LH4354UHS-B1AG 43 Inch 4K UHD Professional Digital Signage Display
Product Information
The PROLITE LH4354UHS-B1AG is a display monitor with advanced
features and capabilities. It comes with an on-board CMS (Content
Management Software) that allows remote and secure control of
messaging and advertising. The SDM Slot provides an embedded PC
option for flexibility, security, and control. With the Signal
FailOver feature, the monitor automatically switches to the next
available input when there is no signal on the default input,
ensuring that your content is always actively displayed. The
monitor is WiFi-enabled, allowing remote content delivery through a
network or LAN control.
Thanks to Android OS, the display can be easily customized by
installing applications directly to it. The monitor also offers
various interfaces, connectors, and controls for seamless
connectivity and control.
Product Usage Instructions
Signal FailOver
The Signal FailOver feature automatically detects input sources
and switches to the next available input when there is no signal on
the default input. To prioritize inputs, including Browser, Media
Player, and Custom, follow these steps:
- Access the settings menu on the monitor.
- Select the “Signal FailOver” option.
- Choose the desired inputs in the priority order.
Android OS Customization
To customize the display using Android OS:
- Access the settings menu on the monitor.
- Select “Android OS” or “Applications”.
- Install the desired applications directly to the monitor.
Interfaces / Connectors / Controls
The PROLITE LH4354UHS-B1AG offers the following interfaces,
connectors, and controls:
- Analog signal input: VGA x1 (DVI-I: VGA+DVI)
- Digital signal input: DVI x1 (max. 2560×1440 @60Hz), HDMI x3
(v.2.0, max. 3840×2160 @60Hz), DisplayPort x1 (v.1.4, max.
3840×2160 @60Hz) - Audio input: Mini jack x1 (3.5mm)
- Monitor control input: RS-232c x1 (2.5mm sub-mini jack)
- Digital signal output: DisplayPort x1 (max. 3840×2160 @60Hz,
MST-out Daisy Chain v.1.2) - Audio output: Mini jack x1
- Monitor control output: RS-232c x1 (2.5mm sub-mini jack), IR
loop through x1 (3.5mm stereo mini) - HDCP support
- USB ports: x2 (v.2.0)
Features
The PROLITE LH4354UHS-B1AG offers the following features:
- Integrated software
- WiFi connectivity
- Hardware for additional functionality
- Max. non-stop operating time
- Anti-image retention
- Video wall / daisy chain support
- Media playback capabilities
- Housing with bezel
Power Management
The monitor has the following power management features:
- Power supply unit: internal AC 100 – 240V, 50/60Hz
- Power usage: 124W typical, 0.5W standby, 0.3W off mode
Please refer to the user manual for detailed instructions on
other features, mechanical specifications, accessories included,
sustainability, and dimensions/weight.
PROLITE LH4354UHS-B1AG
43″ 4K UHD Professional Digital Signage 24/7 display featuring Android OS, FailOver and Intel® SDM slot
Choose non-stop high performance and reliability with the ideal all-in-one signage solution for mission critical environments. The LH4354UHS from iiyama is a 500cd/m² high brightness professional large format display and can be operated in landscape or portrait orientation in continual around the clock environments 24/7 without any interruption. Its versatility can be adapted to your industry’s display needs. On-board Android OS means you can customize the display to your needs and install applications directly to it.
The on-board CMS (Content Management Software) gives you total control of your messaging and advertising remotely and safely. The SDM Slot provides embedded PC option for total flexibility, security and control, while the Signal FailOver feature ensures your content is always actively displayed through your choice of inputs. WiFi enabled, this series is ready for remote content delivery using your network or you can choose to utilise LAN control.
Signal FailOver
FailOver is a feature which automatically detects input sources. When there is no signal on the default input it will automatically switch to the next available input. FailOver allows customers to prioritize a number of inputs (incl. Browser, Media Player and Custom) and ensures your content is always actively displayed, assuring active content at all times.
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
01 DISPLAY CHARACTERISTICS
Design Diagonal Panel Native resolution Aspect ratio Panel brightness Static contrast Response time (GTG) Viewing zone Colour support Horizontal Sync Viewable area W x H Pixel pitch Bezel colour and finish
Thin bezel 42.5″, 108cm IPS, AG coated glass, matte finish, haze 25% 3840 x 2160 @60Hz (8.3 MegaPixels 4K UHD) 16:9 500 cd/m² 1200:1 8ms horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° 1.07B 8bit+FRC (NTSC 72%) 28 – 160kHz 941 x 529mm, 37 x 20.8″ 0.245mm black, matte
02 INTERFACES / CONNECTORS / CONTROLS
Analog signal input Digital signal input
Audio input Monitor control input
Digital signal output Audio output Monitor control output HDCP USB ports
VGA x1 (DVI-I: VGA+DVI)
DVI x1 (max. 2560×1440 @60Hz) HDMI x3 (v.2.0, max. 3840×2160 @60Hz) DisplayPort x1 (v.1.4, max. 3840×2160 @60Hz)
Mini jack x1 (3.5mm)
RS-232c x1 (2.5mm sub-mini jack) RJ45 (LAN) x1 IR x1 (3.5mm stereo mini)
DisplayPort x1 (max. 3840×2160 @60Hz, MST-out Daisy Chain v.1.2)
Mini jack x1 Speakers 2 x 10W
RS-232c x1 (2.5mm sub-mini jack) IR loop through x1 (3.5mm stereo mini)
v.2.2
x2 (v.2.0)
03 FEATURES
Integrated software WiFi Hardware Extra Max. non-stop operating time Anti image retention Video wall / daisy chain Media playback Housing (bezel)
Android 11 OS, iiSignage2 (available soon), FailOver, EShare yes (Built-in) CPU: A73*4+A53*4, GPU: G52 MP8, RAM: 4GB, ROM: 32GB Intel® SDM-S, micro SD card slot 24/7 yes Yes, (MST-output) yes metal
04 GENERAL
OSD languages Control buttons
EN, DE, FR, ES, IT, CN, RU, JP, CZ, NL, PL Power, Up, Down, Volume up, Volume down, Mute, Input, Menu
User controls
Plug&Play
05 MECHANICAL
Orientation Fanless design VESA mounting Operation temperature range Storage temperature range MTBF
06 ACCESSORIES INCLUDED
Cables Guides Other Remote control
07 POWER MANAGEMENT
Power supply unit Power supply Power usage
08 SUSTAINABILITY
Regulations Energy efficiency class (Regulation (EU) 2017/1369)
09 DIMENSIONS / WEIGHT
Product dimensions W x H x D Box dimensions W x H x D Weight (without box) Weight (with box) EAN code
picture (brightness, contrast, sharpness, black level, tint, colour, noise reduction, gamma selection, colour temperature, colour control, over scan, picture reset), screen (H. position, V. position, clock, clock phase, zoom mode, custom zoom, auto adjust, screen reset), Audio (balance, treble, bass, volume, audio out, maximum volume, minimum volume, mute, audio source, audio reset, audio out sync, speaker setting), configuration 1 (switch on state, panel saving, RS232routing, boot on source, WOL, configuration 1 reset, factory reset), Configuration 2 (OSD timeout, OSD H-Position, OSD V-position, rotation, information OSD, logo and animation logo setting, animation setting, monitor ID, group ID, monitor information, DP version, DP monitors, HDMI version, configuration 2 reset), advanced option (IR control, power LED light, keyboard control, tiling, off timer, schedule, HDMI with one wire, HDMI with one wire power off, FailOver, language, OSD transparency, power saving, SDM settings, advanced option reset), Android settings (network & internet, apps & notifications, display, signage display, security, language & input, date & time, about device) DDC2B
landscape, portrait yes 200 x 200mm 0°C – 40°C – 20°C – 60°C 50.000 hours (excluding backlight)
power, HDMI, RS-232c quick start guide, safety guide Stickers for screw holes, wire buckles yes (batteries included)
internal AC 100 – 240V, 50/60Hz 124W typical, 0.5W stand by, 0.3W off mode
CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH G
972 x 560 x 67.5mm 1070 x 690 x 139mm 9.1kg 18.6kg 4948570120970
All trademarks and registered trademarks acknowledged. E & O E. Specification subject to change without notice. All LCD’s comply with ISO-9241307:2008 in connection with pixel defects.
