SAMSUNG Federal Communications Commission Instructions
Date: Jan.21, 2021
Federal Communications Commission
Office of Engineering and Technology Laboratory Division
7435 Oakland Mills Rd.
Columbia MD 21046
Attn: Office of Engineering and Technology
HAC Attestation – FCC ID: A3LSMA325M
To whom it may concern:
Samsung Electronics Co. Ltd., hereby declares that the MIF values detailed below are based on worst case
operating modes for all air interfaces for which the HAC rating is provided based on the current methodology for
determining MIF values.
Reference Test report Number(s): HCT-SR-2101-FC011
SPEAG test files
| Ul D | Communication System Name | MIF (dB) |
| 10021-DAC | GSM-FDD (TDMA, GMSK) | 3.63 |
| 10460-MA | UMTS-FDD (WCDMA,AMR) | -25.43 |
| 10170-CAE | LTE-FDD (SC-FDMA. 1 RB, 20 MHz, 16QAM) | -9.76 |
| 10182-CAE | LTE-FDD (SC-FDMA. 1 RB, 15 MHz, 16QAM) | -9.76 |
| 10176-CAG | LTE-FDD (SC-FDMA. 1 RB, 10 MHz, 16QAM) | -9.76 |
| 10173-CAG | LTE-TDD (SC-FDMA. 1 RB, 10 MHz, 16QAM) | -1.44 |
| 10061-CAB | IEEE 802.11b WiFi 2.4 GHz (DSSS. 11 Mbps) | -2.02 |
| 10077-CAB | IEEE 802.11g WiFi 2.4 GHz (DSSS/OFDM. 54 Mbps) | 0.12 |
| 10591-AAB | IEEE 802.11 n (HT Mixed. 20MHz. MCSO. 90pc duty cycle) | -5.59 |
| 10069-CAC | IEEE 802.11a/n WiFi 5 GHz (OFDM. 54 Mbps) | -3.15 |
| 10616-AAB | IEEE 802.11ac WiFi (40MHz, MCSO. 90pc duty cycle) | -5.57 |
| 10030-CAA | IEEE 802.15.1 Bluetooth (GFSK. DH1) | 1.02 |
Sincerely,
—————————————————-
Jenni Chun / General Manager
Samsung Electronics America, Inc.
Address: 19 Chapin Rd., Building D
Pine Brook, NJ 07058
Tel: 1-973-808-6375
