Aura V1 Interior Single 6pc Lighting Kit

Product Information: TM INTERIOR 6PC

The TM Interior 6PC is a lighting kit that enhances the interior
of your vehicle. The kit includes light strips, a control box,
Y-splitters, a handheld remote, extension wires, a cigarette
lighter power adapter, and a mounting kit. The light strips can be
controlled using the handheld remote which has different modes,
speed levels, and color selections. The kit is designed to work
with a 12-volt charging port and has a warning to ensure that it is
not connected to more than 10 amps. Additionally, it is recommended
to mount the LED bars or strips, control box, and wiring in areas
where they will not exceed 85 or 185.

Product Usage Instructions

Step 1: Connect the Light Strips to the Control Box

Decide where to locate the light strips and ensure wiring has
enough length for control box to be installed in desired location.
Connect all light strips to the control box with the included
extension cables. Be sure to follow the WARNING provided in the
manual to avoid early failure of the kit. Once connected, plug the
control box Cigarette Power Adapter into an available 12 volt
charging port.

Step 2: Secure the Control Box

Secure Control box in desired location with Velcro or zip ties.
Ensure the control box is safely and securely hidden from exposing
elements of moisture as it is not waterproof.

Step 3: Mount the LED Strip

Thoroughly clean the surface where you plan on mounting the LED
strip with rubbing / isopropyl alcohol. Tear off the 3M
Double-sided tape and firmly press the LED strip to the mounting
area and hold for 3 seconds. Then use the Zip-Ties to tie all
wiring away from all moving components.

Step 4: Select Desired Color or Pattern

Using the included 21Key E-Z Remote, select your desired color
or pattern. Keep the remote within 10m/33ft as much as possible
while using it.

Disclaimer

OPT7 Lighting is not liable for damages or personal injuries
while installing this product. The Installation Guide is intended
as assistance to reduce setup time. OPT7 Lighting assumes no
responsibility for improper installation. If you are unfamiliar
with your vehicle or inexperienced with aftermarket upgrades,
please seek professional assistance. OPT7 recommends installation
for safety and guidance. Modified installations or installation
recommendations not specified by OPT7 Lighting will void product
warranty.

TM

INTERIOR
6PC INSTALLATION GUIDE
MAIN COMPONENTS

LIGHT STRIPS

On AUTO Off

S+ M+

S-

M-

AURA CONTROL BOX

1

2

3

Y-SPLITTERS

HAND HELD REMOTE

EXTENSION WIRES

CIGARETTE LIGHTER POWER ADAPTER

MOUNTING KIT

INSTALLATION

STEP 1
Decide where to locate the light strips and ensure wiring has enough length for control box to be installed in desired location.

EXTENSION WIRE

Y SPLITTER

As shown below, connect all light strips to the control box with the included extension cables.

LIGHT STRIP

WARNING

1. Connecting to more than 10 AMP will override the kit and cause early failure, ensure it is 10AMPs or less!!
2. Please ensure that the LED bars or strips/control box/wiring all are mounted in areas where will not exceed 85 or 185.

Once connected, plug the control box Cigarette Power Adapter into an available 12 volt charging port.

12 VOLT CHARGING PORT

CIGARETTE POWER ADAPTER

INSTALLATION

STEP 2
Secure Control box in desired location with Velcro or zip ties.
* CONTROL BOX NOT WATERPROOF Ensure the control box is safely and securely hidden from exposing elements of moisture.

STEP 3
Thoroughly clean the surface where you plan on mounting the LED strip with rubbing / isopropyl alcohol. (This part is essential for a rm and long lasting placement.

A dirty surface will prevent the strip from attaching rmly.) Tear o the 3M Double-sided tape and rmly press the LED strip to the mounting area and hold for 3 seconds.Then use the ZIp-Ties to tie all wiring away from all moving components.

STEP 4
Using the included 21Key E-Z Remote, select your desired color or pattern. ( Note: When you use this product, keep it within 10m/33ft as much as possible )

Power 1 ON

Automatic Color Change 2

Power 3 OFF

Speed

4 9 Levels

Mode

5 3 Modes

Dimmer

6 9 Levels

Color Selection 7 9 Colors

SoundSYNC 8 3 Modes

1
On

2

3

AUTO Off

4

5

6

S+ M+

S-

M-

7

8

1

2

3

DISCLAIMER
OPT7 Lighting is not liable for damages or personal injuries while installing this product. The Installation Guide is intended as assistance to reduce setup time. OPT7 Lighting assumes no responsibility for improper installation. If you are unfamiliar with your vehicle or inexperienced with aftermarket upgrades, please seek professional assistance.
OPT7 recommends installation for safety and guidance. Modified installations or installation recommendations not specified by OPT7 Lighting will void product warranty.
