WCU110 110 Cup Coffee Urn
Product Information
- Product Name: 110 Cup Coffee Urn
- Model: WCU110
- Unit Information:
- Power Supply: 120 volts – 1500 watts
- Dual heater system for brewing and keep warm at optimal
temperatures - Boil dry protection with auto reset
Product Usage Instructions
- Open the coffee urn by turning the lid to the “OPEN”
position. - Fill the tank with the desired amount of water, ensuring it
does not exceed the maximum level indicated (110 cups). - Add the appropriate amount of coffee grounds based on the
desired number of cups to be brewed. Refer to the brewing
instructions table below for guidance. - Close the coffee urn by turning the lid to the “CLOSE”
position. - Connect the power cord to a suitable power outlet.
- Switch on the coffee urn using the “ON” switch.
- Wait for the coffee to brew. The “READY” light will turn on
when the coffee is ready. - To keep the coffee warm, switch on the “KEEP WARM” function
using the respective switch. - When finished, switch off the coffee urn using the “OFF”
switch. - Unplug the power cord from the power outlet.
- Allow the coffee urn to cool down before cleaning or
storing.
Brewing Instructions
| Cups of Grounds | Total Cups Brewed |
|---|---|
| 8 | 110 |
| 7 | 90 |
| 6 | 70 |
| 5 | 50 |
| 3 1/2 | 30 |
Note: Adjust the amount of coffee grounds based on personal
preference for stronger or weaker coffee.
Brewing Instructions
Cups of Grounds = Total Cups Brewed
8
110
7
90
6
70
5
50
31/2
30
Unit Information
120 volts – 1500 watts
2
Dual heater system for brewing and keep warm at optimal
temperatures
Boil dry protection with auto reset
110 Cup Coffee Urn
WCU110
OPEN
CLOSE
4
3
1
7
5
MAX
MAX
110
110
90
90
8
70
70
50
50
MIN
MIN
30
30
17
7 6
16
ON
READY
OFF
9 15
10 11
12
036434
13
WCU110 Unit
Graphic By: Sandra A. Montysko
Revised June 6, 2018 Approved 6/7/18
14
Page 1 of 3
036624
Hex Nut (2 required)
032360
Spring Washer (2 required)
036652
Screw
036650
Spring Washer
036641
8.5″ Yellow/Green Lead
(2 required)
036642
7.75″ Red Lead
036624
Hex Nut
032360
WCU110
Internal Components
Spring Washer
036650
Spring Washer (2 required)
036652
Screw (2 required)
036646
Thermostat Dry
(on coffee heater)
036648
Rocker Switch
036643
7.75″ Blue Lead
036644
10″ Blue Lead
036651
Screw
032360
Spring Washer
012409
Crimp Connector
(2 required)
036652
Screw
036650
Spring Washer
036649
Screw
(2 required)
036650
Spring Washer
036647 (2 required)
036645
17.25″ Blue Lead
(with sleeve and bracket)
Thermostat Brew
(on Tank)
036640
Screw
036656
(2 required per clamp)
Keep Warm Heater (PTC) (no terminals)
036639
Cord Clamp
(2 required)
036653
Ready Light Assembly
(no terminals)
013731
Wire Tie
(2 required)
036624
Hex Nut
032360 (2 required)
Spring Washer
(2 required)
036658
Bracket
Page 2 of 3 Revised June 6, 2018
036655
7.75″ Red Lead (no terminals)
036654
8″ White Lead (no terminals)
Catalog/Model WCU110
Illustration# Part#
1
036429
2
036430
3
036431
4
036413
5
036432
6
036422
7
036415
8
036433
9
036417
10
036418
11
036419
12
036420
13
036635
14
036638
15
036636
16
036637
17
036659
314 Ella T. Grasso Ave. Torrington, CT 06790 Tele. 1-800-269-6640
Fax 860-496-9017 www.waringcommercialproducts.com
Description
Cover Coffee Basket Percolator Tube Water Gauge Cover Water Gauge Tube Water Guage Tube Collar Glass Tube Seal (2 required) Glass Tube Spigot Spigot Seal Spigot Nut Feet (4 required) Screw (3 required) Cord Tank Base Tank Skirt Tank (comes with coffee heater, handles and sight glass bracket)
Note: Use Thermal Grease with Thermostat (dry),
Thermostat (brew) and Keep Warm Heater.
Revised June 6, 2018 Page 3 of 3
Waring® Commercial
