Oz Indoor Suspended Lamp
Owner’s Manual
Oz Indoor Suspended Lamp
rev. 21-02-2023
General info
DECORATIVO – Hanging
Indoor suspended lamp with integrated LED sources and diffuse light emission
| Ean | 8.0217E+12 |
| Item | OZ SP D80 ON-OFF OTTONE |
| Installation | Suspension |
| Guarantee | 5 years |
| Gross weight | 4.74 kg |
| Volume | 0.060692 m3 |
Technical info
| Net weight | 1.92 kg |
| Insulation class | I |
| Protection index | IP20 |
| Compliance | CE |
| Operating temperature | 0° ~ +40 °C |
| Dimmer | Non-dimmable, On-Off |
| Power output | 220-240 V AC 50/60 Hz In-built, included |
| Power supply | Replaceable (by qualified operators only), electronic |
Source info
| Integrated source | Integrated LED module |
| Repleaceable source | No |
| Power | LED 55 W |
| Emission | Diffuse |
| Max consuption | max 55 W |
| Features LED | LED SMD |
| CCT | 3000 K |
| Duration LED (t. 25°c) | 30000 h |
| CRI | > 80 |
| Light beam | 120° |
| Light beam flux | 6100 lm |
| Useful light flux | 2510 lm |
| Photobiological risk | 1 |
| Standby power | < 0.50 W |
IDEAL LUX s.r.l.
Via Taglio Destro, 32, 30035 Mirano (Venezia)
Tel +39 041 5790500
Fax +39 041 8872349
E-mail [email protected]
www.ideal-lux.com
