Minotaur Extendable Battery
Lithium Battery Pack Instruction Manual
Product Information
The Minotaur Extendable Battery Pack is an external lithium
battery that can be used to extend the backup time of the Minotaur
Portable Power Station. The battery pack comes with a carrying
strap, user manual, and a cable to connect it to the power station.
The battery pack has a user-friendly LCD digital display and an
IP54 waterproof casing. It is designed for easy portability across
long distances.
Technical Specifications
- Model: Minotaur Extendable Battery
- Battery Capacity: Not specified
- Input: Aviation Socket
- Output: Aviation Socket
- Dimensions: Not specified
- Working Temperature: Not specified
- Working Humidity: Not specified
- Storage Temperature: Not specified
- Technical Standard: Not specified
- Physical Protection(Optional): Not specified
- Net Weight: Not specified
Packing List
- Lithium Battery Pack
- AC / DC Adapter (Optional)
- Carrying Strap
- User Manual
- Cable (to Power Station)
Safety and Precautions
Before using the Minotaur Extendable Battery Pack, please follow
the basic precautions and read all instructions provided in the
user manual. The product includes an AC/DC adapter with input
voltage from 100V to 240V. Connecting to voltages that do not meet
the required specifications is prohibited. The battery pack should
be kept away from heat sources and direct sunlight. It should also
be kept out of reach of children and pets. Close supervision is
required when using this product near children.
Operating Instructions
To use the Minotaur Extendable Battery Pack, follow these
steps:
- Connect the cable provided to the battery pack and the Minotaur
Portable Power Station. - The power station will detect the external battery and display
“Ext” on the LCD screen. - The power station will automatically start drawing energy from
the external battery pack.
Error Codes
No error codes are specified in the user manual.
Operating Conditions
For more information on operating conditions, please visit our
website at www.srportables.com or contact our technical team at +61
3 8618 6984.
Lithium Battery Pack
Instruction Manual
MINOTAUR EXTENDABLE BATTERY PACK
Packing List
1 Pcs 1 Pcs 1 Pcs 1 Pcs 1 Pcs
Lithium Battery Pack AC / DC Adapter (Optional) Carrying Strap User Manual Cable (to Power Station)
Please visit our website www.srportables.com to register your product 1
Part Description
· Press for 3 seconds to turn on and enter the standby state · Press for 3 seconds to shut down
Operating Instructions
Use the cable provided to connect the battery pack to the Minotaur power station. Once connected, the Minotaur power station will detect the external battery and display “Ext” on the LCD screen. The power station will automatically start drawing energy from the external battery pack.
Lithium Battery Pack
Minotaur Portable Power Station 2
Charging Method
Safety and Precautions
Please follow the basic precautions and read all instructions before any operation.
1. The product includes an AC/DC adaptor with input voltage from 100V to 240V. Connecting to voltages that do not meet the required specification sis prohibited.
2. Use only the adaptor supplied with the package to charge the product. 3. Do not drop the product as it may damage the battery and the internal circuit. 4. Do not attempt to disassemble or modify the internal and external structure of the product. 5. Do not connect the positive and negative terminals with foreign objects and materials. 6. Exposure to water may cause circuit failure and lead to abnormal chemical reactions, heat, smoke, explosion or fire. 7. Do not use or place the battery near a fire or any other heat sources (over 80 °C). 8. Do not store the battery in a high temperature environment (>40 °C) for a long time. 9. If the product is not used for a long time, please charge the battery to over 60% capacity, and recharge the battery within 6
months. 10. Close supervision is required when using this product near children.
Features
1. External battery to extend backup time; 2. User friendly LCD digital display; 3. IP54 waterproof casing; 4. Comfortable carrying strap and handles allows easy portability across long distances
Error Codes
3
Technical Specifications
Model Capacity
Input Output
General
Minotaur Extendable Battery Battery Capacity Aviation Socket Aviation Socket Dimensions Working Temperature Working Humidity Storage Temperature Technical Standard Physical Protection(Optional) Net Weight
1395Wh(37.7Ah/37V) Adaptor 42V/7A (Optional) 27.5V-42V 50A max L430xW257xH173.4mm 0 ~ 45°C 0 ~ 90% -20°C ~ 45°C PSE, FCC, CE, UN38.3, ROHS IP54 8.5Kg
Operating Conditions
1. Operational Environment: Indoor and Outdoor (non waterproof) 2. Operational Temperature: Charge 0°C ~ 45°C, Discharge -20°C ~ 60°C (powering appliances) 3. Storage: -20°C ~ 45°C
Visit our website www.srportables.com for more information or contact our technical team on +61 3 8618 6984 4
