Livex Lighting 48978-04 2-light Nickel Accents Sphere Semi Flush Light Instructions

48978-04 2-Light Nickel Accents Sphere Semi Flush Light

Product Information: Assembling & Installation
Instructions

The product installation instructions apply to the enclosed
product, although the drawing shown may not exactly match the
product enclosed. The fixture comes with a lamp body, glass shade,
and necessary hardware for installation. The junction box is not
included. The fixture is designed to work with specific wattage and
should not exceed the specified wattage.

Product Usage Instructions:

1. Turn off the power at the circuit breaker box before beginning
   installation.
2. Remove the old fixture and all hardware from the junction
   box.
3. Unpack the new fixture and lay out all parts on a clear area.
   Take care not to lose any small parts necessary for
   installation.
4. Thread the pipe screw partway into the center hole of the
   single bar and secure it with a hex nut.
5. Attach the single bar to the junction box using two box screws.
   The side of the single bar marked “GND” must face out.
6. Connect the electrical wires as shown in Fig.2, making sure
   that all wire nuts are secured. If your outlet has a ground wire
   (green or bare copper), connect the fixture ground wire to it.
   Otherwise, connect the fixture’s ground wire directly to the
   mounting strap with the green screw provided. After wires are
   connected, tuck them carefully inside the junction box.
7. Raise the lamp body onto the junction box, aligning the pipe
   screw on the single bar with the center hole in the lamp body and
   lock it securely with the ball nut.
8. Attach the glass shade to the bottom of the lamp holder, then
   lock it securely with a check ring until snug.
9. Install light bulbs (not included) in accordance with the
   fixture’s specifications.
10. Turn on the power to the junction box and test the
    fixture.

Following these instructions will ensure safe and proper
installation and usage of the product.

ASSEMBLING & INSTALLATION INSTRUCTIONS
The drawing shown may not exactly match the product enclosed. However, the installation instructions do apply to this product.
WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER. ATTENTION! COUPER LE COURANT AU FUSIBLE OU UN DISJONCTEUR.
MOUNTING THE FIXTURE (Fig.1)
1. Shut off the power at the circuit breaker box. Remove old fixture and all hardware from Junction Box.
2. Carefully unpack your new fixture and lay out all the parts on a clear area. Take care not to lose any small parts necessary for installation.
3. Thread the pipe screw part way into the center hole of the single bar and secure with hex nut.
4. Attach the single bar to the junction box using two box screws as shown. The side of the single bar marked “GND” must face out . The junction box is not included.
5. While holding the lamp body(A) towards the ceiling, connect the electrical wires as Shown in Fig.2, making sure that all wire nuts are secured. You may have to wrap the connections with electrical tape. If your outlet has a ground wire (green or bare copper), connect the fixture ground wire to it. Otherwise connect fixture’s ground wire directly to the Mounting strap with the green screw provided. After wires are connected, tuck them carefully inside the Junction Box.
6. Raise lamp body (A) onto the junction box, aligning pipe screw on single bar with center hole in lamp body and lock it securely with the ball nut(D).
7. Attach the glass shade(B) to bottom of the lamp holder, then lock it securely with check ring(C) until snug.
8. Install the light bulbs(not included) in accordance with the fixture’s specifications. NOTE: DO NOT EXCEED THE SPECIFIED WATTAGE!
Your installation is now complete. Return power to the junction box and test the fixture.

FIG.1

FIG.3

FIXTURE WIRES BLACK

FIXTURE WIRES WHITE

HOUSE WIRES Black
(Hot)

HOUSE
WIRES White (Neutral)

FIXTURE WIRES GREEN Thread (Ground)
HOUSE WIRES Green or Bare Copper(Ground)
