EVBUM2818/D 100 W TYPE-C PD3.0 PPS Charger Solution Evaluation Board

Product Information

Product Name: 100 W TYPE-C PD3.0 / PPS Charger
Solution Evaluation Board
User Manual: www.onsemi.com
Model Number: EVBUM2818/D
Specifications:
– onsemi’s Device: NCP1623ASNT1G
– Application: Smart phone, PAD
– NCP1343AMDCDBD1R2G and NB adapter
– NCP4307FASNT1G supporting FUSB15101 PD3.0/PPS protocol
– FCMT250N65S3, FCMT199N60/FDMS86180, NTTFS4C02NTAG
– Input Voltage: 90 Vac to 264 Vac
– Output Power: 100 W
– Topology: VSFF PFC Flyback
– I/O Isolation: Isolated (3 kV)
– Output Voltage: 5 V, 9 V, 12 V, 15 V, 20 V
– Nominal Current: 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20
V / 5 A
– Max Current: 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V /
5 A
– PD Output Specification: 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V /
3 A, 20 V / 5 A
– PPS Output Specification: 3 V – 21 V, 5 A
– Avg. Efficiency: 92.3% & 92.9% @ 20 V 3.25 A, 115 & 230
Vac
– Ripple: N/A (not specified in the text)
– Standby Power: N/A (not specified in the text)
– Power Density: N/A (not specified in the text)
– Protection: N/A (not specified in the text)
– PCBA Size: N/A (not specified in the text)

Product Usage Instructions

This evaluation board user’s manual provides instructions for
using the 100 W TYPE-C PD3.0 / PPS Charger Solution Evaluation
Board. The board is designed for smart phone, PAD, and NB adapter
applications that support PD3.0/PPS protocol and require isolation
from the AC mains, while emphasizing low cost, high efficiency, and
low standby power consumption.

To use the evaluation board, follow these steps:

Ensure that the input voltage is within the range of 90 Vac to
264 Vac.
Connect the appropriate load device (smart phone, PAD, or NB
adapter) to the output of the evaluation board.
Set the desired output voltage by selecting one of the
available options: 5 V, 9 V, 12 V, 15 V, or 20 V.
For PD output specification, choose the desired current rating
based on the requirements of the connected device: 5 V / 3 A, 9 V /
3 A, 12 V / 3 A, 15 V / 3 A, or 20 V / 5 A.
For PPS output specification, set the desired voltage within
the range of 3 V to 21 V and ensure a current rating of 5 A.
Refer to the user’s manual for any additional information on
protection features, PCBA size, power density, ripple, standby
power, and average efficiency.

For more detailed information and technical specifications,
please refer to the user’s manual available at www.onsemi.com.

View Fullscreen

EVAL BOARD USER’S MANUAL www.onsemi.com
100 W TYPE-C PD3.0 / PPS Charger Solution Evaluation Board User’s Manual
EVBUM2818/D

SPECIFICATION

onsemi’s Device

Application

NCP1623ASNT1G

Smart phone, PAD

NCP1343AMDCDBD1R2G and NB adapter

NCP4307FASNT1G

supporting

FUSB15101

PD3.0/PPS protocol

FCMT250N65S3

FCMT199N60/FDMS86180

NTTFS4C02NTAG

Input Voltage 90 Vac to 264 Vac

Output Power 100 W

Topology VSFF PFC Flyback

I/O Isolation Isolated (3 kV)

Output Voltage Nominal Current
Max Current

PD Output Specification 5 V, 9 V, 12 V, 15 V, 20 V 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V / 5 A 5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V / 5 A

PPS Output Specification 3 V – 21 V 5 A 5 A

Avg. Efficiency
Ripple
Standby Power
Power Density
Protection
PCBA Size
CIRCUIT DESCRIPTION This evaluation board user’s manual describes a 100 W,
Type C interface, universal AC input, constant voltage power supply intended for smart phone, PAD and NB adaptor supporting PD3.0/PPS protocol, where isolation from the AC mains is required, and low cost, high efficiency, and low standby power are essential.
The featured power supply is a simple QR flyback topology utilizing onsemi’s NCP1623 VSFF PFC controller with 2 stage level, NCP1343 Multi-mode HF PWM controller with transient peak excursion power, NCP4307 synchronous rectified controller, onsemi’s FCMT199N60/ FCMT250N65/FDMS86180/NTTFS4C02 MOSFET. This evaluation board user’s manual provides the complete circuit schematic details, PCB and BOM for 100 W Type C Interface PD3.0 Power adapter solution which supports PD output (5 V / 3 A, 9 V / 3 A, 12 V / 3 A, 15 V / 3 A, 20 V / 5 A).
This design combined with onsemi’s FUSB15101 PD3.0/PPS protocol controller to provide PD3.0 and PPS

92.3% & 92.9% @ 20 V 3.25 A, 115 & 230 Vac
<60 mV
<50 mW @ 5 V & 230 Vac (No cable plug in)
1.46 W/cm3
Adaptive UVP, OVP, OVP, SCP, OTP
60 mm x 60 mm x 19 mm
functions. This design also proposes a dual auxiliary power supply to supply PWM controller, the PWM controller is supplied by high voltage auxiliary voltage at low output voltage and supplied by low voltage auxiliary voltage at high output voltage.
NCP1623 is next generation of NCP1622 PFC controller and compatible with NCP1622, it provides two stage level output and greatly improves the efficiency at low line. NCP1343 has same die as NCP1342, blank IC can be trimmed for NCP1342 or NCP1343, so it should have same reliability as NCP1342. NCP1343 provides a PEM mode with CCM operation and allows to use smaller capacitance for bulk CAP and minimize transformer value for transformer, it will save more size and cost than NCP1342 in a PFC plus PWM applications.
This design also uses NCP4307 synchronous rectified controller which eliminated external Vcc circuit at low output, it is also configured on high side or low side.

January, 2022 – Rev. 0

Publication Order Number: EVBUM2818/D

EVBUM2818/D

KEY FEATURES & PERFORMANCES

· AC input from 90 V to 264 V · VSFF CRM PFC with 2 stage output voltage, 250 V at LL
and 390 V at HL
· HF CCM/CRM PWM with 2x PEM supports more power
transition without PFC working and 68uF PFC capacitor
· High Frequency Operation up to avg. 190 kHz at 264 Vac
& full load and easy to be changed to GaN solution
· Quite skip and Flyback DCM operation with frequency
foldback at no load & light load
· Output voltage 3.3 V – 21 V · Max Output power: 100 W

· Support PD3.0, PPS, BC1.2 etc. · Ripple & Noise: <60 mV · AVG efficiency: 92% at 115 Vac & 230 Vac · Full load efficiency: 92.3% & 92.9% at 115 Vac &
230 Vac and 20 V 3.25 A
· Output precise OVP · Output OCP, SCP · Open loop protection · Small size with compact design · PCBA size: 60 mm x 60 mm x 19 mm

BOARD PHOTOS

Figure 1. Profile of 100 W TYPE-C PD Adapter Solution

Figure 2. PFC Side View 1 of Demoboard

Figure 3. PWM Side View 1 of Demoboard

www.onsemi.com 2

PFC: 2 stage output 390 V above 163 Vac 250 V under 146 Vac

EVBUM2818/D
CIRCUIT SCHEMATIC (PFC)
Figure 4. Circuit Schematic (PFC) www.onsemi.com 3

EVBUM2818/D
CIRCUIT SCHEMATIC (PWM & PROTOCOL)
Figure 5. Circuit Schematic (PWM & Protocol) www.onsemi.com 4

EVBUM2818/D
PCB

Figure 6. (Top), Top View of PCB

Figure 7. (Bottom), Bottom View of PCB

www.onsemi.com 5

EVBUM2818/D
PFC INDUCTOR SPECIFICATION
Figure 8. PFC Inductor Specification www.onsemi.com 6

EVBUM2818/D
TRANSFORMER SPECIFICATION
Figure 9. Transformer Specification www.onsemi.com 7

EVBUM2818/D
STANDBY POWER AT 5 V OUTPUT (CABLE UNPLUG) @ 90 Vac TO 264 Vac INPUT
(Test condition: all efficiency is tested at board end)
Figure 10. COC V5 TIER2 SPECIFICATION AND AVERAGE/LIGHT LOAD EFFICIENCY
(Test condition: all efficiency is tested at board end)

Figure 11. Avg Efficiency vs. COC V5 Tier2

Figure 12. 10% Efficiency vs. COC V5 Tier2

www.onsemi.com 8

EVBUM2818/D
EFFICIENCY VS. OUTPUT LOAD CURVES
(Test condition: all efficiency is tested at board end)

Figure 13. PD_5V Output

Figure 14. PD_9V Output

Figure 15. PD_12V Output

Figure 16. PD_15V Output

Figure 17. PD_20V Output
www.onsemi.com 9

EVBUM2818/D
PFC VALLEY SWITCHING

Figure 18. 115 Vac & 20 V 5 A (CH1: Vin-rect, CH2: Vds-pfc, CH3: Vcs_pfc)

Figure 19. 230 Vac & 20 V 5 A (CH1: Vin-rect, CH2: Vds-pfc)

INPUT CURRENT AT LL AND HL

Figure 20. 90 Vac & 20 V 5 A (CH1: Vin-rect, CH3: Iin)

Figure 21. 64 Vac & 20 V 5 A (CH1: Vin-rect, CH3: Iin)

PFC OPERATION WAVEFORM AT LL AND HL

Figure 22. 90 Vac & 20 V 5 A
(CH1: Vin-rect, CH2: Vds-pfc, CH3: Vcs-pfc, CH4: Vcc-pfc)

Figure 23. 264 Vac & 20 V 5 A
(CH1: Vin-rect, CH2: Vds-pfc, CH3: Vcs-pfc, CH4: Vcc-pfc)

www.onsemi.com 10

EVBUM2818/D
PFC LL TO HL AND HL TO LL CHANGE

Figure 24. 115 Vac to 230 Vac at 20 V 5 A
(CH1: Vin-rect, CH2: Vds-pfc, CH3: Vcs-pfc, CH4: Vcc-pfc)

Figure 25. 230 Vac to 115 Vac at 20 V 5 A
(CH1: Vin-rect, CH2: Vds-pfc, CH3: Vcs-pfc, CH4: Vcc-pfc)

PD VOLTAGE CHANGE

Figure 26. 115 Vac, No Load (CH1: Vds, CH4: Vo)

Figure 27. 115 Vac, 3 A Load (CH1: Vds, CH4: Vo)

PRIMARY AND SEC. FET STRESS AT 264 Vac & 20 V 5 A

Figure 28. (CH1: Vds, CH4: Vds-sec)
www.onsemi.com 11

EVBUM2818/D
SYN. DRIVE DURING LOAD TRANSITION AT 264 V

Figure 29. 264 Vac & 15 V, 0 to 3 A (CH3: Vds-sec, CH4: Vsyn-drv)

Figure 30. 264 Vac & 15 V, 3 A to 0 (CH3: Vds-sec, CH4: Vsyn-drv)

OUTPUT RIPPLE @ 90 Vac INPUT

Figure 31. 5 V 3 A Output (CH4: Vo)

Figure 32. 9 V 3 A Output (CH4: Vo)

Figure 33. 15 V 3 A Output (CH4: Vo)

Figure 34. 20 V 5 A Output (CH4: Vo)

www.onsemi.com 12

EVBUM2818/D
RIPPLE AT 90 Vac & 20 V 2.5 A (BEFORE PFC OPERATION)

Figure 35. 20 V Output (CH4: Vo) PWM OPERATION FREQUENCY AT FULL LOAD

Figure 36. 90 Vac and 20 V 5 A (CH1: Vds, CH3: Vsyn-drv)

Figure 37. 264 Vac and 20 V 5 A (CH1: Vds, CH3: Vsyn-drv)

www.onsemi.com 13

EVBUM2818/D
NCP1343 TRANSITION LOAD FROM 0 – 5 A AT 90 Vac & 20 V

Figure 38. (CH1: Vds_pwm, CH: Vcs_pwm, CH3: Vcc_pfc, CH4: Vsyn_drv)

Figure 39. (CH1: Vds_pwm, CH: Vcs_pwm, CH3: Vcc_pfc, CH4: Vsyn_drv)

Figure 40.

Figure 41.

PRI. & SEC. Vds AND SYNCHRONOUS DRIVE WAVEFORM

Figure 42. 90 Vac (CH1: Vds_sec, CH2: Vdrv)

Figure 43. 115 Vac (CH1: Vds_sec, CH2: Vdrv)

www.onsemi.com 14

EVBUM2818/D
SHORT CIRCUIT PROTECTION AND Tovld, Tauto-recovery TIME

Figure 44. (CH1: Vds-pwm, CH3: Vsec-ds, CH4: Vo)

Figure 45. (CH1: Vds-pwm, CH3: Vsec-ds, CH4: Vo)

PRIMARY AND SEC. FET STRESS DURING SCP

Figure 46. SCP at 264 Vac Input, 20 V 3.25 A Output (CH1: Vds_pwm, CH2: Vcs_pwm, CH3: Vds_sec, CH4: Vsyn_drv)

Figure 47. Startup at 264 Vac Input, 5 V 3 A Output (CH1: Vds_pwm, CH2: Vcs_pwm, CH3: Vds_sec,
CH4: Vsyn_drv)

OVP & X2 DISCHARGE TEST

Figure 48. OVP (Open Loop) at 115 Vac Input, 20 V Output
(CH1:Vds_pwm, CH2:Vcs_pwm, CH4: Vo)

Figure 49. Plug Out AC at 264 Vac Input, 20 V & No Load
(CH1: Vac, CH3: Vccl)

www.onsemi.com 15

Table 1. Input 90 Vac

EVBUM2818/D
THERMAL IMAGE @ 20 V 3.25 A OUTPUT

PFC Side

PWM Side

115 Vac

230 Vac 264 Vac

www.onsemi.com 16

EMI Test at 230 Vac & Full Load

EVBUM2818/D
EMI

Figure 50. Line

Figure 51. Neutral
www.onsemi.com 17

EMI Test at 115 Vac & Full Load

EVBUM2818/D

Figure 52. Line

Figure 53. Neutral
www.onsemi.com 18

EVBUM2818/D
BOM

Table 2. BOM

Item Qty Reference

C45

C44

C37

C1, C5

Type NMOSFET Ceramic Capacitor Ceramic Capacitor Ceramic Capacitor Film Capacitor

C9, C33 Ceramic Capacitor

Ceramic Capacitor

3 C26, C31, Ceramic Capacitor

C47

C52

Ceramic Capacitor

10 1

C12

Ceramic Capacitor

11 4

C39,

Ceramic Capacitor

C49-50, C70

12 1

C27

Ceramic Capacitor

13 1

C35

Ceramic Capacitor

14 1

C36

Ceramic Capacitor

15 1

C24

Ceramic Capacitor

16 1

C25

X2 Capacitor

17 1

C34

Ceramic Capacitor

18 1

C41

Ceramic Capacitor

19 2 C38, C69 Ceramic Capacitor

20 1

Ceramic Capacitor

21 1

C40

Ceramic Capacitor

22 4 C2, C4, C29, Ceramic Capacitor C43

23 1

Ceramic Capacitor

24 1

C10

Ceramic Capacitor

Part Name BSS123LT1G
Std /885012206120 /885012206073 ECWFD2W684Q
/885012206077 /885012206083 C3216X7T2W104K

MFR SOT23
603 603 603 THT, 10 mm, 13 mm x 6 mm x 12 mm 603 603 1206

/885012106018

603

/885012006085

603

/885012206076

603

C2012X7R1E106K

805

/885012206085

603

/885012106018

603

/885012206079

603

/890324024002

THT, 12.5 mm, 15 mm x 7 mm x 12 mm

/885012006053

603

/885012206091

603

/885012206083

603

Std

603

/885012206092

603

C1608X5R1E475K080AC

603

C3216C0G2J471J CD45-B2GA471K-NKA

1206 Lead type

Value onsemi
std Wurth Wurth Panasonic
Wurth Wurth TDK
Wurth Wurth Wurth
TDK Wurth Wurth Wurth Wurth
Wurth Wurth Wurth
Std Wurth TDK
TDK TDK

25 1

C68

Ceramic Capacitor

std

26 1

C20

Ceramic Capacitor

C2012X7S2A105K

27 1

C42

Ceramic Capacitor

Std

28 2

D2, D4

Bridge rectifier

Z4GP40MH

29 1

Rectifier

S3J

30 1

DNR

Varistor

820573011

31 1

D22

Switching diode

BAS21HT1G

32 1

Switching diode

BAS21HT1G

33 2 D16, D24

Switching diode

BAT54HT1G

34 1

D20

Switching diode

NSD350HT1G

35 1

General rectifier

36 2

D12-13

General rectifier

37 4 D8, D17-18, Switching diode D23

4007 4007 BAS21HT1G

38 1

FB2

39 1

FB1

Ferrite bead Ferrite bead

742792511 PZ3225D601-3R0TFONL

40 1

Common filter

Custom

41 1

42 1

Common filter Fuse

Custom 20T-016H

603 805 603 Z4PAK SMC TH SOD323 SOD323 SOD323 SOD323 SOD123FL SOD123FL SOD323
1812 1210 TH type TH type Axial lead

Wurth TDK Wurth ZOWIE onsemi Wurth onsemi onsemi onsemi onsemi std std onsemi
Wurth Shunlord Customed Customed Hollyfuse

Package 0.2 A, 100 V
0.1 mF 0.1 mF, 100 V
0.22 mF 0.68 mF, 450 V
100 pF 102
104, 450 V
2.2 mF, 16 V 1 nF, 100 V 1 mF, 25 V
10 mF, 25 V 2.2 mF 2.2 mF 220 pF 224, X2
22 pF 22 nF 330 pF 36 pF 33nF 4.7 mF, 25 V
470 pF, 630 V 470 pF, Y1
nc nc nc 4 A, 1000 V 3 A, 600 V 10D471K 0.2 A, 250 V 0.2 A, 250 V 0.2 A, 30 V 0.2 A, 350 V 0.8 A, 600 V 0.8 A, 600 V 0.2 A, 250 V
120 W @ 100 M, 3 A 600 W @ 100 M, 3 A
30 mH 18 mH 3.15 A, 250 Vac

Description NMOSFET Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 100 V, 10% Capacitor, Ceramic, 25 V, 10% Film capacitor
Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, SMD, 5%
Capacitor, Ceramic, 16 V, 10% Capacitor, Ceramic, SMD, 5% Capacitor, Ceramic, 25 V, 10%
Capacitor, Ceramic, 25 V, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 16 V, 10% Capacitor, Ceramic, 50 V, 10% X2 capacitor, Safety standard approved, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 25 V, 10%
Capacitor, Ceramic, Chip, 5% HV Ceramic Capacitor, safety standard approved, 10% Capacitor, Ceramic, 50 V, 10% Capacitor, Ceramic, 100 V, 10% Capacitor, Ceramic, 50 V, 10% Bridge Rectifier, 1000 V, 4 A General Rectifier Varistor, 10D471K Switching diode, SMD Switching diode, SMD Switching diode, SMD Switching diode, SMD General Rectifier, 0.8 A, 600 V General Rectifier, 0.8 A, 600 V Switching diode, SMD
120 W @ 100 MHz 600 W @ 100 MHz T type, 8*4*3 NiZn core CM Filter, T14*8*7 MnZn core Micro Fuse, 1.6 A/250 V

www.onsemi.com 19

EVBUM2818/D

Table 2. BOM (continued)

Item Qty Reference

Type

43 1

NPN Transistor

44 1

Q13

PNP Transistor

45 1

Ultrafast Rectifier

46 1

PFC controller

Part Name MMBT3904LT1G MMBT3906LT1G MURD550PFG NCP1623ASNT1G

47 1

48 1 49 1
50 1 51 2

U1 NTC1
NTC2-3 U4, U11

Syn. rectified controller
PWM controller
NTC

NCP4307FASNT1G
NCP1343AMDCDBD1R2G SDNT1608X104J4250HTF

NTC Optical coupler

SDNT1608X104J4250HTF FODM1009

52 1

Toroidal Line Choke

7447021

53 1

SMD Inductor

54 1

R11

Resistor

55 2 R48, R57

Resistor

56 1

R61

Resistor

57 3 R13, R32, R49

Resistor

58 1

R21

Resistor

59 4 R23, R38, R46, R66

Resistor

60 3 R3, R34, R36

Resistor

61 1

Resistor

62 1

R60

Resistor

63 1

R33

Resistor

64 1

R65

Resistor

65 3 R39, R52, R56

Resistor

66 1

Resistor

67 2 R27, R53

Resistor

68 1

R43

Resistor

69 1

R63

Resistor

70 1

R16

Resistor

71 1

R20

Resistor

72 2 R26, R28

Resistor

73 1

R30

Resistor

74 2 R47, R54

Resistor

75 1

R28

Resistor

76 1

R22

Resistor

77 1 78 2 79 2

R29 R50-51
R4-5

Resistor Resistor Resistor

80 1 81 2

R40 R1-2

Resistor Resistor

82 2

R7, R58

Resistor

83 2 R31, R35

Resistor

84 1 85 2

R12 R41-42

Resistor Resistor

86 1

R45

Resistor

MCL1608S4R7MT Std Std Std Std
Std Std
Std Std Std Std Std Std
Std Std Std Std Std Std Std Std Std Std Std Std ERJ8BQFR24V ERJ8BQFR56V std Std Std Std Std Std Std

MFR SOT23 SOT23 DPAK TSOP6
TSOP6
SO9 603
603 LSOP4
TH type
603 603 603 603 603
603 603
603 603 603 603 805 603
603 603 603 603 603 603 603 603 603 603 603 603 1206 1206 1206 1206 1206 1206 1206 1206 1206

Value onsemi onsemi onsemi onsemi
onsemi
onsemi Shunloard
Shunlord onsemi
Wurth
Shunlord Std Std Std Std
Std Std
Std Std Std Std Std Std
Std Std Std Std Std Std Std Std Std Std Std Std Panasonic Panasonic Std Std Std Std Std Std Std

Package
5 A, 520 V
100 k
nc
100 mH
4.7 mH 0 W 0 W 1 W
100 kW
10 kW 10 W
1 kW 2.4 kW 200 W 200 kW 30 W 22 kW
2 kW 270 kW 30 kW 300 kW 36 kW 390 kW 4,7 W 5.1 kW
47 W 47 kW 510 W
nc 0,24 W 0,56 W 1.6 MW 120 W 2.4 MW 2.7 kW 22 W 2 MW 390 kW

Description General NPN Transistor, SMD General PNP Transistor, SMD Ultrafast Rectifier, 5 A, 520 V 2 stage Follower/Boost PFC controller Syn. Controller
2x PEM CCM/QR controller NTC, 0603, replaced by 100 kW resistor NTC, 0603, no connect optical coupler, standard SOP package Toroidal Line Choke, 15.8 x 8.5, 2.5 A
Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1%
Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1%
Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/8 W, 1% Resistor, Chip, 1/10 W, 1%
Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1% Resistor, Chip, 1/10 W, 1%, Resistor, Chip, 1/2 W, 1% Resistor, Chip, 1/2 W, 1% Resistor, Chip, 1/4 W, 1% Resistor, Chip, 1/4 W, 1% Resistor, Chip, 1/4 W, 1% Resistor, Chip, 1/4 W, 1% Resistor, Chip, 1/4 W, 1% Resistor, Chip, 1/4 W, 1% Resistor, Chip, 1/4 W, 1%

www.onsemi.com 20

EVBUM2818/D

Table 2. BOM (continued)

Item Qty Reference

Type

87 1

R25

Resistor

88 1

Transformer

Part Name ERJ8BQFR005V
Customed

89 1

PFC Inductor

Customed

90 1

C46

Electrolytic capacitor

91 3 C13-14, C48 Electrolytic solid capacitor

KF Series PS681M025F080P

92 1

C32

Electrolytic

KL680M450J300A00H

electrolytic capacitor

93 1

MOSFET

FDMS86180

94 1

MOSFET

FCMT250N65S3

95 1

MOSFET

FCMT199N60

96 1

MOSFET

NTTFS4C02NT1G

97 1

USB Type C connector

CUS31738616001

98 1

U10

PD Controller

FUSB15101

99 1

ZD2

Zener

MM3Z13VT1G

100 1 101 4

ZD1 ESD1-4

Zener ESD

MM3Z18VT1G SD05T1G

MFR 1206 TH type
TH type
6.3 mm x 11 mm 8 mm x 14 mm
18 mm x 30 mm
SO8FL Power88 Power88
u8FL SMD
DFN4X4 SOD323 SOD323 SOD323

Value Panasonic
Custom
Custom
CapXon CapXon
CapXon
onsemi onsemi onsemi onsemi CSCONN
onsemi onsemi onsemi onsemi

Package 5 mW
see specification 200 mH
22 mF, 100 V 680 mF, 25 V 68 mF, 450 V
13 V 18 V 5 V

Description Resistor, Chip, 1/2 W, 1% RM8, Ferroxcube 3C95, 6 Pin Bobbin RM8, Ferroxcube 3C95 core, 6 Pin Bobbin size: 6.3 mm x 11 mm size: 8 mm x 14 mm
size: 18 mm x 30 mm
MOSFET, NChan, 100 V MOSFET, NChan, 650 V MOSFET, NChan, 600 V MOSFET, NChan, 3.4 mW Type C connector, SMT
PD protocol controller GENERIC ZENER-DIODE GENERIC ZENER-DIODE ESD protection device

REFERENCES
onsemi datasheet for NCP1623, NCP1343, NCP4307, FUSB15101, FCMT199N60, FCMT250N65, FDMS86180, NTTFS4C02 onsemi Design Notes DN05043

www.onsemi.com 21

onsemi,

, and other names, marks, and brands are registered and/or common law trademarks of Semiconductor Components Industries, LLC dba “onsemi” or its affiliates

and/or subsidiaries in the United States and/or other countries. onsemi owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of onsemi’s product/patent coverage may be accessed at www.onsemi.com/site/pdf/Patent-Marking.pdf. onsemi is an Equal Opportunity/Affirmative Action Employer. This

literature is subject to all applicable copyright laws and is not for resale in any manner.

The evaluation board/kit (research and development board/kit) (hereinafter the “board”) is not a finished product and is not available for sale to consumers. The board is only intended for research, development, demonstration and evaluation purposes and will only be used in laboratory/development areas by persons with an engineering/technical training and familiar with the risks associated with handling electrical/mechanical components, systems and subsystems. This person assumes full responsibility/liability for proper and safe handling. Any other use, resale or redistribution for any other purpose is strictly prohibited.

THE BOARD IS PROVIDED BY ONSEMI TO YOU “AS IS” AND WITHOUT ANY REPRESENTATIONS OR WARRANTIES WHATSOEVER. WITHOUT LIMITING THE FOREGOING, ONSEMI (AND ITS LICENSORS/SUPPLIERS) HEREBY DISCLAIMS ANY AND ALL REPRESENTATIONS AND WARRANTIES IN RELATION TO THE BOARD, ANY MODIFICATIONS, OR THIS AGREEMENT, WHETHER EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT LIMITATION ANY AND ALL REPRESENTATIONS AND WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, NON-INFRINGEMENT, AND THOSE ARISING FROM A COURSE OF DEALING, TRADE USAGE, TRADE CUSTOM OR TRADE PRACTICE.

onsemi reserves the right to make changes without further notice to any board.
You are responsible for determining whether the board will be suitable for your intended use or application or will achieve your intended results. Prior to using or distributing any systems that have been evaluated, designed or tested using the board, you agree to test and validate your design to confirm the functionality for your application. Any technical, applications or design information or advice, quality characterization, reliability data or other services provided by onsemi shall not constitute any representation or warranty by onsemi, and no additional obligations or liabilities shall arise from onsemi having provided such information or services.
onsemi products including the boards are not designed, intended, or authorized for use in life support systems, or any FDA Class 3 medical devices or medical devices with a similar or equivalent classification in a foreign jurisdiction, or any devices intended for implantation in the human body. You agree to indemnify, defend and hold harmless onsemi, its directors, officers, employees, representatives, agents, subsidiaries, affiliates, distributors, and assigns, against any and all liabilities, losses, costs, damages, judgments, and expenses, arising out of any claim, demand, investigation, lawsuit, regulatory action or cause of action arising out of or associated with any unauthorized use, even if such claim alleges that onsemi was negligent regarding the design or manufacture of any products and/or the board.
This evaluation board/kit does not fall within the scope of the European Union directives regarding electromagnetic compatibility, restricted substances (RoHS), recycling (WEEE), FCC, CE or UL, and may not meet the technical requirements of these or other related directives.
FCC WARNING This evaluation board/kit is intended for use for engineering development, demonstration, or evaluation purposes only and is not considered by onsemi to be a finished end product fit for general consumer use. It may generate, use, or radiate radio frequency energy and has not been tested for compliance with the limits of computing devices pursuant to part 15 of FCC rules, which are designed to provide reasonable protection against radio frequency interference. Operation of this equipment may cause interference with radio communications, in which case the user shall be responsible, at its expense, to take whatever measures may be required to correct this interference.
onsemi does not convey any license under its patent rights nor the rights of others.
LIMITATIONS OF LIABILITY: onsemi shall not be liable for any special, consequential, incidental, indirect or punitive damages, including, but not limited to the costs of requalification, delay, loss of profits or goodwill, arising out of or in connection with the board, even if onsemi is advised of the possibility of such damages. In no event shall onsemi’s aggregate liability from any obligation arising out of or in connection with the board, under any theory of liability, exceed the purchase price paid for the board, if any.
The board is provided to you subject to the license and other terms per onsemi’s standard terms and conditions of sale. For more information and documentation, please visit www.onsemi.com.

ADDITIONAL INFORMATION
TECHNICAL PUBLICATIONS: Technical Library: www.onsemi.com/design/resources/technical-documentation onsemi Website: www.onsemi.com

ONLINE SUPPORT: www.onsemi.com/support For additional information, please contact your local Sales Representative at www.onsemi.com/support/sales

www.onsemi.com
