EC-RF620 Dual Channel RFID Controller
Product Information: EC-RF620 Dual-channel RFID controller
The EC-RF620 Dual-channel RFID controller is a product of
EC-LINK Automation (Shenzhen) Co. Ltd. It is a compact device with
dimensions of 132X87X35mm and has a protection level of IP67. The
device has a working power supply of DC 9V-36V2A and a maximum
power consumption of 8W. It has a working temperature range of -25
to +70 degrees Celsius and a storage temperature range of -40 to
+85 degrees Celsius. The device has a communication interface that
includes Ethernet, RS-232, and RS485. It also has IO interfaces and
ANT1/ANT2 interfaces.
Product Features:
- Compact size
- IP67 protection level
- DC 9V-36V2A power supply
- Maximum power consumption of 8W
- Working temperature range of -25 to +70 degrees Celsius
- Storage temperature range of -40 to +85 degrees Celsius
- Communication interface that includes Ethernet, RS-232, and
RS485 - IO interfaces and ANT1/ANT2 interfaces
Product Usage Instructions:
The EC-RF620 Dual-channel RFID controller can be used in various
applications such as access control systems, inventory management
systems, and asset tracking systems. To use the device, follow the
steps below:
- Mount the device using the DIN Guide rail installation kit or
wall set. - Connect the power supply to the POWER interface using the M12-A
4 pin connector. - Connect the device to the network using the LAN interface and
the M12-D 4 pin connector. - Connect the antennas to the ANT1/ANT2 interfaces using the SMA
connector. Only connect the antennas required to be used.
Unconnected antenna, software do not open, otherwise no load may
damage the reader! - Connect input/output devices to the IO interfaces using the
M12-A 12-pin connector. The interface definition is as follows:- IN1: Input1
- IN2: Input2
- IN3: Input3
- IN4: Input4
- OUT1: Output1
- OUT2: Output2
- RS232-RXD: RS232 Receive Data
- RS232-TXD: RS232 Transmit Data
- RS232-GND: RS232 Ground
- RS485A: RS485 A
- RS485B: RS485 B
- Power source GND
- The device has 3 LED display lights that indicate the device’s
status:- Red light bright: The device power is ON.
- Blue light bright: Represents data upload (read to tag). No
bright means that there is no data upload. - Green light bright: Indicates receiving data. No light
indicates that no data is received.
For more information and support, contact EC-LINK Automation
(Shenzhen) Co. Ltd. at Room 2206, Block B, Shixia Xintian Century
Business Center, Futian District, Shenzhen City. You can also visit
their website at www.eclinksz.com or contact them
through telephone at 0086-755-8368 1813 or fax at 0086-755-8323
5833. You may also send an email to [email protected].
EC-LINK Automation (Shenzhen) Co. Ltd. EC-RF620 Dual-channel RFID controller
1Product features
Operating Frequency 860MHz960MHz Support Protocolsupport EPC class Gen2 (ISO 18000-6-c)GB/T29768 Working mode: fixed frequency or frequency jump Output power1dBm-33±1dBm Read-write speed Greater than 400, times / second Read and write distanceGreater than 10 m, related to the antenna and label
specifications. Working power supply DC 9V-36V2A Maximum power consumption8W Working temperature-25- +70 Storage temperature-40- +85 Working humidity: 10% ~ 95% RH without condensation Communication interface: EthernetRS-232RS485
ADD:Room 2206, Block B, Shixia Xintian Century Business Center, Futian District, Shenzhen City http://www.eclinksz.com Tel:0086-755-8368 1813 Fax:0086-755-8323 5833 E-mail:[email protected]
1
EC-LINK Automation (Shenzhen) Co. Ltd.
Finished product size132X87X35mm Installation method: the 4 x M4 screws are fixed Protection levelIP67 Impact and vibration test standardsIEC61373
2Interface definition
1 POWER interface,The connector meets the standard GJB142A, M12-A 4 pin connector definition
2 LAN interface,M12-D 4pin Connector definition
3 ANT1ANT2interface,The SMA connector,connecting to the antenna
Only connect to the antennas required to be used. Unconnected antenna, software do not open, otherwise no load may damage the reader!
ADD:Room 2206, Block B, Shixia Xintian Century Business Center, Futian District, Shenzhen City http://www.eclinksz.com Tel:0086-755-8368 1813 Fax:0086-755-8323 5833 E-mail:[email protected]
2
EC-LINK Automation (Shenzhen) Co. Ltd.
4 IO Interface, M12-A 12-pin connector definition
I/O Interface definition
1
IN4 Input4
2
RS485A
3
RS232-RXD
4
RS232-TXD
5
OUT2 Output2
6
OUT1 Output1
7
IN1 Input1
8
IN2 Input2
9
IN3 Input3
10
RS485B
11
RS232-GND
12
Power source
GND
Schematic diagram of the wiring port
3Human-computer interface requirements
The controller has 3 LED display lights, specifically defined as follows:
Lights PR TX RX
Definition
Red light bright–The device power ON
Blue light bright–Represents data upload (read to tag)No bright means that there is no data upload Green light bright–Indicates receiving dataNo light indicates that no data is received
ADD:Room 2206, Block B, Shixia Xintian Century Business Center, Futian District, Shenzhen City http://www.eclinksz.com Tel:0086-755-8368 1813 Fax:0086-755-8323 5833 E-mail:[email protected]
3
EC-LINK Automation (Shenzhen) Co. Ltd. 4Install the size diagram
ADD:Room 2206, Block B, Shixia Xintian Century Business Center, Futian District, Shenzhen City http://www.eclinksz.com Tel:0086-755-8368 1813 Fax:0086-755-8323 5833 E-mail:[email protected]
4
EC-LINK Automation (Shenzhen) Co. Ltd. 5Installation accessories:
1DIN Guide rail installation kit, model20950000004
Technical data
MaterialStainless steel Accord with RoHS Accord with REACH Package sizeLength 132 mm X width35 mm X Thickness of 1.5 mm Net weight82.7 g
ADD:Room 2206, Block B, Shixia Xintian Century Business Center, Futian District, Shenzhen City http://www.eclinksz.com Tel:0086-755-8368 1813 Fax:0086-755-8323 5833 E-mail:[email protected]
5
EC-LINK Automation (Shenzhen) Co. Ltd.
2Wall set, model: 20 95300 0007
Technical data
MaterialStainless steel SizeLength 132 mm X width 85.5 mm X height 37.5 mm Accord with RoHS Accord with REACH Net weight164.1 g
caution
This device must be professionally installed This equipment does not allow any antenna to work with the transmitter; the permitted antenna type must be specified external antennas, for example (antenna name:Planar RFID antenna,Model:EC-UHF-NF3004) device is generally for industrial/commercial use. it must be sold to authorized dealers or installers only,cannot be sold via retail to the general public or by mail order. The equipment is an RFID technology RF product, and must be installed by electrical and electronic professionals with a professional certificate
ADD:Room 2206, Block B, Shixia Xintian Century Business Center, Futian District, Shenzhen City http://www.eclinksz.com Tel:0086-755-8368 1813 Fax:0086-755-8323 5833 E-mail:[email protected]
6
EC-LINK Automation (Shenzhen) Co. Ltd.
FCC Caution
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.
RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
IC Caution.
CAN ICES-003(B) / NMB-003(B)
RSS-Gen Issue 3 December 2010″&”CNR-Gen 3e éditionDécembre 2010:
– English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. – French:
ADD:Room 2206, Block B, Shixia Xintian Century Business Center, Futian District, Shenzhen City http://www.eclinksz.com Tel:0086-755-8368 1813 Fax:0086-755-8323 5833 E-mail:[email protected]
7
EC-LINK Automation (Shenzhen) Co. Ltd.
Le présentappareilestconforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitationestautorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d’encompromettre le fonctionnement.
