SXA700 Wireless Audio Transmitter, Receiver

Wireless Audio Transmitter/Receiver

SXA700 USER MANUAL

Table of Contents

1. Introduction
2. Specifications
3. Package Contents
4. Transmitter Mode
5. Receiver Mode

1. Introduction

The Wireless Audio Transmitter/Receiver (SXA700) is a versatile
adapter that can be used with a variety of devices including
computers, laptops, home stereo systems, headphones, smartphones,
Mp3 players, CD players, and more. The adapter comes with a 3.5mm
cable and a 3.5mm to 2RCA cable for easy connectivity.

2. Specifications

The specifications for the Wireless Audio Transmitter/Receiver
(SXA700) are as follows:

• Power Input: DC 5V/500mA
• Bluetooth Version: 5.0
• Bluetooth Protocol: A2DP/AVRCP
• Transmission Distance: Up to 10m
• Frequency Response: 20Hz-20KHz

3. Package Contents

Please check the package before attempting to use the unit. Make
sure the following items are all contained in the package:

• Wireless Audio Transmitter/Receiver (SXA700)
• Micro USB Power Cable
• RCA Cable
• 3.5mm Aux Cable
• 230V USB charger
• User Manual

4. Transmitter Mode

To use the Wireless Audio Transmitter/Receiver (SXA700) in
transmitter mode, follow these steps:

1. Connect the 3.5mm or RCA cable to the audio output of your
   device.
2. Connect the other end of the cable to the audio input on the
   Wireless Audio Transmitter/Receiver (SXA700).
3. Turn on the Wireless Audio Transmitter/Receiver (SXA700) by
   pressing and holding the power button for 3 seconds.
4. The LED light will flash blue, indicating that the device is in
   pairing mode.
5. Enable Bluetooth on your receiving device and search for
   available devices.
6. Select “SXA700” from the list of available devices.
7. Once connected, the LED light will turn solid blue.

5. Receiver Mode

To use the Wireless Audio Transmitter/Receiver (SXA700) in
receiver mode, follow these steps:

1. Connect the 3.5mm or RCA cable to the audio input of your
   device.
2. Connect the other end of the cable to the audio output on the
   Wireless Audio Transmitter/Receiver (SXA700).
3. Turn on the Wireless Audio Transmitter/Receiver (SXA700) by
   pressing and holding the power button for 3 seconds.
4. The LED light will flash blue, indicating that the device is in
   pairing mode.
5. Enable Bluetooth on your transmitting device and search for
   available devices.
6. Select “SXA700” from the list of available devices.
7. Once connected, the LED light will turn solid blue.

Wireless Audio Transmitter/Receiver
SXA700 USER MANUAL
Trådløs Audio Transmitter/Receiver
SXA700 BRUGSANVISNING

Table of Contents
1. Introduction 2. Specifications 3. Package Contents 4. Transmitter Mode 5. Receiver Mode

1. Introduction
This extremely portable, lightweight wireless audio transmitter & receiver is an ideal wireless audio solution for a wide range of situations and uses. Receiver mode: wirelessly streams audio from your Bluetoothenabled phone, tablet, or computer to your wired stereo, speakers, headphones or even the speakers in your car by using the AUX-in. Because of the inbuilt battery, you can stream audio up to 6 hours without power. Transmitter mode: wirelessly streams audio from your non-Bluetooth TV, home stereo system, or CD player to your Bluetooth headphones or speakers. Switch between transmitter and receiver modes with the simple flick of a switch. Effortlessly connect using advanced Bluetooth technology and 3.5mm audio cable (included).

Broad Compatibility: With the included 3.5mm cable and 3.5mm to 2RCA cable, this Receiver/Transmitter adapter can widely be used on your computer, laptop, home stereo system, headphone, smartphone, Mp3 player, CD player, etc.
2. Specifications
Technologies: BT4.2, A2DP, AVRCP (receiver mode only) Operation Range: Up to 10m / 33ft (without any blocking objects) Charging Time: 2 hours Continuous Use Time: 6 hours (Receiver Mode) / 5 hours (Transmitter Mode) Battery Type: Li-Polymer (200mAh) Dimensions: 44 × 44 × 12mm Weight: 18g

Indholdsfortegnelse
1. Introduktion 2. Specifikationer 3. Indhold 4. Transmitter Mode 5. Receiver Mode

1. Introduktion
Denne lette og transportable trådløse audio transmitter/receiver er ideel til mange situationer. Receiver mode: streamer trådløst lyd fra din Bluetooth-aktiverede mobil, tablet eller computer til dine højttalere, høretelefoner eller højttalerne i din bil gennem AUX-in. Grundet det indbyggede batteri kan du streame lyd i op til 6 timer uden strømforsyning. Transmitter mode: streamer trådløst lyd fra dit TV, home stereo system eller CD afspiller, som ikke har Bluetooth, til dine Bluetooth høretelefoner eller højttalere. Du kan nemt skifte mellem transmitter og receiver mode på den lille knap. Opret nemt forbindelse ved hjælp af avanceret Bluetoothteknologi og 3,5 mm lydkabel (medfølger). Bred kompatibilitet: Med det inkluderede 3.5mm kabel og 2RCA kabel, kan du bruge denne transmitter/receiver på din computer, home stereo system, høretelefoner, Mp3 afspiller og meget mere.

2. Specifikationer
Teknologi: BT4.2, A2DP, AVRCP (kun receiver mode) Rækkevidde: op til 10m / 33ft (uden blokerende objekter) Opladningstid: 2 timer Afspilningstid: 6 timer (Receiver Mode) / 5 timer (Transmitter Mode) Batteritype: Li-Polymer (200mAh) Dimensioner: 44 × 44 × 12mm Vægt: 18g

3. Package Contents

Please check the package before attempting to use the unit. Make sure the following items are all contained in the package:

1) Wireless Audio Transmitter/Receiver 2) Micro USB Power Cable 3) RCA Cable 4) 3.5mm Aux Cable 5) 230V USB charger 6) User Manual

1 pcs. 1 pcs. 1 pcs. 1 pcs. 1 pcs. 1 pcs.

3. Indhold

Kontrollér venligst pakken før brug. Sørg for at følgende enheder er i pakken:

1) Trådløs Audio Transmitter/Receiver 2) Micro USB strømkabel 3) RCA kabel 4) 3.5mm AUX kabel 5) 230V USB lader 6) Brugsanvisning

1 stk. 1 stk. 1 stk. 1 stk. 1 stk. 1 stk.

Sinox Europe A/S Troensevej 11
DK-9220 Aalborg www.sinox-europe.com
[email protected]
Sinox Europe A/S Troensevej 11
DK-9220 Aalborg www.sinox-europe.com
[email protected]
