P10034AP-L3-FR02 Microwave Oven
Product Information – GREYSTONE Microwave Oven
Model: P10034AP-L3-FR02
The GREYSTONE Microwave Oven is a versatile kitchen appliance
designed for heating, cooking, and drying food. It is important to
follow the instructions provided in this manual to ensure safe and
proper usage of the oven.
Precautions to Avoid Possible Exposure to Excessive Microwave
Energy:
- Do not operate the oven with the door open as it can result in
harmful exposure to microwave energy. - Do not place any object between the oven front face and the
door, and avoid accumulation of soil or cleaner residue on sealing
surfaces. - Do not use the oven if it is damaged, and ensure that the door
closes properly without any damage to the door, hinges, latches,
and door seals. - Adjustments or repairs should only be done by qualified service
personnel.
Important Safety Instructions:
- Read all instructions before using the appliance.
- Follow the specific precautions mentioned above to avoid
possible exposure to excessive microwave energy. - The appliance must be properly grounded by connecting it to a
grounded outlet. - Do not operate the oven when empty.
- Install or locate the appliance according to the provided
installation instructions. - Avoid heating whole eggs and sealed containers that may
explode. - Use the appliance only for its intended purpose and avoid using
corrosive chemicals or vapors. - Supervise children when using the oven.
- Take precautions to prevent fire, such as not overcooking food,
removing wire twist-ties from bags, and not using the cavity for
storage purposes. - Be cautious when heating liquids, as they can overheat without
appearing to boil and suddenly boil over when a utensil is
inserted. Stir the liquid before and halfway through heating, and
use appropriate containers.
Product Usage Instructions:
- Before using the microwave oven, carefully read all the
instructions provided in the manual. - Ensure that the oven is properly installed according to the
installation instructions. - Do not operate the oven with the door open as it can result in
harmful exposure to microwave energy. - Avoid placing any objects between the oven front face and the
door, and keep sealing surfaces clean and free from soil or cleaner
residue. - Check for any damage to the oven before operation. Ensure that
the door closes properly without any bent parts, broken or loosened
hinges and latches, or damaged door seals and sealing
surfaces. - If any adjustments or repairs are required, contact qualified
service personnel. - Always ground the appliance by connecting it to a properly
grounded outlet. - Avoid operating the oven when it is empty.
- Use the oven only for its intended purpose of heating, cooking,
and drying food. Do not use corrosive chemicals or vapors in the
oven. - Supervise children when they are using the microwave oven.
- Take precautions to prevent fire. Do not overcook food, remove
wire twist-ties from bags, and avoid leaving paper products,
cooking utensils, or food in the cavity when not in use. - Be cautious when heating liquids. Do not overheat them, stir
them before and halfway through heating, and avoid using
straight-sided containers with narrow necks. Allow the container to
stand in the microwave oven for a short time after heating.
GREYSTONE
Model: P10034AP-L3-FR02
Microwave Oven Instructions
Please read these instructions carefully before installing and operating the oven.
Content
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY….. 2 IMPORTANT SAFETY INSTRUCTIONS ……………………………………………………………………………………… 2 GROUNDING INSTRUCTIONS……………………………………………………………………………………………………. 4 INSTALLATION GUIDE ………………………………………………………………………………………………………………. 5 COOKING UTENSILS GUIDE ……………………………………………………………………………………………………… 5 SPECIFICATIONS………………………………………………………………………………………………………………………… 6 PRODUCT DIAGRAM………………………………………………………………………………………………………………….. 6 CONTROL PANEL ……………………………………………………………………………………………………………………….. 7 OPERATION INSTRUCTIONS …………………………………………………………………………………………………….. 8
SETTING THE CLOCK …………………………………………………………………………………………………………… 8 SETTING THE TIMER…………………………………………………………………………………………………………….. 8 EXPRESS COOKING………………………………………………………………………………………………………………. 8 +30 SEC FUNCTION……………………………………………………………………………………………………………….. 8 MICROWAVE COOKING………………………………………………………………………………………………………… 8 SPEED DEF…………………………………………………………………………………………………………………………….. 9 COOK BY WEIGHT ………………………………………………………………………………………………………………… 9 WEIGHT DEF. ………………………………………………………………………………………………………………………. 10 MULTI-STAGE COOKING…………………………………………………………………………………………………….. 10 CHILD LOCK ……………………………………………………………………………………………………………………….. 10 AUTO COOK MENUS ………………………………………………………………………………………………………………… 11 POTATO……………………………………………………………………………………………………………………………….. 11 POPCORN ……………………………………………………………………………………………………………………………. 11 PIZZA ………………………………………………………………………………………………………………………………….. 11 BEVERAGE………………………………………………………………………………………………………………………….. 11 FROZEN DINNER ………………………………………………………………………………………………………………… 11 REHEAT……………………………………………………………………………………………………………………………….. 11 CLEANING AND CARE ……………………………………………………………………………………………………………… 12
1
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
1. Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is very important that the oven door close properly and that there is no damage to the a) Door (including any bent), b) Hinges and latches (broken or loosened), c)Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except qualified service personnel.
IMPORTANT SAFETY INSTRUCTIONS
WARNING!–To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2. Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY” on page 2. 3. This appliance must be grounded. Connect only to properly grounded outlet. See
“GROUNDING INSTRUCTIONS” on page 4. 4. Do not operate the oven when empty. 5. Install or locate this appliance only in accordance with the provided installation
instructions. 6. Some products such as whole eggs and sealed containers -for example, closed glass
jars- are able to explode and should not be heated in this oven. 7. Use this appliance only for its intended use as described in this manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use. 8. As with any appliance, close supervision is necessary when used by children. 9. To reduce the risk of fire in the oven cavity: a) Do not overcook food. Carefully attend appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking. b) Remove wire twist-ties from paper or plastic bags before placing bag in oven.
2
c) If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the power cord or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or food in the cavity when not in use.
10. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THEIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury to person:
a) Do not overheat the liquid. b) Stir the liquid both before and halfway through heating it. c) Do not use straight-sided containers with narrow necks. d) After heating, allow the container to stand in the microwave oven for a short time
before removing the container. e) Use extreme care when inserting a spoon or other utensil into the container. 11. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in
microwave oven. 12. Do not cover or block any openings on the appliance. 13. Do not store or use this appliance outdoors. Do not use this product near water, for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations. 14. Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly or if it has been damaged or dropped. 15. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let cord hang over edge of table or counter. 16. This appliance should be serviced only by qualified service personnel, contact nearest authorized service facility for examination, repair, or adjustment. 17. When cleaning surfaces of door and oven that comes together on closing the door, use only mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth. 18. This equipment has been tested and found to comply with Part 18 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the product. 19. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
3
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: y Reorient or relocate the receiving antenna. y Increase the separation between the equipment and receiver. y Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected. y Consult the dealer or an experienced radio/TV technician for help.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. WARNING!– Improper use of the grounding plug can result in a risk of electric shock. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded, and if it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord shall be equal to or greater than the electrical rating of the appliance. Electrical Requirements The electrical requirements are a 120 volt 60 Hz, AC only, 20 amp. It is recommended that a separate circuit serving only the oven be provided. The oven is equipped with a 3-prong grounding plug. It must be plugged into a wall outlet properly installed and grounded. Power Cord 1. A short power supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord. 2. Longer cord sets or extension cords are available and may be used if care is exercised
in their use. 3. If long cord or extension cord is used a) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance. b) The extension cord must be a grounding-type 3-wire cord, and The longer cord should
be arranged so that it will not drape over the counter top or table top where it can be pulled on by children or tripped over unintentionally.
4
Installation Guide
1. Make sure that all the packing materials are removed from the inside of the door. 2. This microwave oven must be placed on a flat. 3. For correct operation, the oven must have sufficient air flow. Allow 20cm of space above the oven,
10cm at back and 5cm at both sides. Do not cover or block any openings on the appliance. Do not remove feet on which oven stands. 4. Do not operate the oven without glass tray, roller support, and shaft in their proper positions. 5. Make sure that the power cord is undamaged and does not run under the oven or over any hot or sharp surface. 6. The socket must be readily accessible so the microwave oven can be easily unplugged in an emergency.
Cooking Utensils Guide
This section lists which utensils can be used in this microwave, which have limited use for short periods, and which should not be used in this microwave.
RECOMMENDED Microwave browning dish — Use to brown the exterior of small items such as steaks, chops, or pancakes. Follow the directions provided with your browning dish. Microwaveable plastic wrap — Use to retain steam. Leave a small opening for some steam to escape and avoid placing it directly on the food. Paper towels and napkins — Use for short-term heating and covering; these absorb excess moisture and prevent spattering. Do not use recycled paper towels, which may contain metal and could ignite. Glass and glass-ceramic bowls and dishes — Use for heating or cooking. Paper plates and cups — Use for short-term heating at low temperatures. Do not use recycled paper, which may contain metal and could ignite. Wax paper — Use as a cover to prevent spattering. Thermometers — Use only those labeled “Microwave Safe” and follow all directions. Check the food in several places. Conventional thermometers may be used on microwave food once the food has been removed from the oven.
LIMITED USE Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too much foil can damage your oven, so be careful. You should keep distance of 1 inch (2.54cm) between aluminum foil and cavity. Ceramic, porcelain, and stoneware– Use these if they are labeled “Microwave Safe”. If they are not labeled, test them to make sure they can be used safely. Plastic — Use only if labeled “Microwave Safe”. Other plastics can melt.
NOT RECOMMENDED Glass jars and bottles — Regular glass is too thin to be used in a microwave. It can shatter and cause damage and injury.
5
Paper bags — These are a fire hazard, except for popcorn bags that are designed for microwave use. Styrofoam plates and cups — These can melt and leave an unhealthy residue on food. Plastic storage and food containers — Containers such as margarine tubs can melt in the microwave. Metal utensils — These can damage your oven. Remove all metal before cooking. Note: Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.
Specifications
Power Consumption Output Operation Frequency Outside Dimensions(H x W x D) Oven Capacity Net Weight
120V/60Hz, 1500W(microwave) 1000W
2450MHz 432×653×440mm
1.3cu.ft. Approx38.1lbs
Product Diagram
1. Door Safety Lock System 2. Oven Window 3. Shaft 4. Roller Ring 5. Door Release Button 6. Control Panel 7. Wave Guide (Please do not remove
the mica plate covering the wave guide) 8. Glass Tray
6
Control Panel
Q MENU ACTION SCREEN Cooking time, power, indicators and present time are displayed. Q AUTO COOK MENUS Instant settings to cook popular foods Q NUMBER PADS(0-9) Press to set time or amount. Use number pads from 1 to 6 to set express cooking. Q CLOCK Press to set clock time. Q RESET/HOLD Press to reset the oven before setting a cooking program. Press and hold to set child lock. Q POWER Press to set microwave cooking power level. Q TIMER Press to set timer function. Q COOK Use to set multi-stage cooking program. Q COOK BY WEIGHT Press to set cooking program based on weight. Q WEIGHT DEF. Press to set defrost program based on weight. Q SPEED DEF. Press to set speed defrost program based on time. Q + 30 SEC. Simply press it a number of times to set cooking time and cook immediately at full power level. Press to add cooking time. Q START/STOP Press to start or stop cooking program.
7
Operation Instructions
¾ In the process of setting, broke about 30 seconds the oven will return to standby mode. ¾ During cooking, if press START/STOP pad once, the program will be paused, and then press
START/STOP pad once again to resume. During pausing, press RESET/HOLD pad once, the program will be canceled. ¾ After cooking end, the screen will display End with sound every two minutes until user press any pad or open the door. ¾ In the process of operation, press a valid pad, the buzzer rings once, but if press a invalid pad, the buzzer rings twice.
SETTING THE CLOCK
1. In standby mode, press CLOCK pad once. 2. Use number pads to enter the correct time. 3. Press CLOCK pad to confirm. NOTE: This is a 12 hour clock. When the oven is first plugged in, the display will show “ENTER”, “CLOCK” and “TIME”. If you don’t have to set the clock time, press the RESET/HOLD pad directly to enter next operation.
SETTING THE TIMER
1. Press TIMER pad once. 2. Use number pads to enter desired time. The longest time is 99 minutes and 99 seconds. 3. Press START/STOP pad to confirm. NOTE: When the countdown ends, the buzzer will beep to remind you. Time countdown can be seen in display for 5 seconds by pressing TIMER pad and then you can cancel the program by pressing RESET/HOLD pad when display shows the time.
EXPRESS COOKING
Directly in standby mode, when you press a number pad (1, 2, 3, 4, 5 or 6) once, The system starts the cooking program directly with the corresponding time (respectively 1 minute, 2 minutes, 3 minutes, 4 minutes, 5 minutes and 6 minutes). The microwave oven will start to cook at full power level.
+30 SEC FUNCTION
In standby mode, press +30 SEC. pad in quick succession to set the cooking time (each press for 30 seconds, and up to 99 minutes and 59 seconds). The oven will start working automatically. NOTE: During cooking, you can add the current cooking time by pressing +30 SEC. pad. Weight defrost, speed defrost, cook by weight and auto cook menus cannot be added cooking time.
MICROWAVE COOKING
1. In standby mode, press POWER LEVEL pad repeatedly to select power level. 2. Use number pads to enter cooking time. The longest time is 99 minutes and 99 seconds. 3. Press START/STOP pad to confirm.
8
Press POWER LEVEL repeatedly to select power level:
Press POWER LEVEL Power(Display) Press POWER LEVEL Power(Display)
Once
100%(P100)
7 times
40%(P-40)
Twice
90%(P-90)
8 times
30%(P-30)
3 times
80%(P-80)
9 times
20%(P-20)
4 times
70%(P-70)
10 times
10%(P-10)
5 times
60%(P-60)
11 times
0%(P-00)
6 times
50%(P-50)
NOTE: During cooking, you can check the current cooking power level by pressing POWER LEVEL pad.
SPEED DEF.
1. Press SPEED DEF. pad once. 2. Use number pads to enter defrosting time. The longest time is 99 minutes and 99 seconds. 3. Press START/STOP pad to confirm. NOTE: During cooking program, the system will pause to remind user to turn food over, and then press START/STOP to resume the cooking.
COOK BY WEIGHT
The cooking time and power are adjusted automatically once food category and weight are programmed. 1. Press COOK BY WEIGHT pad once. 2. Press number pad 1, 2 or 3 to select food type.
Code 1
Food Type Beef
Maximum Weight 5 lb.16 oz
2
Mutton
3
Pork
5 lb.16 oz 4 lb.8 oz
3. Use number pads to enter food weight.
4. Press START/STOP pad to confirm.
NOTE:
g During cooking, the system will pause and sound to remind user to turn food over, and then press
START/STOP pad to resume.
g Meat must be defrosted and at refrigerated temperature.
g Weight must be in pounds and ounces. If label gives weight in pounds only, change the fraction of a
pound to ounces by using the chart.
Converting fractions of a pound to ounces
Fractions of a pound
Ounces
Fractions of a pound
Ounces
Less than .03
0
.54 to .59
9
.03 to .09
1
.60 to .65
10
.10 to .15
2
.66 to .71
11
.16 to .21
3
.72 to .78
12
.22 to .27
4
.79 to .84
13
.28 to .34
5
.85 to .90
14
.35 to .40
6
.91 to .97
15
.41 to .46
7
above .97
go to next even
.47 to .53
8
9
WEIGHT DEF.
1. Press WEIGHT DEF. pad once. 2. Use number pad enter food weight. The maximum weight you can enter is 5 lb.16 oz. 3. Press START/STOP pad to confirm. NOTE: y Weight must be in pounds and ounces. If label gives weight in pounds only, change the fraction of a
pound to ounces by using the chart given above. y During cooking program, the system will pause and sound beeps to remind user to turn food over,
and then press START/STOP to resume the cooking.
MULTI-STAGE COOKING
Your oven can be programmed for up to 3 automatic cooking sequences. It can be composed of speed defrost with one or two microwave cooking program, or composed of two microwave cooking program. Speed defrost can only be set in the first sequence. A. Speed defrost with one or two-stage microwave cooking 1. Open the door and place the food into the oven, close it. 2. Press SPEED DEFROST pad once. 3. Enter desired defrosting time by pressing correct number pads. 4. Press COOK pad once. 5. Input first microwave cooking program. Do not press START/STOP pad. 6. Press COOK pad once. 7. Input second microwave cooking program. 8. Press START/STOP pad to start. NOTE: Step 6 and 7 are not necessary if you have one microwave cooking program. B. Two-stage microwave cooking Some recipes require different stages of cooking at different temperatures. 1. Input first microwave cooking program. Do not press START/STOP pad. 2. Press COOK pad once. 3. Input second microwave cooking program. 4. Press START/STOP pad to start.
CHILD LOCK
The safety lock prevents unsupervised operation by children. To set the child proof lock: In standby mode, press and hold RESET/HOLD pad for 3 seconds, then a beep will sound, the oven will auto enter child lock mode and the lock indicator light will turn on. In the lock state, all pads are disabled. To cancel the child proof lock: Press and hold RESET/HOLD pad for 3 seconds, then a beep will sound and the indicator light will come off.
10
Auto Cook Menus
The auto cook menus setting allow you to cook or reheat food automatically without entering power level
or time. For smaller portions, simply press the applicable pad and start. For larger portions, push the pad
twice. FROZEN DINNER, BAKED POTATO and BEVERAGE allow you to cook multiple amounts of the
same food.
2. Press START/STOP to confirm.
POTATO
1. Press POTATO once or twice.
BEVERAGE
2. Enter number of potatoes by pressing number 1. Press BEVERAGE once or twice.
pads from 1 to 4.
2. Enter number of cups by pressing number
3. Press START/STOP to confirm.
pads from 1 to 4.
3. Press START/STOP to confirm.
POPCORN
1. Press POPCORN once.
FROZEN DINNER
2. Press START/STOP to confirm.
1. Press FROZEN DINNER once or twice.
NOTE: To change the preset POPCORN time: 2. For 1 entree, press number pad “1”. For 2
Press POPCORN twice. Use number pads to
entrees, press number pad “2”.
enter minutes and seconds. Press START/STOP. 3. Press START/STOP pad to confirm.
The longest time is 99 minutes and 99 seconds.
This new cooking time will be set as the default REHEAT
one until you change it or next power on.
To reheat a plate of leftover (12 oz ~18 oz):
PIZZA
1. Press REHEAT pad once. 2. Press START/STOP to confirm.
1. Press PIZZA once or twice.
11
Cleaning and Care
1. Turn off the oven and unplug the power cord from the wall when cleaning. 2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using spray or other harsh cleaners. They may stain, streak or dull the door surface. 3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the operating parts inside the oven, water should not be allowed to seep into the ventilation openings. 4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth to remove any spills or spatters. Do not use abrasive cleaner. 5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the control panel, leave oven door open to prevent oven from accidentally turning on. 6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may occur when the microwave oven is operated under high humidity condition. And it is normal. 7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher. 8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the bottom surface of the oven with mild detergent. The roller ring may be washed in mild, soapy water or in a dishwasher. When removing the roller ring, be sure to replace it in the proper position. 9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth. 10. If the light bulb burns out, please contact customer service to have it replaced. 11. The oven should be cleaned regularly and any food deposits should be removed. Failure to maintain the oven in a clean condition could lead to deterioration of surface that could adversely affect the life of the unit and could possibly result in a hazardous situation. 12. Please do not dispose of this appliance into the domestic rubbish bin; it should be disposed to the particular disposal center provided by the municipalities.
12
