Jimilot Ll702 4g Cat.1 Wireless Gps Tracker User Manual

JimiloT LL702 4G Cat.1 Wireless GPS Tracker

INTRODUCTION

The LL702 is a wireless GPS tracker designed for ultra-long operation and easy installation The 4,200mAh battery allows if fo operates for more than 3 years in default mode, that is one position fix a day. The compact size and the strong magnet enable it to be installed hidden in vehicles equipment, and other valuables securely, If pinpoints the locafions of these assets accurately using satellites (GPS/BDS), base stations and WiFi hotspots. Other features include tamper alert, low battery alert, geofence alert, multiple working modes, and more making if suitable fo be used in various fracking scenarios fo keep your Cssef safe and give you peace of mind.

• GPS & BDs & LBS & Wi-Fi Positioning
  A synergy of multiple positioning systems ensures that locations are accurately displayed on the cloud platform.
• Tamper Alert
  Receive a tamper alert when the light sensor detects device removal.
• Strong Magnetic Base
  Near zero installation; the LL702 tightly and efforilessly fastens for most metal surfaces,
• LTE & GSM Network
  Communication via 4G LTE networks with 2G GSM fallback.
• Multiple Working Modes
  Configurable working modes according to your actual demands.
• Multiple Alerts
  Instant alerts for atypical events such as geo-fence entry/exit, abnormal vibration, Iow battery device fall/removal, etc.

GNSS

• Positioning system GPS+BDS+LBS+WiF
• Frequency
  • GPS: L1
  • BDS: B1
• Positioning accuracy: <2.5m CEP
• Tracking sensitivity: -165dBmn
• Acquisition sensitivity: -148dBmn
• TTFF (open sky): Avg. hot start1sec/Avg. cold start32sec

Cellular

• Communication network LTE Cat.1/GSM
• Frequency
  • LL702-E:
    • LTE-FDD: B1/B3/B5/B7/B8/B20/B28
    • LTE-TDD: B38/B40/B41
    • GSM: B2/B3/B5/B8
  • LL702-L:
    • UE-FDD: B1/B2/83/84/B5/B7/B8/820/828
    • LTE-TDD: B40
    • GSM: B2/B3/B5/B8

Power

• Battery: 4,200mAh/3.0V industria-grade Li-Manganese battery
• Working modes
  • Mode 1: Tacking mode
  • Mode 2: Regular GPS mode
  • Mode 3: Week-based mode
  • Mode 4: Alarm-based mode
  • Mode 6: Phase-based mode
• Standby time up to 3 years (one fix per day)

Interface

• LED indication Cellular (Green)
• SIM Nano-SIM
• Data storage 32+32Mb
• Tamper proof Light sensor

Physical specification

• Dimensions 80.0 x 45.0 x 31.4mm
• Weight 145g

Operating environment

• Operating temperature -20C to +70C

Feature

• Sensors Light sensor accelerometer
• Scenarios ldmper alert, low battery alert geo-fence alert
• Specialties Additional fixes (generated in cellular blind spots) upload upon cellular reconnection

Jimi loT Co., Ltd.

• Web: www.jimilab.com
• Email: [email protected]

We reserve the right to the final interpretation of this leaflet. All information is for reference only and is subject to change without further notice.
