C.A 6131 Electrical Installation Tester
Product Information: C.A 6131 – C.A 6133 Electrical
Installation Testers
The C.A 6131 and C.A 6133 are low-voltage electrical
installation testers that are designed to test the safety of
electrical installations. They can be used to check new
installations before powering them up, inspect existing
installations, and troubleshoot any dysfunctions. The testers are
compliant with applicable standards and are ideal for use by
inspection organizations. The testers have the following
features:
- Earth measurement by stake and loop methods
- Continuity measurement at 0.2A
- Insulation testing
- RCD testing: current and trip time
- Automatic test sequences
- Storage of test results
- Android application for report generation
- Power supply by mains-rechargeable batteries, USB socket or
vehicle cigarette lighter - 600 V CAT III
- IP 54 protection rating
The testers come with accessories such as a carrying bag, neck
strap, mains cable, safety cables, crocodile clips, test probe,
batteries, user manual, quick startup guide, safety datasheet, and
test report with measurement report. The C.A 6133 also comes with a
USB power supply, razor-type USB power cable, and battery
information sheet.
Product Usage Instructions:
To use the electrical installation testers, follow these
steps:
- Connect the tester to the installation using the appropriate
cables and probes. - Select the type of test you want to perform from the menu.
- Follow the on-screen instructions to complete the test.
- Once the test is complete, the results will be stored in the
tester’s memory. - You can generate a report using the Android application or by
downloading the results to a computer. - The testers can be powered by mains-rechargeable batteries, USB
socket, or vehicle cigarette lighter. - The testers have a long battery life and can perform over 1,900
continuity measurements at 1 A (C.A 6131) or over 1,700 continuity
measurements at 1 A (C.A 6133). - The testers have a backlit LCD display that shows the
measurements and recorded results. - The testers have a magnetized casing for easy mounting and a
neck strap for hands-free use.
It is important to follow all safety guidelines and applicable
standards when using the electrical installation testers.
C.A 6131 – C.A 6133
Electrical installation testers
Test the electrical safety of your installations
Earth measurement by stake and loop methods Continuity measurement at 0.2A Insulation testing RCD testing: current and trip time Automatic test sequences Storage of test results ANDROID application for report generation Power supply by mains-rechargeable batteries, USB socket or vehicle cigarette lighter
600 V
CAT III
IP
54
Auto Script
ELECTRICAL INSTALLATION TESTERS
ERGONOMICS AND FUNCTIONS
Designed for checking safety on electrical installations, the C.A 6131 and C.A 6133 can be used to test a new installation before powering it up, check an existing installation, whether in operation or not, and to troubleshoot a dysfunction. For inspection organizations, these portable instruments are simple, effective and, above all, compliant with the applicable standards.
Terminal strip.
A specific 4-point socket for the MN73A current clamp (option).
A battery charger input. Measurement validation LED.
3 voltage inputs including one for the
remote-control probe.
Magnetized casing for magne-
LED showing voltage
Buzzer activation/deactivation. Cable compensation.
Activation of backlighting/ tic mounting. Bluetooth activation.
present on PE.
Data storage.
Neck strap for hands-free use.
Built-in stand for benchtop use..
Direct access to the measurements.
Backlit LCD Rereading/deletion of
display.
recorded measurements.
TEST button. Navigation keys.
Charging via universal USB connections!
Functions
0
+ COM
<2
0 SE H
RE-3P
A
TEST SITE
TEST SITE
Continuity
Earth
L
PE L
0
LOOP Ik UL 50V
HOLD A
TEST SITE
Loop
+ COM
M
M V 500V
TEST SITE
Insulation
L
PE L
mA
UL 50V
RCD
AC In
RCD
HOLD V
x1 mA
TEST SITE
Compliant with the IEC 61557-4 This function allows you to Loop measurement is perfor- The user selects the test The comprehensive RCD test
standard. If the buzzer is active, measure an earthy resistance med in Trip or No Trip mode. voltage and chooses the set of can be used with type A and
users are informed by a beep if using the stake method when On a TN or TT installation, loop alarm thresholds. A visual indi- AC RCDs. 3 types of test are
the measurement is below the the electrical installation to be impedance measurement can cation instantaneously shows available:
threshold, so they do not have tested is not powered up (new be used to size the protective whether the test is OK or not: – No Trip test,
to look at the screen.
installation, for example). It is systems for the installation if the measurement is higher – Trip test in pulse mode,
only available on the C.A 6133. (fuses or RCDs), particularly in than the threshold, the V LED – Trip test in ramp mode.
terms of breaking capacity. On lights up. If the measurement is
a TT installation, this measure- lower than the threshold, the X
ment serves to determine the LED lights up.
value of the earth resistance
without setting up any stakes
and without having to power
down the installation.
CHECK THE COMPLIANCE OF ELECTRICAL INSTALLATIONS WITH A SINGLE INSTRUMENT
Continuity Earth Neutral Phase
Loop
Insulation
Earth 3p
100 % 62 % 0 %
RCD
PASS/FAIL LED for viewing the results instantaneously.
3-pole cable for direct measurements on 2P+E sockets.
COMPLEMENTARY FUNCTIONS AVAILABLE ON THE C.A 6133
Automatic test sequence
Current measurement
Save time! The AUTO-RCD automatic test sequence performs the following operations: – the No-Trip test, the Trip test at 1 x In and the Trip test at 5 x In, – if necessary, the Trip test in ramp mode. A single press on the backup buttons saves all the tests performed. Another automatic test sequence is also available which performs the following tests, successively:
The MN73A clamp is recognized automatically when it is connected, as is the measurement calibre.
LOOP RCD INSULATION
Data storage
0 SE H
RE-3P
TEST SITE
The data storage function can be used to store your measurement results: up to 99 tests per site on up to 30 sites!
Bluetooth communication for Android IT-Report application
The ANDROID IT-Report application can be used to transfer the test results stored in the C.A 6133 onto a tablet or smartphone via Bluetooth. Test reports are then generated and sent automatically by email or simply stored for processing later on.
Technical Specifications
Continuity Range / Resolution / Accuracy
Resistance Range / Resolution / Accuracy
Insulation Test voltage
Range / Resolution / Accuracy Earth resistance – 3P method
Range Resolution Accuracy Measurement frequency Earth loop (Zs) measurement No Trip (12 mA) Range / Resolution / Accuracy Calculation of Ik With Trip (300 mA) Range / Resolution / Accuracy Calculation of Ik Fault loop (Zi) measurement Type of connection Range / Resolution / Accuracy Calculation of Ik RCD test Installation voltage Types and calibres
Trip time Trip current Fault voltage: Range / Resolution / Accuracy Automatic test sequences Voltage & Frequency Voltage: Range / Resolution / Accuracy Frequency: Range / Resolution / Accuracy Phase rotation Current
AUX sensor function (C.A 6131) AC+DC range: Range / Resolution / Accuracy DC range / Resolution / Accuracy
C.A 6131
C.A 6133
0.00 to 9.99 — Compensation of cables up to 5 ; I 200 mA / 0.01 / ± (2 % R* + 2 cts)
1 to 9,999 — 10.00 to 99.99 k / 1 — 10 / ± (1 % R + 5 cts)
250 V / 500 V
250 V / 500 V / 1 000 V 0.01 to 999.9 M / 10 k or 100 k / ± (3 % R + 3 cts)
–
0.50 to 99.99
100.0 to 999.9
1,000 to 2,000
–
0.01
0.1
1
–
±(2 % R + 10 cts)
±(2 % R + 5 cts)
±(2 % R + 5 cts)
–
128 Hz
1 to 19 — 20 to 39 — 40 to 2,000 / 1 / ± (2 cts) — ±(15 % R + 3 < cts) — ± (5 % R + 2 cts) 1 to 999 A
0.1 to 0.9 — 1.0 to 399.9 / 0.1 / ±(2 cts) — ±(5 % R + 2 cts) 1 to 9,999 A
Banana cables 300 mA measurement current: 0.1 to 0.9 — 1.0 to 399.9 / 0.1 / ± (2 cts) — ± (5% R + 2 cts)
1 to 9,999 A
90 to 450 V; 45 to 65 Hz
AC and A; 30 mA – 100 mA – 300 mA – 500 mA – 650 mA
0.5 x I N ; 1 x I N ; 5 x I N / 5.0 to 300 ms
30 mA: 0 .. +(7%R +3.3% I N + 2 mA)
1.0 to 25.0 V — 25.0 to 70.0 V / 0.1 V / ± (15% R + 3 cts) — ± (5% R + 2 cts)
No
RCD, Loop-RCD-Insulation
2.0 to 550.0 VAC 0.0 to 800.0 VDC / 0.1 V / ± (1%R+2cts)
–
30.0 to 999.9 Hz / 0.1 Hz / ±(0.1 % R + 1 ct) – Voltage > 2V
45 to 550 V — 45 to 65 Hz
Via clamp with voltage output using the voltage sensor function (AUX)
Via MN73A clamp with 2A calibre: 10.0 mA to 2,400 mA, 200 A calibre: 1.00 to 200 A
2.0 to 999.9 mV / 1.000 to 1.2000 V / 0.1 mV — 1 mV / ±(1 % R + 2 cts)
–
±(0.0 to 999.9 mV) — ±(1.000 to 2.000 V) / 0.1 mV — 1 mV / ±(1 % R + 2 cts)
–
Display Data storage Communication Software Power supply Battery life Dimensions / weight Environment Protection Standards / Electrical safety Compliance with IEC 61557
General Specifications
Custom 231-segment LCD with blue backlighting
–
30 sites x 99 tests
–
Bluetooth Class 1; range > 10m
–
Android IT-Report application
6 x LR 6 or AA batteries
6 NiMH mains-rechargeable batteries, charging < 6 hrs , USB or vehicle cigarette lighter
> 1,900 continuity measurements at 1
> 1,700 continuity measurements at 1
223 x 1 26 x 70 mm / 700 g approx.
Use: 0 to 40 °C / Storage: – 10 to 70 °C (RH 80%)
IP 54 (IEC 60 529) ; IK 04 (IEC 50102)
EMV: IEC 61326-1 ; IEC 61010-1 ; IEC 61010-2-030 ; IEC 61010-2-034, 600V CAT III, 300V CAT II on charger input
Parts 1, 2, 3, 4, 6, 7 and 10
Parts 1, 2, 3, 4, 5, 6, 7 and 10
State at delivery and references
Accessories
C.A 6131
P01146011
Low-voltage installation tester delivered in a cardboard
box containing:
– 1 carrying bag – 1 neck strap – 1 EURO mains 3-pole cable – 3 x 1.5m/4 mm safety cables (red/black/green), – 3 crocodile clips (red/black/green), – 1 black test probe, 6 x LR6 1.5V batteries, – 1 User’s manual on CD-ROM (5 languages), – 1 quick startup guide on paper, – 1 safety datasheet, – 1 test report with measurement report
C.A 6133
P01146013
Low-voltage installation tester delivered in a cardboard box containing:
– 1 carrying bag – 1 neck strap – 1 EURO mains 3-pole cable – 3 x 1.5m/4 mm safety cables (red/black/green), – 3 crocodile clips (red/black/green), – 1 black test probe, – 6 x NiMH batteries, – 1 x 2A USB power supply, – 1 razor-type USB power cable, – 1 User’s manual on CD-ROM (5 languages), – 1 quick startup guide on paper, – 1 safety datasheet, – 1 test report with measurement report – 1 battery information sheet
– Remote-control probe:
P01102157
– MN 73A 2A/200A bi-calibre current clamp with P01120439
4-point connectors (C.A 6133):
– MN 73 2A/200A bi-calibre current clamp with P01120421
banana connections (C.A 6131):
– Continuity rod
P01102084A
906 211 580 – FM – Ed.1 – 10/2018 – Non-contractual document. Please confirm specifications when ordering.
