Smart Line®
Versaflow TWM 9000 Electromagnetic Flow Converter
MM 92 Modular Version
Model Selection Guide 36-MM-16-07 Issue 27
Section: 14
Effective Date: October 1, 2021
Model Selection Guide with Price Data
Honeywell Proprietary
Instructions
Select the desired key number. The arrow to the right marks the selection available.
Make the desired selections from Tables I through VII using the column below the proper arrow. A dot ( ) denotes availability.
| Table | I | II | III | IV | V | VI | VII | VIII | IX |
| MM92 | 4 | _ | _ | _ | _ _ | _ _ | _ | _ _ _ _ | _ _ _ |
List Price equals the sum of prices for all selections made.
| KEY NUMBER | Description | Selection | Availability | |
| MM92 | MM92 | ↓ | ||
| TABLE I | ||||
| Flow Sensor | Flow Converter | 4 | * | |
| TABLE II | ||||
| Type | TWM 9000 C TWM 9000 F TWM 9000 R TWM 9000 W | 4 H L N | * * c * | |
| TABLE III | ||||
| Power Supply | 12 – 24 V DC 24 V DC / AC 100 – 230 V AC | (12 – 24 V DC) (19 – 29 V) (85 – 250 V AC, 50/60 Hz) | 1 4 A | * * * |
| TABLE IV | ||||
| Hazardous Area Approvals | None – non Ex EEx zone 1 EEx zone 1 FM Class 1 DIV 2 CSA Class 1 DIV 2 | (terminal compartment “d” – C) (terminal compartment “e” – C, F) | 0 1 2 5 C | * r s q q |
| TABLE V | ||||
| Cable connection | 3 x 1/2″ NPT 3 x PF 1/2″ 3 x M20 x 1,5 Terminal Strip | 4 _ 5 _ 6 _ B _ | * * * a | |
| Operating manual/ Language | German English US French None None None | german operating language english US operating language french operating language german operating language english GB operating language french operating language | _ 1 _ 3 _ 4 _ 5 _ 6 _ 7 | * * * * * * |
| TABLE VI | ||||
| Custody transfer | Without Water, NMi OIML R49 – non EU ( C & F only )** Water, MI-001 – EU ( C, F & W only )** | 0 _ 1 _ 5 _ | * t u | |
| Process diagnostics | Standard Batch controlling – BC | _ 0 _ 4 | * * | |
| TABLE VII – Converter housing | ||||
| Converter Housing | Standard Stainless steel 1.4408 Aluminum, custody transfer: sealed Stainless steel 1.4408, custody transfer: sealed | 1 2 3 4 | * b v v | |
Housing Table
| Table VII | Standard | Stainless steel 1.4408 | |
| Converter | Table II | 1,3 | 2,4 |
| TWM 9000 C | 4 | ||
| TWM 9000 F | H | ||
| TWM 9000 R | L | ||
| TWM 9000 W | N |
The minimum value of orders acceptable for Honeywell is USD 500. Handling fee is the amount of the difference between USD 500 and the actual purchase price.
| TABLE VIII | |||||
| Selection | Availability | ||||
| No Selection | None | V _ _ _ | * | ||
| Communications | Module IO: CO act. + PO act./hc Module IO: CO act. + PO pas./hc Module IO: CO act. + PO pas./Na Module IO: CO pas. + PO act./hc Module IO: CO pas. + PO pas./hc Module IO: CO pas. + PO pas./Na Fieldbus IO: Foundation Fieldbus IO: RS485 Modbus | (CO-active+PO-active/high current) (CO-active+PO-passive/high cur.) (CO-active+PO-passive/Namur) (CO-passive+PO-active/high cur.) (CO-passive+PO-passive/high cur.) (CO-passive+PO-passive/Namur) | (See Note 1) (See Note 1) (See Note 1) (See Note 1) (See Note 1) (See Note 1) (See Note 1) (See Note 1) | _ 4 _ _ _ 6 _ _ _ 7 _ _ _ 8 _ _ _ B _ _ _ C _ _ _ E _ _ _ G _ _ | g h j k l m p p |
| 1st IO Module | No IO module Current Output – active Current Output – passive Pulse Output – active / high current Pulse Output – passive / high current Pulse Output – passive / Namur Control Input – active / high current Control Input – active / Namur Control Input – passive / high current | _ _ 8 _ _ _ A _ _ _ B _ _ _ C _ _ _ E _ _ _ F _ _ _ G _ _ _ H _ _ _ K _ | * * * * * * * * * | ||
| No IO module Current Output – active Current Output – passive Pulse Output – active / high current Pulse Output – passive / high current Pulse Output – passive / Namur Control Input – active / high current Control Input – active / Namur Control Input – passive / high current | (not for Profibus DP) (not for Profibus DP) (not for Profibus DP) (not for Profibus DP) (not for Profibus DP) (not for Profibus DP) (not for Profibus DP) (not for Profibus DP) (not for Profibus DP) | _ _ _8 _ _ _A _ _ _B _ _ _C _ _ _E _ _ _F _ _ _G _ _ _H _ _ _K | f f f f f f f f f | ||
| TABLE IX | |||||
| Reference Method | Standard Virtual reference | 0 _ _ 1 _ _ | * * | ||
| Tagplate | None 316 / 1.4401 tagplate (120 x 46 mm) 4 lines, 25 characters each line max. 316 / 1.4401 tagplate (67 x 25 mm) 4 lines, 25 characters each line max. | _ 0 _ _ 2 _ _ 3 _ | * d d | ||
| No Selection | _ _ 0 | * | |||
RESTRICTIONS
| Restriction Letter | Available only with | Not available with | ||
| Table | Selection | Table | Selection | |
| a | II | L | ||
| b | II | 4.H | ||
| c | V | B_ | ||
| d | II | H. L. N | ||
| f | VIII | _F_ _ | ||
| 9 | VIII | _ _88,_ _A8._ _AA. _ _A C, _ _ A.G. _ _ C 8. _ _CC,_ _CG._ _G8. _ _G G | ||
| h | VIII | _ _88._ _ A8._ _ AA. _ _A E. _ _ A.K. _ E 8. _ _ EE,_ _ E K._ _ K8. _ _K K | ||
| VIII | _ _88._ _A8._ _A A. _ _AF,_ _A.H,_ _F8, _ _FF._ _FH._ _H8. _ _HH | |||
| k | VIII | _ _88._ _138._ _ 13 B. _ _ BC,_ _13.G._ _C 8. _ _CC,_ _CG._ _G8. _ _G G | ||
| I | VIII | _ _88._ _138,_ _ BB. _ _B E, _ _ B.K. _ E 8. _ _E E,_ _ E K._ _ K8. _ _K K | ||
| m | VIII | _ _88._ _88._ _1313. –B F. _ _ EH. _ _ F 8. _ _FF,_ _FH._ _H8. _ _hi 11 | ||
| P | VIII | _ _88._ _A8._ _AA. _ _ AC,_ _ A.K._ _ C8. _ _CC,_ _CK._ _K8. _ _ K K | ||
| 9 | II | 4. | ||
| V | 4_.6_ _. _ | |||
| r | II | 4 | ||
| s | II | 4.H | ||
| t | II | 4. | ||
| VII | 3. | |||
| VIII | V488.V4C8 | |||
| u | II | 4. H. N | ||
| VII | 3. | |||
| VIII | V488.V4C8 | |||
| v | II | 4. H | ||
| VI | 1_5_ | |||
Note 1: Only the following combinations are available for the Communication, first I/O Module and second I/O module.
The minimum value of orders acceptable for Honeywell is USD 500. Handling fee is the amount of the difference between USD 500 and the actual purchase price.
