BERNSTEIN ENK-SU1Z-iw IW Series Transmitter Model
Transmitter module
ELECTRICAL DATA
| Electrical data | ||
| Transmission frequency | 863 MHz – 870 MHz 902 MHz – 928 MHz | (configurable) |
| Printout | Proprietary | |
| Supply voltage internal | 3 V / 2 x Battery AAA (LR03) | |
MECHANICAL DATA
| Mechanical data | |
| Enclosure | PA66 + PA6, red |
| Cover | PA66 + PA6, black |
| Cover gasket | TPE |
| Actuator | POM |
| Sleeve | NBR-50 |
| Ambient air temperature | -5 °C … +55 °C |
| Type of protection | IP 65 acc. to IEC 529, EN 60529 |
| Function indication | 1 x LED, red / green |
STANDARD
| Standards |
| VdS 3448 (VdS-Directive) |
| EN 54-25 |
| ETSI EN 301489-1, ETSI EN 300220-1 |
EU CONFORMITY
| EU Conformity |
| acc. to directive 2011/65/EU (RoHS II) |
| acc. to directive 2014/53/EU (RED) |
| according to directive 2012/19/EU (EU-WEEE II) |
APPROVALS
| Approvals |
| Radio approval FCC ID: 2ABA6RT1 IC: 11535A-RT1 |
| FCC/IC Requirements: This device complies with Industry Canada licence-exempt RSS standard(s) and part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate the equipment. |
