5301002 ABS 2 Way Cable Grommet Solar Module Holding Spoiler
Product Information
Product Name: ES-ABD 21/22
Color: White / Black
Language: English (EN)
Model Numbers: 5301002, 5302002
Dimensions (mm): X1
Product Usage Instructions
- Prepare for assembly:
- Ensure that the surfaces are clean, dry, and free from grease,
oil, wax, and dust. - Gather the necessary tools (not included) for assembly.
- Remove the bolt head from the casing.
- Follow the remaining assembly steps as provided in the full
user manual.
Please refer to the complete user manual for detailed
instructions and additional information.
ES-ABD 21/22
White / Black
EN
5301002 5302002
ES-ABD 21/22
enjoysolar®ABS double Cable Entry Gland
Dimension(mm)
X1
Prepare for assembly
Tools (not incl.)
Sikaflex® – 554 construction adhesive
Tipps:
Surfaces must be clean, dry and free from all traces of grease, oil, wax and dust.
Copyright© 2022 SolarV GmbH All rights reserved.
Assembly instructions
1 Remove the bolt head from casing
Copyright© 2022 SolarV GmbH All rights reserved.
2 Apply the Sikaflex®-554 construction adhesive
Copyright© 2022 SolarV GmbH All rights reserved.
3 Draw the cables through then glue with Sikaflex554 construction adhesive Copyright© 2022 SolarV GmbH All rights reserved.
4 Done!
Copyright© 2022 SolarV GmbH All rights reserved.
