FNX-1200)
FP-1200S (FNX-1200S)
FP-1200T (FNX-1200T)
FP-1200TS (FNX-1200TS)
FP-2000 (FNX-2000)
FP-2000S (FNX-2000S)
FP-2000T (FNX-2000T)
FP-2000TS (FNX-2000TS)
FP-3000 (FNX-3000)
FP-3000S (FNX-3000S)
FP-3000T (FNX-3000T)
FP-3000TS (FNX-3000TS)
FP-4200T (FNX-4200T)
FP-4200TS (FNX-4200TS)
FP-5700 (FNX-5700)
FP-5700S (FNX-5700S)
FP-5700T (FNX-5700T)
FP-5700TS (FNX-5700TS)
Please refer to instructions included with Sequential Activator for proper wiring.
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
8
SPECIAL RELEASING ACCESSORIES (continued)
Fireway Inc. STAT-X Aerosol Fire Suppression System
Stat-X, 30E Stat-X, 60E Stat-X, 60ME Stat-X, 100E Stat-X, 250E Stat-X, 500E Stat-X, 1000E Stat-X, 1500E Stat-X, 2500E Stat-X EX, 30E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 30E, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 60E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 60E, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 60ME, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 60ME, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 100E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 100E, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 250E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 250E, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 500E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 500E, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 1000E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 1000E, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 1500E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 1500E, CLI DIV2/Zone 2, SS Elbow Stat-X EX, 2500E, CLI DIV2/Zone 2, Brass Elbow Stat-X EX, 2500E, CLI DIV2/Zone 2, SS Elbow
Please refer to instructions included with Sequential Activator for proper wiring.
15100 15110 15111 15120 15130 15140 15150 15160 15170 11880 11885 11890 11895 11900 11905 11910 11915 11920 11925 11930 11935 11940 11945 11950 11955 11960 11965
REFERENCES
Reference the following documentation for installing, operating, and configuring this device with the XT+ Releasing Control Unit: · XT+ Releasing Control Unit Installation Manual, MAN-1252KE · XT+ Releasing Control Unit Operating Instructions, MAN-1253KE
For technical support, contact Kentec Electronics, Ltd at +44 (0)1322 222121 or techsupport@ kentec.co.uk.
Document Number MAN-1255KE Version 1.01
September 2022
Kentec Electronics Ltd | Units 25-26 Fawkes Avenue | Questor, Dartford | Kent DA1 1JQ United Kingdom | +44 (0)1322 222121 | www.kentec.co.uk
