BIG DOG Wireless Bluetooth Speakers
Product Description
- POWER ON
Press Power button around 1.55 to power on - POWER OFF Press Power button around 25
- PLAY/PAUSE
Press Play/Pause button - VOLUME DOWN
Press Volume Down button - VOWME UP
Press Volume Up button - PREY Hold Volume Down button
- NEXT Hold Volume up button
- SWITCH MODE
Hold Mode button around 2s to switch BT,TF,U5B disk,AUX mode - EQ Press Mode button for different EQ (full sound mode I bass mode /natural sound)
- PICKUP CALL Press Play/Pause button
- REJECT CALL Press Play/Pause button 25
- END CALL Press Play/Pause button
- REDIAL Press Play/Pause button twice
- BLUETOOTH DISCONNECT Hold Play/Pause button around 35
Press Power button around 1.55 to power on
Press Play/Pause button
Press Volume Down button
Press Volume Up button
Hold Mode button around 2s to switch BT,TF,U5B disk,AUX modeSpecification
| SIZE | D87*H218 |
| WEIGHT | 823g |
| BLUETOOTH | Version – 5.0 Bluetooth – When powered on, Bluetooth is on automatically, the blue light will flash quickly, the light will stay on when connected. TWS Stereo Pairing –
Bluetooth Distance – around 18m (depending on the environment) |
| PROMPT | Power On Prompt – Dag bark Power Off Prompt – Dog whine |
| OTHER | Waterproof – IPX6 DSP-Yes Max Loud – 105dBA Stand-By Time – Shuts down automatically after 10 mins if there is no Bluetooth connection Logo – Metal logo with wire appearance |
| SPEAKER | Drivers – Two drivers, dia 57mm Radiators – Two radiators, dia 60mm Total RMS Power – 2x20W |
| PORT FUNCTION | Type-C Port – Charging port AUX Port – Plays aux source when plugged into aux cable TF Card Port – Plays TF card source when plugged into TF card USB·A Port – Plays USB source when plugged into USB disk USB·A Port – Charges other devices when plugged into charging cable |
| LED STATUS | AUX Mode – Blue light flashes when playing music, blue light stays on when paused TF Card Mode – Blue light flashes when playing music, blue light stays on when paused U Disk Model – Blue light flashes when playing music, blue light stays on when paused RGB – Slow flash – run light – off RGB TWS
Chargin
Low Power- Red light will flash |
| BATTERY | Battery Type – Lithium Ion battery pack Capacity- 7.2V 2500mAh / 18WH Play Time -15 hours at around 15% volume |
| ADDITIONAL ACCESSORIES | Charging Cable – USB A-type C, length 50cm User Manual – General Manual 3.5mm AUX Cable – 3.5mm – 3.5mm cable, length 50cm Strap-Yes |
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
