Ease C4 canister vacuum cleaner
Installation Guide
www.electrolux.com/shop
www.electroluxshop.co.kr
https://shop.electrolux.com.au/
(for selected countries only)
Safety requirements and warning
This appliance can be used by children aged from 8 years and above and persons with reduced physical,sensory or mental capabilities or lack of experience and knowledge if the have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
WARNING: Turbo nozzles* have a rotating brush in which parts may become entrapped. Please use them with caution and only on intended surfaces. Please turn the vacuum cleaner off before removing entrapped parts or cleaning the brush. Certain models only.
Children should be supervised to ensure that they do not play with the appliance.
Cleaning and maintenance shall not be made by children without supervision.
Always disconnect the plug from the mains before cleaning or maintaining the appliance.
Never use the vacuum cleaner without its filters.
Caution
This appliance contains electrical connections.
- Never vacuum any liquid.
- Do not immerse in any liquid for cleaning.
- The hose should be checked regularly and must not be used if damaged.
The above can cause serious damage to the motor, which is not covered by the warranty.
This vacuum cleaner is for domestic use only.
Never use a vacuum cleaner
- Close to flammable gases, etc.
- On sharp objects.
- On hot or cold cinders, lit cigarette butts, etc.
- On fine dust, for instance, plaster, concrete, flour.
Power cord precautions
- Regularly check that the plug and cord are not damaged. Never use the vacuum cleaner if the cord is damaged.
- If the cord is damaged, it must be replaced only by an authorized Electrolux service center in order to avoid a hazard. Damage to the vacuum cleaner’s cord is not covered by the warranty.
- Never pull or lift the vacuum cleaner by the cord.
All servicing and repairs must be performed by an authorized Electrolux service center.
Store the vacuum cleaner in a dry place.
Consumer information
Electrolux declines all responsibility for all damages arising from any improper use of the appliance or in cases of tampering with the appliance. For more details of warranty and consumers’ contacts see the Warranty Booklet in the packaging. If you have any comments on the cleaner or the Operating Instructions manual please e-mail us at [email protected].
Sustainability policy
This product is designed with the environment in mind. All plastic parts are marked for recycling purposes.
For details see our website: www.electrolux.com.
The packaging material is chosen to be environmentally friendly and can be recycled.
Recycle the materials with the symbol
. Put the packaging in applicable containers to recycle it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances.
Do not dispose of appliances marked with the symbol
Ji with household waste. Return the product to your- local recycling facility or contact your municipal office.
The declared values on the energy label are measured according to the required measurement methods (EN60312-1).
| Problem | Solution |
| The vacuum cleaner does not start | • Check that the cable is connected to the mains. • Check that the plug and cable are not damaged. • Check for a blown fuse. |
| The cleaner shots | The cleaner might be overheated: disconnect it from the mains; check if the nozzle, tube, hose or filters are blocked. Let the cleaner cool down for 30 minutes before plugging it in again. If the cleaner still does not work, contact an authorized Electrolux service center. |
| Reduced suction capacity | • Check if the dust container is full or blocked. • Check if the nozzle, tube hose or filters are blocked. • Check if the dust container and filters are in place. Clean or replace the filter. If the hose is damaged it will be necessary to replace it. |
| Clearing the hose | Clear the hose by “squeezing” it. However, be careful in case the obstruction has been caused by glass or needles caught inside the hose. Note: The warranty does not cover any damage to the hose caused by cleaning it. |
| The vacuum cleaner is overheated | • Check if the dust container is full or blocked. Empty the dust container. • Clean or replace the filter. |
| Water has been sucked into the vacuum cleaner | It will be necessary to replace the motor at an authorized Electrolux service center. Damage to the motor caused by the penetration of water is not covered by the warranty |
| For any further problems, contact an authorized Electrolux service center. | |
