Austin Range Bathroom Furniture Fitting Guide

Before installing the product, please ensure you have the
following tools:

Suitable fixings for securing the unit to the wall (pre-drilled
holes provided in back panel of unit)
Screwdriver
Measuring tape
Silicone

Hinge Adjustment

Loosen screw ‘A’ on all hinges, adjust door and retighten screw
for vertical adjustment. For lateral adjustment, loosen screw ‘B’,
adjust door and retighten screw. For horizontal adjustment, follow
step ‘C’ to adjust the screw.

Drawers Remove/Install

To remove the drawer, follow step ‘A’ and remove the fastener,
then follow step ‘B’. To install the drawer, follow step ‘B’ and
then follow step ‘A’ to lock the fastener. If drawer position needs
altering, follow step ‘C’ to adjust the screw.

Wall Hung Unit Installation

Please measure the ‘L’ distance between each bracket on the unit
and the ‘H’ height as requested by the customer. The standard
height is 850mm (including basin height) from floor to wash basin.
Use suitable fixings provided in the box to secure the unit to the
wall.

Mirror Cabinet and Storage Unit Installation

Please measure the ‘L’ and ‘H’ distance between each pre-drilled
hole on the product and fix them using the plug screws with chrome
covers provided in the box. The distance between the mirror cabinet
and basin should be 300-400mm. The distance from floor to the
bottom of the storage unit should be as requested by the
customer.

View Fullscreen

AUSTIN RANGE BATHROOM FURNITURE FITTING GUIDE
Tools required for installations
Note: For safety reasons Unit must be secured to the wall using suitable fixings (pre-drilled holes provide in back panel of unit) When fitting a basin to a unit, a bead of silicone should be applied to the top edge of the basin unit to seal between the basin and unit.

Hinge Adjustment

A – Ve r t i c a l
Loosen screw`A’on all hinges. Adjust door and retighten screw.

B-Lateral
Loosen screw`B’.Adjust door and retighten screw.

C-Horizontal
Loosen screw `B’ ½ turn. Turn screw`C’until door is positioned correctly and retighten screw`B’.

Drawers Remove/Install
To Remove the Drawer: Follow step ‘A’ and remove the fastener then follow step ‘B’. To Install the Drawer: Follow step ‘B’ and then follow step ‘A’ to lock the fastener. Drawer position: If drawer position needs altering follow step ‘C’ to adjust the screw.

pull out/lock
A

Wall hung unit installation.( fixings in box)
Please measure the L distance between each brackets on unit. and H ( height as customers request. The standard height is 850mm (including basin height) from floor to wash basin

request hight

24h

Mirror cabinet and Storage unit. ( plug screws with chrome covers in box) Please measure the L&H distance between each pre-drilled holes on products.and fixing them as below steps.the distance will be 300-400 the mirror cabinet to basin as below . the distance from floor to bottom of storage as customer requests.

H H

request hight

1
H=300-400mm
