Ford 2.0 EcoBlue TDCi Vibration Damper Pulley Puller

Product Information:

• Part No.: 7334
• Product Name: Vibration Damper Pulley Puller
• Manufacturer: Laser Tools
• Website: www.lasertools.co.uk

Product Usage Instructions:

1. Ensure you are using this product with hand tools only.
2. Keep the threaded force screw clean and lubricated with
   Molybdenum Disulphide grease.
3. Failure to adequately lubricate the force screw and frame may
   result in damage, which will affect the product warranty.
4. Refer to OEM derived data such as the vehicle manufacturers’
   own data or Autodata for specific guidance on usage.

Compatible Applications:

For more up-to-date applications, please visit the product page on the
Laser Tools website.

Please note that the instructions provided are for guidance
only. It is recommended to refer to OEM derived data or consult the
vehicle manufacturers’ own data for precise instructions. The use
of this kit is solely at the user’s discretion, and Tool Connection
Ltd. cannot be held responsible for any damage caused.

Safety Warnings:

• Only use this product with hand tools.
• Keep the threaded force screw clean and lubricated with
  Molybdenum Disulphide grease.
• Failure to adequately lubricate the force screw and frame may
  result in damage, which will affect the product warranty.

Refer to the provided figures below for visual instructions:

Part No. 7334
Vibration Damper Pulley Puller
Ford 2.0 EcoBlue TDCi Instructions
www.lasertools.co.uk

Introduction
This Pulley Puller kit has been designed for the latest Ford 2.0L EcoBlue TDCi engine which features an innovative “belt in oil” design where the synchronous drive belt is sited inside the oiled area of the engine. In order to gain access to the timing belt area of these engines it is necessary to remove the front pulley which often requires some force. The tool does this by connecting to the inner part of the pulley which ensures no damage to the rubber component of the pulley. For timing belt replacement see Laser 7323.
Components

Applications

Make Ford

Model Edge Focus Focus Active Galaxy Kuga Mondeo S-MAX Transit Transit Custom Tourneo Custom

Year 2018 – 21 2018 – on 2019 – on 2018 – 21 2019 – on 2019 – 21 2018 – 21 2016 – on 2016 – on 2016 – on

Type 2.0 EcoBlue TDCi

Engine Codes BCCA, BCCB, BCCC, BCDA, YLCA, YLCB, YLCC, YLDA, YLDC, YLF6, YLFA*, YLFB*, YLFS, YLR6, YMCA, YMCB, YMCC, YMDA, YMF6, YMFA*, YMFB*, YMFS, YMR6, YNCA, YNF6, YNFA*, YNFB*, YNFS, YNR6
*NOTE: Some Transit use Laser Part No. 8394 (OEM 303-1657).

Ref. Code A C866 B C C867 D

OEM Ref. 204-158-01*
205-295*

Description Crankshaft Protector Spigot Puller Bridge Bolts and Washer x 2 Force Screw

*NOTE: Performs the function of OEM 205-295 (puller) and 204-158-01 (crankshaft nose protector spigot) for the applications listed only.

www.lasertools.co.uk 2

Always refer to the website for most up to date applications: www.lasertools.co.uk/product/7334
The following instructions are for guidance only. Please refer to OEM derived data such as the vehicle manufacturers’ own data or Autodata. The use of this kit is purely down to the user’s discretion and Tool Connection Ltd. cannot be held responsible for any damage caused what so ever.
www.lasertools.co.uk 3

Safety Warnings – PLEASE READ
· Personal protection and safety equipment must be used at all times. Eye protection and protective gloves must be worn when using these tools.
· Misuse of tools is unsafe,and can cause engine damage. · Remove damaged tools from use. · Store in a dry place when not in use.
Warning:
Only to be used with hand tools. The threaded force screw must be kept clean and lubricated with Molybdenum Disulphide grease. Failure to adequately lubricate the force screw and frame may result in damage which will affect the product warranty.

Preparation · Remove starter motor and install flywheel locking tool. · Remove auxiliary drive belt.
Important Notes · Water pump “stretchy” auxiliary drive belt once removed
should not be re-used. · Mark position of RH engine mounting before removal. · Replacement of the timing belt also requires replacement of
the tensioner and cover. · For Engine Timing Tool use Laser 7323.

Where Used

www.lasertools.co.uk 4

www.lasertools.co.uk 5

Instructions
Component A ­ Crankshaft Protector Spigot Component A is used to protect the end of the crankshaft from the forces of the force screw. With the crankshaft pulley bolt (1) and auxiliary drive belt (2) removed insert the crankshaft protector spigot (A) into the end of the crankshaft. NOTE: The crankshaft retaining bolt must be replaced.

Instructions
Component B, C and D ­ Pulley Puller Assembly Components B, C and D are used to push against component A to pull the pulley off. Assemble B, C and D as shown in Fig.2. · Ensure the force screw (D) is well lubricated with
Molybdenum Disulphide grease at the points shown in Fig.2. · Ensure the holding bolts (C) are evenly tightened and that
the force screw (D) sits square and on the centre of the spigot (A). · Wind the force screw in to pull the pulley off.

Fig.1

Fig.2

www.lasertools.co.uk 6

www.lasertools.co.uk 7
