TRAXXAS TRA101076-4-RED Ford F-150 Raptor R
Product Information
The product is a remote-controlled vehicle designed for off-road use. It is equipped with various parts and accessories to enhance its performance and durability. The chassis and attachments are made of high-quality materials to withstand rough terrains. The driveline components and differential components ensure smooth power transmission and stability. The front suspension and steering system provides excellent control and maneuverability. The LED lights add a realistic touch to the vehicle and can be controlled using the LED light harness.
Product Usage Instructions
- Before using the product, make sure to read the user manual thoroughly for proper assembly and operation instructions.
- Charge the vehicle’s batteries according to the instructions provided in the user manual.
- Attach the optional accessories, such as body clips, antenna caps, and LED light harnesses, if desired.
- Ensure that all parts are properly secured and tightened before operating the vehicle.
- Find an open area with enough space to drive the vehicle safely.
- Turn on the vehicle’s power switch and the remote control transmitter.
- Use the remote control transmitter to control the vehicle’s movement. The steering controls will allow you to turn the vehicle left or right, while the throttle controls will enable you to accelerate or brake.
- Practice driving the vehicle at low speeds to familiarize yourself with its handling and responsiveness.
- Avoid driving the vehicle on surfaces that may damage its components or hinder its performance, such as rough or uneven terrains.
- When not in use, store the vehicle in a safe and dry place to prevent damage or corrosion.
If you need any assistance or have further questions about the product, you can contact Traxxas customer support at 1-888-TRAXXAS or via email at [email protected].
- Parts shown in bold are optional accessories. Part categories and individual part listings are arranged alphabetically.
PARTS
| Bearings & Bushings | |
| 2728 | Ball bearings (5x8x2.5mm) (2) |
| 5119A | Ball bearings, black rubber sealed (10x15x4mm) (2) |
| 5119 | Ball bearings, blue rubber sealed (10x15x4mm) (2) |
| 5120 | Ball bearings, blue rubber sealed (12x18x4mm) (2) |
| 5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) |
| 5117 | Ball bearings, blue rubber sealed (6x12x4mm) (2) |
| 5118 | Ball bearings, blue rubber sealed (8x16x5mm) (2) |
| 5114 | Ball bearings, blue rubber shield (5x8x2.5mm) (2) |
| 3934 | Body clips, heavy duty (12) |
| 1985 | PTFE-coated Washers, 5x8x0.5mm (20) (use with ball bearings) |
| Body & Accessories | |
| 1926 | Antenna caps, vinyl (2)/ antenna spool |
| 1726 | Antenna, tube (1)/ vinyl antenna cap (1)/ wire retainer (1) |
| 10124 | Body mount, front/ adapter, front/ inserts (2) (for clipless body mounting) |
| 10125 | Body mount, rear/ inserts (2) (for clipless body mounting) |
| 10111 | Body, Ford Raptor R (clear, requires painting)/ window masks/ decal sheets |
| 10112-BLK | Body, Ford Raptor R, complete (black) (includes grille, tailgate trim, side mirrors, decals, & clipless mounting) (requires #10124 & 10125 body mounts) |
| 10112-BLUE | Body, Ford Raptor R, complete (blue) (includes grille, tailgate trim, side mirrors, decals, & clipless mounting) (requires #10124 & 10125 body mounts) |
| 10112-RED | Body, Ford Raptor R, complete (red) (includes grille, tailgate trim, side mirrors, decals, & clipless mounting) (requires #10124 & 10125 body mounts) |
| 10120 | Grille/ grille mount/ 3×10 BCS (7) (fully assembled, includes installed headlight lenses and decals) (fits #10111 body) |
| 10142 | Latch, body mount, front/ hood insert/ 3x8mm BCS (5) (for clipless body mounting) (attaches to #10111 body) |
| 10143 | Side mirrors (left & right)/ mirror mounts (left & right)/ 3x14mm BCS (2) (attaches to #10111 body) |
| 10144 | Latch, body mount, rear/ rear latch mount (2)/ 3x8mm BCS (4) (for clipless body mounting) (attaches to #10111 body) |
| 10121 | Tailgate trim/ trim mount/ 3x10mm BCS (7)/ decals (attaches to #10111 body) |
| Center Driveline | |
| 5119A | Ball bearings, black rubber sealed (10x15x4mm) (2) |
| 5119 | Ball bearings, blue rubber sealed (10x15x4mm) (2) |
| 5120 | Ball bearings, blue rubber sealed (12x18x4mm) (2) |
| 5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) |
| 5117 | Ball bearings, blue rubber sealed (6x12x4mm) (2) |
| 6893X | Bearing adapter, 6061-T6 aluminum (blue-anodized) (1)/10x15x4mm ball bearing (black rubber sealed) (1) (for slipper shaft) |
| 6893G | Bearing adapter, 6061-T6 aluminum (green-anodized) (1)/ 10x15x4mm ball bearing (black rubber sealed) (1) (for slipper shaft) |
| 10122 | Chassis/ adapter, center driveshaft cover |
| 6841 | Cover, center driveshaft (clear) |
| 6877A | Cover, gear (clear) |
| 6877 | Cover, gear/ motor wire hold-down clip |
| 6814 | Differential kit, center (complete) |
| 6888 | Drive hub, center, rear (1)/ 4×3 GS (1) |
| 6888X | Drive hub, front, hardened steel (1)/ screw pin (1) |
| 10155 | Driveshaft, center, 6061-T6 aluminum (blue-anodized) (274mm) |
| 6883 | Gear set, center differential (output gears (2)/ spider gears (2)/ spider gear shaft) |
| 5148 | Grease, white lithium |
| 6884 | Housing, center differential/ x-ring gaskets (2)/ ring gear gasket/ bushings (2)/ 5x10x0.5 TW (2)/ CCS 2.5×8 (4) |
| 6893 | Input shaft (slipper shaft)/ bearing adapter (1)/ pin (1) |
| 6890 | Plate, motor |
| 6890X | Plate, motor, 6061-T6 aluminum (blue-anodized) |
| 5352R | Rebuild kit (heavy duty), slipper clutch (steel disc/ aluminum friction pads (3)/ spring (1)/ 2×9.8mm pin/ 5x8mm MW/ 5.0mm NL (1)/ 4.0mm NL (1)) |
| 5352X | Rebuild kit, slipper clutch (steel disc/ friction pads (3)/ spring (1)/ 2×9.8mm pin/ 5x8mm MW/ 5.0mm NL (1)/ 4.0mm NL (1)) |
| 5552X | Rebuild kit, slipper clutch (steel disc/ friction pads (3)/ spring (2)/ pin/ 4.0mm NL (1)/ 5.0mm NL (1)) |
| 2575 | Screws, 3x6mm button-head machine (hex drive) (6) |
| 2554 | Screws, 3x6mm caphead machine (hex drive) (6) |
| 3932 | Screws, 3x6mm flat-head machine (hex drive) (6) |
| 1647 | Silicone Grease |
| 6878 | Slipper clutch, complete (for Slash 4×4) |
| 5556 | Slipper pressure plate & hub (aluminum alloy) |
| 5351 | Slipper pressure plate and hub (alloy) |
| Chassis & Attachments | |
| 8327 | Battery hold-down/ battery clip/ hold-down post/screw pin (for 256mm wheelbase) |
| 10124 | Body mount, front/ adapter, front/ inserts (2) (for clipless body mounting) |
| 10125 | Body mount, rear/ inserts (2) (for clipless body mounting) |
| 7424 | Box, receiver (sealed)/ foam pads/ 2.5x12mm CS (2)/ 3x6mm CS (2)/ 3x12mm BCS (2) |
| 10151 | Bumper, front/ bumper mount, front/ light covers (left & right)/ 2.5x10mm BCS (4) (fits Ford Raptor R) |
| 10152 | Bumper, rear/ bumper mounts, rear (upper & lower) (fits Ford Raptor R) |
| 10150 | Chassis/ adapter, center driveshaft cover |
| 6841 | Cover, center driveshaft (clear) |
| 7423 | Nerf bars, chassis (2) |
| 7425 | Seal kit, receiver box (includes o-ring, seals, and silicone grease) |
| Differential Components | |
| 5119 | Ball bearings, blue rubber sealed (10x15x4mm) (2) |
| 5117 | Ball bearings, blue rubber sealed (6x12x4mm) (2) |
| 5118 | Ball bearings, blue rubber sealed (8x16x5mm) (2) |
| 5381 | Carrier, differential/ x-ring gaskets (2)/ ring gear gasket/ 6x10x0.5 TW |
| 6780 | Differential kit, center (complete) |
| 6814 | Differential kit, center (complete) |
| 5136X | Differential oil kit (1 each: 10K, 30K, 50K weights) |
| 6788 | Differential, front (complete with pinion gear and differential plastics) (fits 1/10-scale Rally & 4X4 VXL models: Slash®, Stampede®, Rustler®) (13/37 ratio) |
| 6789 | Differential, rear (complete with pinion gear and differential plastics) (fits 1/10-scale Rally & 4X4 VXL models: Slash®, Stampede®, Rustler®) (13/37 ratio) |
| 6882X | Gear set, differential (output gears (2)/ spider gears (2)/ spider gear shaft, carrier support) |
| 6783 | Gear set, differential (spider gears (4)/ spider gear shaft (2)) |
| 6781 | Housing, center differential (aluminum)/ x-ring gaskets (2)/ ring gear gasket (1)/ bushings (4)/ 5x10x0.5 PTW (1)/ 2.5×10 CCS (with threadlock) (4) |
| 6881 | Housings, differential, front |
| 6880 | Housings, differential, rear |
| 6782 | Output gears, center differential, hardened steel (2) |
| 5379X | Ring gear, differential/ pinion gear, differential |
| 5379R | Ring gear, differential/ pinion gear, differential (machined, spiral cut) (front) |
| 6879R | Ring gear, differential/ pinion gear, differential (machined, spiral cut) (rear) |
| 6879 | Ring gear, differential/ pinion gear, differential (rear) |
| 3965 | Screws, 2.5x8mm cap-head machine (6) |
| 1647 | Silicone Grease |
| Driveline Components | |
| 5119A | Ball bearings, black rubber sealed (10x15x4mm) (2) |
| 5119 | Ball bearings, blue rubber sealed (10x15x4mm) (2) |
| 5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) |
| 9059X | Cross pin (2)/ drive pin (2) (repairs 1 axle shaft) |
| 9057X | Differential output shafts, steel-splined constant-velocity (2) |
| 9057 | Differential output yoke assembly, extreme heavy duty (2) (left or right, front or rear) (assembled with external-splined half shaft) (for use with #9080 upgrade kit) |
| 6828A | Differential output yoke assembly, extreme heavy duty (2) (left or right, front or rear) (assembled with external-splined half shaft)/ screw pin (2) |
| 6828X | Differential output yokes, heavy duty (2)/ screw pin (2) |
| 9051 | Driveshaft assembly, front, extreme heavy duty with 6mm axle (1)/ screw pin (1) (left or right) (fully assembled, ready to install) (for use with #9080 upgrade kit) |
| 9052 | Driveshaft assembly, rear, extreme heavy duty with 6mm axle (1)/ screw pin (1) (left or right) (fully assembled, ready to install) (for use with #9080 upgrade kit) |
| 10155 | Driveshaft, center, 6061-T6 aluminum (blue-anodized) (274mm) |
| 9051R | Driveshafts, front, extreme heavy duty, steel-spline constant- velocity with 6mm stub axles (complete assembly) (2) (for use with #9080 upgrade kit) |
| 9052R | Driveshafts, rear, extreme heavy duty, steel-spline constant- velocity with 6mm stub axles (complete assembly) (2) (for use with #9080 upgrade kit) |
| 9056X | Half shaft, internal splined (steel-spline constant velocity) (1) |
| 9058X | Rebuild kit, steel-splined constant-velocity driveshafts (includes pins and hardware for one axle shaft) |
| 9056 | Stub axle assembly, front, outer, extreme heavy duty (1) (left or right) (assembled with internal-splined half shaft) (for use with #9080 upgrade kit) |
| 5452 | U-joints, driveshaft (carrier (4)/ 4.5mm cross pin (4)/ 3mm cross pin (4)/ e-clips (20)) (metal parts for 2 driveshafts) |
| Extreme HD Upgrade Kit | |
| 9016 | Body mounts, front & rear, extreme heavy duty (for use with #9080 upgrade kit) |
| 9050 | Carriers, stub axle, rear, extreme heavy duty, black (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050X | Carriers, stub axle, rear, extreme heavy duty, blue (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050-GRAY | Carriers, stub axle, rear, extreme heavy duty, gray (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050G | Carriers, stub axle, rear, extreme heavy duty, green (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050T | Carriers, stub axle, rear, extreme heavy duty, orange (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050R | Carriers, stub axle, rear, extreme heavy duty, red (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032 | Caster blocks (c-hubs), extreme heavy duty, black (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032X | Caster blocks (c-hubs), extreme heavy duty, blue (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032-GRAY | Caster blocks (c-hubs), extreme heavy duty, gray (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032G | Caster blocks (c-hubs), extreme heavy duty, green (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032T | Caster blocks (c-hubs), extreme heavy duty, orange (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032R | Caster blocks (c-hubs), extreme heavy duty, red (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9057 | Differential output yoke assembly, extreme heavy duty (2) (left or right, front or rear) (assembled with external-splined half shaft) (for use with #9080 upgrade kit) |
| 9051 | Driveshaft assembly, front, extreme heavy duty with 6mm axle (1)/ screw pin (1) (left or right) (fully assembled, ready to install) (for use with #9080 upgrade kit) |
| 9052 | Driveshaft assembly, rear, extreme heavy duty with 6mm axle (1)/ screw pin (1) (left or right) (fully assembled, ready to install) (for use with #9080 upgrade kit) |
| 9051R | Driveshafts, front, extreme heavy duty, steel-spline constant- velocity with 6mm stub axles (complete assembly) (2) (for use with #9080 upgrade kit) |
| 9052R | Driveshafts, rear, extreme heavy duty, steel-spline constant- velocity with 6mm stub axles (complete assembly) (2) (for use with #9080 upgrade kit) |
| 9080 | Outer Driveline & Suspension Upgrade Kit, extreme heavy duty, black |
| 9080X | Outer Driveline & Suspension Upgrade Kit, extreme heavy duty, blue |
| 9080-GRAY | Outer Driveline & Suspension Upgrade Kit, extreme heavy duty, gray |
| 9080G | Outer Driveline & Suspension Upgrade Kit, extreme heavy duty, green |
| 9080T | Outer Driveline & Suspension Upgrade Kit, extreme heavy duty, orange |
| 9080R | Outer Driveline & Suspension Upgrade Kit, extreme heavy duty, red |
| 9043 | Screw pins, 3x16mm, extreme heavy duty (6) (for use with #9080 upgrade kit) |
| 9038 | Shock tower, front, extreme heavy duty, black (for use with #9080 upgrade kit) |
| 9038X | Shock tower, front, extreme heavy duty, blue (for use with #9080 upgrade kit) |
| 9038-GRAY | Shock tower, front, extreme heavy duty, gray (for use with #9080 upgrade kit) |
| 9038G | Shock tower, front, extreme heavy duty, green (for use with #9080 upgrade kit) |
| 9038T | Shock tower, front, extreme heavy duty, orange (for use with #9080 upgrade kit) |
| 9038R | Shock tower, front, extreme heavy duty, red (for use with #9080 upgrade kit) |
| 9039 | Shock tower, rear, extreme heavy duty, black (for use with #9080 upgrade kit) |
| 9039X | Shock tower, rear, extreme heavy duty, blue (for use with #9080 upgrade kit) |
| 9039-GRAY | Shock tower, rear, extreme heavy duty, gray (for use with #9080 upgrade kit) |
| 9039G | Shock tower, rear, extreme heavy duty, green (for use with #9080 upgrade kit) |
| 9039T | Shock tower, rear, extreme heavy duty, orange (for use with #9080 upgrade kit) |
| 9039R | Shock tower, rear, extreme heavy duty, red (for use with #9080 upgrade kit) |
| 9037 | Steering blocks, extreme heavy duty, black (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037X | Steering blocks, extreme heavy duty, blue (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037-GRAY | Steering blocks, extreme heavy duty, gray (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037G | Steering blocks, extreme heavy duty, green (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037T | Steering blocks, extreme heavy duty, orange (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037R | Steering blocks, extreme heavy duty, red (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9056 | Stub axle assembly, front, outer, extreme heavy duty (1) (left or right) (assembled with internal-splined half shaft) (for use with #9080 upgrade kit) |
| 9055 | Stub axle assembly, rear, outer, extreme heavy duty (1) (left or right) (assembled with internal-splined half shaft) (for use with #9080 upgrade kit) |
| 9054 | Stub axle, front, 6mm, extreme heavy duty (for use with #9051R steel CV driveshafts) |
| 9053 | Stub axle, rear, 6mm, extreme heavy duty (for use with #9052R steel CV driveshafts) |
| 9042 | Suspension pin set, extreme heavy duty, complete (front and rear) (3x52mm (4), 3x32mm (2), 3x40mm (2)) (for use with #9080 upgrade kit) |
| 9042X | Suspension pin set, extreme heavy duty, complete (front and rear) (hardened steel) (3x52mm (4), 3x32mm (2), 3x40mm (2))/ M2.5×0.45mm NL (8) (for use with #9080 upgrade kit) |
| 9069 | Wheel hubs, 12mm hex (steel), extreme heavy duty (4)/ 2×9.8mm pin (4) (for use with #9080 upgrade kit and 6mm axles) |
| Front Suspension & Steering | |
| 6823 | Bulkhead tie bars, front & rear, aluminum (blue-anodized) |
| 6823G | Bulkhead tie bars, front & rear, aluminum (green-anodized) |
| 6823R | Bulkhead tie bars, front & rear, aluminum (red-anodized) |
| 6830X | Bulkhead, front |
| 3643X | Camber links, front (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3643G | Camber links, front (TUBES green-anodized, 7075-T6 aluminum, stronger than Titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3643R | Camber links, front (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 9032 | Caster blocks (c-hubs), extreme heavy duty, black (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032X | Caster blocks (c-hubs), extreme heavy duty, blue (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 ufpgrade kit) |
| 9032-GRAY | Caster blocks (c-hubs), extreme heavy duty, gray (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032G | Caster blocks (c-hubs), extreme heavy duty, green (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032T | Caster blocks (c-hubs), extreme heavy duty, orange (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9032R | Caster blocks (c-hubs), extreme heavy duty, red (left & right)/ 3x32mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 6845A | Drag link, machined 6061-T6 aluminum (blue-anodized) |
| 6845G | Drag link, machined 6061-T6 aluminum (green-anodized) |
| 6845T | Drag link, machined 6061-T6 aluminum (orange-anodized) |
| 6845R | Drag link, machined 6061-T6 aluminum (red-anodized) |
| 6895 | Linkage, front sway bar (Slash 4×4) (2) (assembled with rod ends, hollow balls and ball studs) |
| 6897 | Linkage, rear sway bar (Slash 4×4) (2) (assembled with rod ends, hollow balls and ball studs) |
| 6846 | Linkage, steering (Revo) (3x20mm turnbuckle) (1)/ rod ends (2)/ hollow balls (2) |
| 3646 | Screws, 3x15mm flat-head machine (hex drive) (6) |
| 9038 | Shock tower, front, extreme heavy duty, black (for use with #9080 upgrade kit) |
| 9038X | Shock tower, front, extreme heavy duty, blue (for use with #9080 upgrade kit) |
| 9038-GRAY | Shock tower, front, extreme heavy duty, gray (for use with #9080 upgrade kit) |
| 9038G | Shock tower, front, extreme heavy duty, green (for use with #9080 upgrade kit) |
| 9038T | Shock tower, front, extreme heavy duty, orange (for use with #9080 upgrade kit) |
| 9038R | Shock tower, front, extreme heavy duty, red (for use with #9080 upgrade kit) |
| 6845X | Steering bellcranks/ servo saver/ servo saver spring/ servo spring retainer/servo horn, steering |
| 9037 | Steering blocks, extreme heavy duty, black (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037X | Steering blocks, extreme heavy duty, blue (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037-GRAY | Steering blocks, extreme heavy duty, gray (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037G | Steering blocks, extreme heavy duty, green (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037T | Steering blocks, extreme heavy duty, orange (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9037R | Steering blocks, extreme heavy duty, red (left & right)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9056 | Stub axle assembly, front, outer, extreme heavy duty (1) (left or right) (assembled with internal-splined half shaft) (for use with #9080 upgrade kit) |
| 6854X | Stub axles, front, heavy duty (2)/ yokes (2)/ pins (4) |
| 3655P | Suspension arms, blue, front/rear (left & right), heavy duty (2) |
| 3655R | Suspension arms, front/rear (left & right), heavy duty (2) |
| 3655G | Suspension arms, green, front/rear (left & right), heavy duty (2) |
| 3655T | Suspension arms, orange, front/rear (left & right), heavy duty (2) |
| 3655L | Suspension arms, red, front/rear (left & right), heavy duty (2) |
| 6834 | Suspension pin set, complete (front and rear) |
| 9042 | Suspension pin set, extreme heavy duty, complete (front and rear) (3x52mm (4), 3x32mm (2), 3x40mm (2)) (for use with #9080 upgrade kit) |
| 9042X | Suspension pin set, extreme heavy duty, complete (front and rear) (hardened steel) (3x52mm (4), 3x32mm (2), 3x40mm (2))/ M2.5×0.45mm NL (8) (for use with #9080 upgrade kit) |
| 6898 | Sway bar kit (front and rear) (includes front and rear sway bars and adjustable linkage) |
| 6742X | Toe links (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 6742G | Toe links (TUBES green-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 6742R | Toe links (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 3643 | Turnbuckles, camber link, 49mm (82mm center to center) (assembled with rod ends and hollow balls) (1 left, 1 right) |
| 5539 | Turnbuckles, camber links, 58mm (assembled with rod ends and hollow balls) (2) |
| 6896 | Wires, sway bar (front & rear, hard & soft) (Slash 4X4)/ 3×6 FCS (4) |
| Hardware | |
| 1926 | Antenna caps, vinyl (2)/ antenna spool |
| 1726 | Antenna, tube (1)/ vinyl antenna cap (1)/ wire retainer (1) |
| 3935 | Body clip (mounting clip), angled, 90-degrees (10) |
| 3935A | Body clip (mounting clip), angled, 90-degrees (black) (10) |
| 3934 | Body clips, heavy duty (12) |
| 1589 | Double-sided adhesive tape (25mm x 25mm) |
| 2745 | Nuts, 3mm nylon locking (12) |
| 3647 | Nuts, 4mm flanged nylon locking (steel, serrated) (8) |
| 1747 | Nuts, 4mm nylon locking (10) |
| 1747A | Nuts, aluminum, flanged, serrated (4mm) (red-anodized) (4) |
| 1985 | PTFE-coated Washers, 5x8x0.5mm (20) (use with ball bearings) |
| 3981 | PTFE-coated Washers, 6×9.5×0.5mm (10) (use with ball bearings) |
| 5525 | Rod ends (12)/ hollow balls (12) |
| 2742X | Rod ends, short (6)/ hollow balls (6) |
| 3347 | Screws, 2.5x5mm button-head machine (hex drive) (6) |
| 3215 | Screws, 2.5x6mm cap-head machine (hex drive) (6) |
| 3965 | Screws, 2.5x8mm cap-head machine (6) |
| 2577 | Screws, 3x10mm button-head machine (hex drive) (6) |
| 2578 | Screws, 3x12mm button-head machine (hex drive) (6) |
| 2552 | Screws, 3x12mm countersunk machine (6) (hex drive) |
| 2579 | Screws, 3x15mm button-head machine (hex drive) (6) |
| 2586 | Screws, 3x15mm cap-head machine (hex drive) (6) |
| 3646 | Screws, 3x15mm flat-head machine (hex drive) (6) |
| 2583 | Screws, 3×18 button-head machine (hex drive) (6) |
| 2580 | Screws, 3x20mm button-head machine (hex drive) (6) |
| 2591 | Screws, 3x23mm button-head machine (hex drive) (6) |
| 2582 | Screws, 3x30mm button-head machine (hex drive) (6) |
| 2592 | Screws, 3x40mm button-head machine (hex drive) (6) |
| 2575 | Screws, 3x6mm button-head machine (hex drive) (6) |
| 2534 | Screws, 3x6mm countersunk machine (6) (hex drive) |
| 3932 | Screws, 3x6mm flat-head machine (hex drive) (6) |
| 2576 | Screws, 3x8mm button-head machine (hex drive) (6) |
| 1552 | Screws, 3x8mm cap-head machine (hex drive) (6)/washers (6)/ wrench |
| 3931 | Screws, 3x8mm flat-head machine (hex drive) (6) |
| 3937 | Screws, 4x12mm button-head machine (hex drive) (6) |
| 2542 | Screws, 4x12mm countersunk machine (hex drive) (6) |
| 2546 | Screws, 4x15mm countersunk machine (hex drive) (6) |
| 2743 | Set (grub) screws, 3mm hardened (12) |
| 3642X | Shoulder screws, Ultra Shocks (3×12 hex drive) (6) |
| 2754 | Stub axle pins (4) |
| 2746 | Washers, 3x6mm metal (12) |
| LED Lights | |
| 10156 | LED light harness, front (fits #10151 bumper) (requires #2263 Y- harness) |
| 5893 | LED light harness, rear (requires #5838, 6737X, or 6836 rear bumper) |
| 2263 | Y-harness, BEC to LED light set |
| Motors & Electronics | |
| 1726 | Antenna, tube (1)/ vinyl antenna cap (1)/ wire retainer (1) |
| 2260 | BEC assembly (complete) (12.6 volts (3s LiPo) maximum input voltage) |
| 3340 | Cooling fan, Velineon® VXL-3s ESC |
| 2072A | Gear set (for 2070, 2075 servos) |
| 2252 | Gear set, metal (for 2250, 2255 servos) |
| 2272 | Gear set, metal (for 2270 waterproof servo) |
| 3458 | Heat sink (fits #3351R and #3461 motors) |
| 3354R | Motor cover, endbell (Velineon® 3500) |
| 6860A | Motor mount (assembled with 3×6 flat-head machine screw)/ 3.0mm NL (1) |
| 6860R | Motor mount, 6061-T6 aluminum (blue-anodized) |
| 3351R | Motor, Velineon® 3500, brushless (assembled with 12-gauge wire and gold-plated bullet connectors) |
| 3352R | Rebuild kit, Velineon® 3500 (includes plastic endbell, 5x11x4mm ball bearings (2), 2.5x5mm BCS (with threadlock) (4), rear bushing) |
| 3347 | Screws, 2.5x5mm button-head machine (hex drive) (6) |
| 3932 | Screws, 3x6mm flat-head machine (hex drive) (6) |
| 2254 | Servo case, aluminum (middle) (blue-anodized) (for 2250 servo) |
| 2253 | Servo case, aluminum (middle) (red-anodized) (for 2255 servo) |
| 2251 | Servo case, plastic (top, middle, bottom)/ gaskets/ hardware (for 2250, 2255 servos) |
| 2271 | Servo case/ gaskets (for 2270 waterproof servo) |
| 2074 | Servo case/gaskets (for 2056 and 2075 waterproof servos) |
| 2075R | Servo, digital high-speed, metal gear (ball bearing), waterproof |
| 2075 | Servo, digital high-torque (ball bearing), waterproof |
| 2250 | Servo, digital high-torque 330 coreless, metal gear (ball bearing), waterproof |
| 2255 | Servo, digital high-torque 400 brushless, metal gear (ball bearing), waterproof |
| 2270 | Servo, digital high-torque, metal gear (ball bearing), waterproof |
| 2075X | Servo, digital high-torque, metal gear (ball bearing), waterproof |
| 3350R | Velineon® VXL-3s Brushless Power System, waterproof (includes VXL-3s waterproof ESC , Velineon® 3500 motor, and speed control mounting plate (part #3725)) |
| 3355R | VXL-3s Waterproof Electronic Speed Control (brushless) (fwd/rev/brake) |
| Radio System, Batteries & Chargers | |
| 2849X | 4000mah 11.1v 3-Cell 25C LiPo Battery |
| 2872X | 5000mah 11.1v 3-Cell 25C LiPo Battery |
| 2857X | 6400mah 11.1v 3-Cell 25C LiPo Battery |
| 2869X | 7600mah 7.4v 2-Cell 25C LiPo Battery |
| 2976 | AC to DC adapter |
| 2938X | Adapter, Traxxas® iD® LiPo battery (adapts Traxxas® iD® batteries to separate balance ports) |
| 2943 | Battery charge indicators, green (4), grey (4), blue (4) |
| 6548 | Battery door, TQ 2.4 transmitter (replacement for #6516, 6517 transmitter) |
| 2914 | Battery, Power Cell AA Alkaline (4) |
| 2923X | Battery, Power Cell, 3000mAh (NiMH, 7-C flat, 8.4V) |
| 2926X | Battery, Power Cell, 3000mAh (NiMH, 7-C hump, 8.4V) |
| 2940X | Battery, Series 3 Power Cell, 3300mAh (NiMH, 7-C flat, 8.4V) |
| 2941X | Battery, Series 3 Power Cell, 3300mAh (NiMH, 7-C hump, 8.4V) |
| 2950X | Battery, Series 4 Power Cell, 4200mAh (NiMH, 7-C flat, 8.4V) |
| 2951X | Battery, Series 4 Power Cell, 4200mAh (NiMH, 7-C hump, 8.4V) |
| 2960X | Battery, Series 5 Power Cell, 5000mAh (NiMH, 7-C flat, 8.4V) |
| 2961X | Battery, Series 5 Power Cell, 5000mAh (NiMH, 7-C hump, 8.4V) |
| 2983 | Battery/charger completer pack (includes #2969 2-amp NiMH peak detecting AC charger (1), #2923X 3000mAh 8.4V 7-cell NiMH iD® battery (1)) |
| 2992 | Battery/charger completer pack (includes #2970 iD® charger (1), #2843X 5800mAh 7.4V 2-cell 25C LiPo iD® battery (1)) |
| 2260 | BEC assembly (complete) (12.6 volts (3s LiPo) maximum input voltage) |
| 2975 | Charger, D/C, 4 amp (6 – 7 cell, 7.2 – 8.4 volt, NiMH) |
| 2972 | Charger, EZ-Peak Dual, 100W, NiMH/LiPo with iD Auto Battery Identification |
| 2973 | Charger, EZ-Peak Live Dual, 200W, NiMH/LiPo with iD Auto Battery Identification |
| 2970 | Charger, EZ-Peak Plus, 4 amp, NiMH/LiPo with iD Auto Battery Identification |
| 2971 | Charger, EZ-Peak® Live, 100W, NiMH/LiPo with iD® Auto Battery Identification |
| 2981 | Charger, EZ-Peak® Plus 4s, 8 amp, NiMH/LiPo with iD® Auto Battery Identification |
| 6525 | Communication link, telemetry expander |
| 6512 | Cover plate, Traxxas® Link Bluetooth® module |
| 2978 | Fuse, D/C charger, 5A (2) (for #2974, 2975, 2977) |
| 2072A | Gear set (for 2070, 2075 servos) |
| 2252 | Gear set, metal (for 2250, 2255 servos) |
| 2272 | Gear set, metal (for 2270 waterproof servo) |
| 2968X | LiPo cell voltage checker/balancer (includes #2938X adapter for Traxxas® iD® batteries) |
| 2968 | LiPo cell voltage checker/balancer (requires #2938X adapter for Traxxas® iD® batteries) |
| 6555 | Mount, telemetry expander (fits Slash 4X4, Stampede® 4X4, Rally, Jato®) |
| 6535 | Mount, temperature sensor (electric motors)/ wire tie/ thermal pad |
| 6533 | Receiver, micro, TQi 2.4GHz with telemetry & TSM® (5-channel) |
| 3932 | Screws, 3x6mm flat-head machine (hex drive) (6) |
| 6552 | Seal kit, expander box (includes o-ring, seals, and silicone grease) |
| 6526 | Sensor, auto-detectable, temperature |
| 6527 | Sensor, auto-detectable, voltage |
| 6520 | Sensor, RPM (long)/ 3x4mm BCS (1)/ 3×4 GS (1) |
| 6521 | Sensor, temperature and voltage (long) |
| 2254 | Servo case, aluminum (middle) (blue-anodized) (for 2250 servo) |
| 2253 | Servo case, aluminum (middle) (red-anodized) (for 2255 servo) |
| 2251 | Servo case, plastic (top, middle, bottom)/ gaskets/ hardware (for 2250, 2255 servos) |
| 2271 | Servo case/ gaskets (for 2270 waterproof servo) |
| 2074 | Servo case/gaskets (for 2056 and 2075 waterproof servos) |
| 2075R | Servo, digital high-speed, metal gear (ball bearing), waterproof |
| 2075 | Servo, digital high-torque (ball bearing), waterproof |
| 2250 | Servo, digital high-torque 330 coreless, metal gear (ball bearing), waterproof |
| 2255 | Servo, digital high-torque 400 brushless, metal gear (ball bearing), waterproof |
| 2270 | Servo, digital high-torque, metal gear (ball bearing), waterproof |
| 2075X | Servo, digital high-torque, metal gear (ball bearing), waterproof |
| 6553X | Telemetry Expander 2.0 and GPS module 2.0, TQi radio system |
| 6550X | Telemetry expander 2.0, TQi radio system (for use only with #6551X GPS module) |
| 6551X | Telemetry GPS module 2.0, TQi radio system (for use only with #6550X telemetry expander) |
| 6539 | Telemetry trigger magnet holder, center differential/ magnet, 5x2mm (1)/ 3x8mm BCS (3) (for use with #6814 center differential) |
| 6538 | Telemetry trigger magnet holders, spur gear/ magnet, 5x2mm (1)/ 3x8mm CCS (3)/ 3x10mm CCS (3) |
| 6540 | Telemetry trigger magnet, 5X2mm (1) |
| 6509R | TQi 2.4 GHz High Output radio system, 2-channel, Traxxas® Link enabled, TSM® (2-ch transmitter, 5-ch micro receiver) |
| 6507R | TQi 2.4 GHz High Output radio system, 4-channel with Traxxas® Link Bluetooth® module, TSM® (4-ch transmitter, 5-ch micro receiver) |
| 6528 | Transmitter, TQi Traxxas® Link enabled, 2.4GHz high output, 2- channel (transmitter only) |
| 6529 | Transmitter, TQi Traxxas® Link enabled, 2.4GHz high output, 3-channel (transmitter only) |
| 6530 | Transmitter, TQi Traxxas® Link enabled, 2.4GHz high output, 4-channel (transmitter only) |
| 6511 | Traxxas® Link Bluetooth® module |
| 3355R | VXL-3s Waterproof Electronic Speed Control (brushless) (fwd/rev/brake) |
| Ready-To-Race Model | |
| 101076-4 | Ford® F-150® Raptor R™ 4X4: 1/10 Scale 4WD Truck with TQi™ Traxxas Link™ Enabled 2.4GHz Radio System & Traxxas Stability Management (TSM)® |
| Rear Suspension | |
| 6823 | Bulkhead tie bars, front & rear, aluminum (blue-anodized) |
| 6823G | Bulkhead tie bars, front & rear, aluminum (green-anodized) |
| 6823R | Bulkhead tie bars, front & rear, aluminum (red-anodized) |
| 6829 | Bulkhead, rear |
| 3644X | Camber links, rear (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644G | Camber links, rear (TUBES green-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644R | Camber links, rear (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 9050 | Carriers, stub axle, rear, extreme heavy duty, black (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050X | Carriers, stub axle, rear, extreme heavy duty, blue (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050-GRAY | Carriers, stub axle, rear, extreme heavy duty, gray (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050G | Carriers, stub axle, rear, extreme heavy duty, green (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050T | Carriers, stub axle, rear, extreme heavy duty, orange (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9050R | Carriers, stub axle, rear, extreme heavy duty, red (left & right)/ 3x41mm hinge pins (2)/ 3x20mm BCS (2) (for use with #9080 upgrade kit) |
| 9039 | Shock tower, rear, extreme heavy duty, black (for use with #9080 upgrade kit) |
| 9039X | Shock tower, rear, extreme heavy duty, blue (for use with #9080 upgrade kit) |
| 9039-GRAY | Shock tower, rear, extreme heavy duty, gray (for use with #9080 upgrade kit) |
| 9039G | Shock tower, rear, extreme heavy duty, green (for use with #9080 upgrade kit) |
| 9039T | Shock tower, rear, extreme heavy duty, orange (for use with #9080 upgrade kit) |
| 9039R | Shock tower, rear, extreme heavy duty, red (for use with #9080 upgrade kit) |
| 9056 | Stub axle assembly, front, outer, extreme heavy duty (1) (left or right) (assembled with internal-splined half shaft) (for use with #9080 upgrade kit) |
| 9055 | Stub axle assembly, rear, outer, extreme heavy duty (1) (left or right) (assembled with internal-splined half shaft) (for use with #9080 upgrade kit) |
| 9054 | Stub axle, front, 6mm, extreme heavy duty (for use with #9051R steel CV driveshafts) |
| 9053 | Stub axle, rear, 6mm, extreme heavy duty (for use with #9052R steel CV driveshafts) |
| 3655P | Suspension arms, blue, front/rear (left & right), heavy duty (2) |
| 3655R | Suspension arms, front/rear (left & right), heavy duty (2) |
| 3655G | Suspension arms, green, front/rear (left & right), heavy duty (2) |
| 3655T | Suspension arms, orange, front/rear (left & right), heavy duty (2) |
| 3655L | Suspension arms, red, front/rear (left & right), heavy duty (2) |
| 9042 | Suspension pin set, extreme heavy duty, complete (front and rear) (3x52mm (4), 3x32mm (2), 3x40mm (2)) (for use with #9080 upgrade kit) |
| 9042X | Suspension pin set, extreme heavy duty, complete (front and rear) (hardened steel) (3x52mm (4), 3x32mm (2), 3x40mm (2))/ M2.5×0.45mm NL (8) (for use with #9080 upgrade kit) |
| 3644 | Turnbuckles, camber link, 39mm (69mm center to center) (assembled with rod ends and hollow balls) (1 left, 1 right) (fits front & rear on Slash, rear on Slash 4X4) |
| Shock Oil | |
| 5031 | Oil, shock (20 wt, 200 cSt, 60cc) (silicone) |
| 5032 | Oil, shock (30 wt, 350 cSt, 60cc) (silicone) |
| 5033 | Oil, shock (40 wt, 500 cSt, 60cc) (silicone) |
| 5034 | Oil, shock (50 wt, 600 cSt, 60cc) (silicone) |
| 5035 | Oil, shock (60 wt, 700 cSt, 60cc) (silicone) |
| 5036 | Oil, shock (70 wt, 900 cSt, 60cc) (silicone) |
| 5037 | Oil, shock (80 wt, 1,000 cSt, 60cc) (silicone) |
| 5029 | Shock oil bottle (60cc) (for mixing shock oil) |
| 5038X | Shock oil set (includes 20 wt, 30 wt, 40 wt, 50 wt, 60 wt, 70 wt, & 80 wt premium shock oils with spinning carousel rack) |
| 5038 | Spinning carousel rack |
| Shocks (GTR) | |
| 7466X | Body, GTR long (hard-anodized, PTFE-coated aluminum) (1) |
| 7466 | Body, GTR long shock, aluminum (blue-anodized) (PTFE- coated bodies) (1) |
| 7466G | Body, GTR long shock, aluminum (green-anodized) (PTFE- coated bodies) (1) |
| 7466A | Body, GTR long shock, aluminum (orange-anodized) (PTFE- coated bodies) (1) |
| 7466R | Body, GTR long shock, aluminum (red-anodized) (PTFE- coated bodies) (1) |
| 7467X | Body, GTR xx-long (hard-anodized, PTFE-coated aluminum) (1) |
| 7467 | Body, GTR xx-long shock, aluminum (blue-anodized) (PTFE- coated bodies) (1) |
| 7467G | Body, GTR xx-long shock, aluminum (green-anodized) (PTFE- coated bodies) (1) |
| 7467A | Body, GTR xx-long shock, aluminum (orange-anodized) (PTFE-coated bodies) (1) |
| 7467R | Body, GTR xx-long shock, aluminum (red-anodized) (PTFE- coated bodies) (1) |
| 7468X | Caps & spring retainers, GTR shock (upper cap (2)/ hollow balls (4)/ bottom cap (2)/ upper retainer (2)/ lower retainer (2)) |
| 7468 | Caps and spring retainers, GTR long/xx-long shock (upper cap (2)/ hollow balls (4)/ bottom cap (2)/ upper retainer (2)/ lower retainer (2)) |
| 5475 | Multi-tool (plastic) |
| 5158 | Nuts, 2.5mm nylon locking (12) |
| 7463 | Rebuild kit, GTR long/xx-long shocks (x-rings, bladders, pistons, piston nuts, shock rod ends, hollow balls) (renews 2 shocks) |
| 5469 | Rod ends (GTR shocks) |
| 7464T | Shaft, GTR long, TiN-coated (2) |
| 7461 | Shocks, GTR long blue-anodized, PTFE-coated bodies with TiN shafts (fully assembled, without springs) (2) |
| 7461G | Shocks, GTR long green-anodized, PTFE-coated bodies with TiN shafts (fully assembled, without springs) (2) |
| 7461X | Shocks, GTR long, hard-anodized, PTFE-coated bodies with TiN shafts (assembled) (2) (without springs) |
| 7462 | Shocks, GTR xx-long blue-anodized, PTFE-coated bodies with TiN shafts (fully assembled, without springs) (2) |
| 7462G | Shocks, GTR xx-long green-anodized, PTFE-coated bodies with TiN shafts (fully assembled, without springs) (2) |
| 7462X | Shocks, GTR xx-long, hard-anodized, PTFE-coated bodies with TiN shafts (assembled) (2) (without springs) |
| 8459 | Spring retainers, lower (captured) (4)/ 2.5×10 CS (4) |
| 7440 | Spring, shock, white (GTR long) (0.623 rate orange) (1 pair) |
| 7441 | Spring, shock, white (GTR long) (0.653 rate green) (1 pair) |
| 7444 | Spring, shock, white (GTR long) (0.767 rate black) (1 pair) |
| 7445 | Spring, shock, white (GTR long) (0.810 rate pink) (1 pair) |
| 7448 | Spring, shock, white (GTR long) (0.892 rate blue) (1 pair) |
| 7442 | Spring, shock, white (GTR xx-long) (0.711 rate orange) (1 pair) |
| 7443 | Spring, shock, white (GTR xx-long) (0.762 rate green) (1 pair) |
| 7446 | Spring, shock, white (GTR xx-long) (0.874 rate black) (1 pair) |
| 7447 | Spring, shock, white (GTR xx-long) (0.884 rate pink) (1 pair) |
| 7449 | Spring, shock, white (GTR xx-long) (1.004 rate blue) (1 pair) |
| Shocks (Pro-level Aluminum) | |
| 2664 | Big Bore shock cylinder (long) (1) |
| 5862 | Big Bore shocks (hard-anodized & PTFE-coated T6 aluminum) (assembled with TiN shafts and springs) (front & rear) (4) |
| 2660 | Big-bore shocks (long) (hard-anodized & PTFE-coated T6 aluminum) (assembled with TiN shafts) w/o springs (2) |
| 2662 | Big-bore shocks (xx-long) (hard-anodized & PTFE-coated T6 aluminum) (assembled with TiN shafts) w/o springs (rear) (2) |
| 2669 | Piston head set (2-hole (2)/ 3-hole (2))/ shock mounting bushings & washers (2) (Big Bore Shocks) |
| 1942 | Rod ends (16 long & 4 short)/ hollow ball connectors (18)/ ball screws (2) |
| 2742X | Rod ends, short (6)/ hollow balls (6) |
| 2667 | Shock caps, aluminum (2) (Big Bore Shocks) |
| 2362 | Shock rebuild kit (for 2 shocks) |
| 1664T | Shock shafts, hardened steel, titanium nitride coated (long) (2) |
| 2656T | Shock shafts, hardened steel, titanium nitride coated (xx- long) (2) |
| 1664 | Shock shafts, steel, chrome finish (long) (2) |
| 2656 | Shock shafts, steel, chrome finish (xx-long) (2) |
| 1765 | Silicone diaphragms (4) |
| 2668 | Spring retainers, upper & lower (2)/ spring pre-load spacers: 1mm (4)/ 1.5mm (2)/ 2mm (2)/ 4mm (2)/ 8mm (2) (Big Bore Shocks) |
| 6863 | Springs, front (progressive, +10% rate, pink) (2) |
| 6864 | Springs, front (progressive, +20% rate, blue) (2) |
| 6862 | Springs, front (progressive, -10% rate, green) (2) |
| 6861 | Springs, front (progressive, -20% rate, orange) (2) |
| 6857 | Springs, front (white) (progressive rate) (2) |
| 6867 | Springs, rear (progressive, +10% rate, pink) (2) |
| 6868 | Springs, rear (progressive, +20% rate, blue) (2) |
| 6866 | Springs, rear (progressive, -10% rate, green) (2) |
| 6865 | Springs, rear (progressive, -20% rate, orange) (2) |
| 6858 | Springs, rear (white) (progressive rate) (2) |
| Shocks (Ultra Shocks) | |
| 3765A | Body, Ultra Shock (long) (grey) (2) |
| 3766A | Body, Ultra Shock (XXL) (grey) (2) |
| 1942 | Rod ends (16 long & 4 short)/ hollow ball connectors (18)/ ball screws (2) |
| 2742X | Rod ends, short (6)/ hollow balls (6) |
| 8361 | Shock caps (black) (4) (assembled with hollow balls) |
| 3767A | Shock caps, aluminum (blue-anodized) (4) (fits all Ultra Shocks) |
| 3767G | Shock caps, aluminum (green-anodized) (4) (fits all Ultra Shocks) |
| 3767T | Shock caps, aluminum (orange-anodized) (4) (fits all Ultra Shocks) |
| 3767P | Shock caps, aluminum (pink-anodized) (4) (fits all Ultra Shocks) |
| 3767X | Shock caps, aluminum (red-anodized) (4) (fits all Ultra Shocks) |
| 2362 | Shock rebuild kit (for 2 shocks) |
| 1664T | Shock shafts, hardened steel, titanium nitride coated (long) (2) |
| 2656T | Shock shafts, hardened steel, titanium nitride coated (xx- long) (2) |
| 1664 | Shock shafts, steel, chrome finish (long) (2) |
| 2656 | Shock shafts, steel, chrome finish (xx-long) (2) |
| 1765 | Silicone diaphragms (4) |
| 3769 | Spring pre-load spacers: 1mm (4)/ 2mm (2)/ 4mm (2)/ 8mm (2) |
| 3768 | Spring retainers, upper & lower (2)/ piston head set (2-hole (2)/ 3-hole (2)) |
| 6863 | Springs, front (progressive, +10% rate, pink) (2) |
| 6864 | Springs, front (progressive, +20% rate, blue) (2) |
| 6862 | Springs, front (progressive, -10% rate, green) (2) |
| 6861 | Springs, front (progressive, -20% rate, orange) (2) |
| 6857 | Springs, front (white) (progressive rate) (2) |
| 6867 | Springs, rear (progressive, +10% rate, pink) (2) |
| 6868 | Springs, rear (progressive, +20% rate, blue) (2) |
| 6866 | Springs, rear (progressive, -10% rate, green) (2) |
| 6865 | Springs, rear (progressive, -20% rate, orange) (2) |
| 6858 | Springs, rear (white) (progressive rate) (2) |
| 3760 | Ultra Shocks (black) (long) (complete w/ spring pre-load spacers & springs) (front) (2) |
| 3762 | Ultra Shocks (black) (xx-long) (complete w/ spring pre-load spacers & springs) (rear) (2) |
| 3760A | Ultra Shocks (grey) (long) (complete w/ spring pre-load spacers & springs) (2) |
| 3762A | Ultra Shocks (grey) (xx-long) (complete w/ spring pre-load spacers & springs) (rear) (2) |
| Slipper Clutch Components | |
| 5119A | Ball bearings, black rubber sealed (10x15x4mm) (2) |
| 6893X | Bearing adapter, 6061-T6 aluminum (blue-anodized) (1)/10x15x4mm ball bearing (black rubber sealed) (1) (for slipper shaft) |
| 6893G | Bearing adapter, 6061-T6 aluminum (green-anodized) (1)/ 10x15x4mm ball bearing (black rubber sealed) (1) (for slipper shaft) |
| 6814 | Differential kit, center (complete) |
| 6888 | Drive hub, center, rear (1)/ 4×3 GS (1) |
| 6888X | Drive hub, front, hardened steel (1)/ screw pin (1) |
| 6883 | Gear set, center differential (output gears (2)/ spider gears (2)/ spider gear shaft) |
| 6884 | Housing, center differential/ x-ring gaskets (2)/ ring gear gasket/ bushings (2)/ 5x10x0.5 TW (2)/ CCS 2.5×8 (4) |
| 6893 | Input shaft (slipper shaft)/ bearing adapter (1)/ pin (1) |
| 5352R | Rebuild kit (heavy duty), slipper clutch (steel disc/ aluminum friction pads (3)/ spring (1)/ 2×9.8mm pin/ 5x8mm MW/ 5.0mm NL (1)/ 4.0mm NL (1)) |
| 5352X | Rebuild kit, slipper clutch (steel disc/ friction pads (3)/ spring (1)/ 2×9.8mm pin/ 5x8mm MW/ 5.0mm NL (1)/ 4.0mm NL (1)) |
| 5552X | Rebuild kit, slipper clutch (steel disc/ friction pads (3)/ spring (2)/ pin/ 4.0mm NL (1)/ 5.0mm NL (1)) |
| 2554 | Screws, 3x6mm caphead machine (hex drive) (6) |
| 6878 | Slipper clutch, complete (for Slash 4×4) |
| 5556 | Slipper pressure plate & hub (aluminum alloy) |
| 5351 | Slipper pressure plate and hub (alloy) |
| Spur Gears & Pinion Gears | |
| 3942X | Gear, 12-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3943X | Gear, 13-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3944X | Gear, 14-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3945X | Gear, 15-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3946X | Gear, 16-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3947X | Gear, 17-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3948X | Gear, 18-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3949X | Gear, 19-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3950X | Gear, 20-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3951X | Gear, 21-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 3952X | Gear, 22-T pinion (32-p), heavy duty (machined, hardened steel) (fits 3mm shaft)/ set screw |
| 6842 | Spur gear, 50-tooth (0.8 metric pitch, compatible with 32- pitch) |
| 6842R | Spur gear, 50-tooth (0.8 metric pitch, compatible with 32- pitch) (for Slash 4×4 center differential) |
| 6843 | Spur gear, 52-tooth (0.8 metric pitch, compatible with 32- pitch) |
| 6843R | Spur gear, 52-tooth (0.8 metric pitch, compatible with 32- pitch) (for Slash 4×4 center differential) |
| 3956 | Spur gear, 54-tooth (0.8 metric pitch, compatible with 32-pitch) |
| 3956R | Spur gear, 54-tooth (0.8 metric pitch, compatible with 32- pitch) (for center differential) |
| 3956X | Spur gear, steel, 54-tooth (0.8 metric pitch, compatible with 32-pitch) (for center differential) |
| Steering Components | |
| 6845A | Drag link, machined 6061-T6 aluminum (blue-anodized) |
| 6845G | Drag link, machined 6061-T6 aluminum (green-anodized) |
| 6845T | Drag link, machined 6061-T6 aluminum (orange-anodized) |
| 6845R | Drag link, machined 6061-T6 aluminum (red-anodized) |
| 6846 | Linkage, steering (Revo) (3x20mm turnbuckle) (1)/ rod ends (2)/ hollow balls (2) |
| 2742 | Rod ends, long (6)/ hollow ball connectors (6) |
| 1552 | Screws, 3x8mm cap-head machine (hex drive) (6)/washers (6)/ wrench |
| 6845X | Steering bellcranks/ servo saver/ servo saver spring/ servo spring retainer/servo horn, steering |
| 6742X | Toe links (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 6742G | Toe links (TUBES green-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 6742R | Toe links (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 2746 | Washers, 3x6mm metal (12) |
| Suspension Linkage | |
| 2537 | 3mm threaded rods: 1 each of 20mm,25mm&44mm |
| 3643X | Camber links, front (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3643G | Camber links, front (TUBES green-anodized, 7075-T6 aluminum, stronger than Titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3643R | Camber links, front (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644X | Camber links, rear (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644G | Camber links, rear (TUBES green-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644R | Camber links, rear (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 5525 | Rod ends (12)/ hollow balls (12) |
| 3739 | Screw pin set (Rustler®/ Bandit/ Stampede®) |
| 6834 | Suspension pin set, complete (front and rear) |
| 3644 | Turnbuckles, camber link, 39mm (69mm center to center) (assembled with rod ends and hollow balls) (1 left, 1 right) (fits front & rear on Slash) |
| 3643 | Turnbuckles, camber link, 49mm (82mm center to center) (assembled with rod ends and hollow balls) (1 left, 1 right) |
| 5539 | Turnbuckles, camber links, 58mm (assembled with rod ends and hollow balls) (2) |
| Team Traxxas Items | |
| 2514 | Decal sheet, racing sponsors |
| 9950 | Official Team Traxxas® racing decal set(flag logo/ 6-color) |
| 9909 | Traxxas® racing banner, red & black (3×7 feet) |
| Tires & Wheels | |
| 5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) |
| 5854 | Hub retainer, 17mm hubs, M4 X 0.7 (4) (use with #5853X, #6856X, #6469) |
| 3647 | Nuts, 4mm flanged nylon locking (steel, serrated) (8) |
| 1985 | PTFE-coated Washers, 5x8x0.5mm (20) (use with ball bearings) |
| 1647 | Silicone Grease |
| 2754 | Stub axle pins (4) |
| 10187-BLKCR | Tires & wheels, assembled, glued (Ford Raptor R black chrome wheels, BFGoodrich® All-Terrain™ T/A® KO2 tires, foam inserts) (2) (4WD front/rear, 2WD rear) |
| 10181 | Tires, BFGoodrich® All-Terrain™ T/A® KO2 (dual profile 4.5×1.7- 2.2/3.0″) (2)/ foam inserts (2) |
| 9069 | Wheel hubs, 12mm hex (steel), extreme heavy duty (4)/ 2×9.8mm pin (4) (for use with #9080 upgrade kit and 6mm axles) |
| 1654R | Wheel hubs, hex (steel) (2)/ axle pins (2) |
| 5353 | Wheel nuts, splined, 17mm (blue-anodized) (4) |
| 5480X | Wheel wrench, splined, 17mm |
| Traxxas Tools | |
| 3433X | Body reamer (aluminum handle) |
| 3433 | Body reamer (plastic handle) |
| 3436 | Cap, body reamer |
| 3432 | Scissors, curved tip |
| 3431 | Scissors, straight tip |
| 8712 | Speed Bit Essentials Set, hex and nut driver, 7-piece, includes premium handle (medium), travel pouch, hex drivers (straight: 1.5mm, 2.0mm, 2.5mm) and nut drivers (5.0mm, 5.5mm, 7.0mm, and 8.0mm), 1/4” drive |
| 8720 | Speed bit handle, large (overmolded) |
| 8721 | Speed bit handle, medium (one piece) |
| 8722 | Speed bit handle, premium (rubber overmold) |
| 8710 | Speed Bit Master Set, hex and nut driver, 13-piece, includes premium handle (medium), travel pouch, hex drivers (straight: 1.5mm, 2.0mm, 2.5mm, 3.0mm), (ball-end: 2.0mm, 2.5mm, 3.0mm), and nut drivers (4.0mm, 4.5mm, 5.0mm, 5.5mm, 7.0mm, 8.0mm), 1/4” drive |
| 8711 | Speed Bit Master Set, hex driver, 7-piece straight and ball end, includes premium handle (medium), travel pouch, hex drivers (straight: 1.5mm, 2.0mm, 2.5mm, 3.0mm) (ball end: 2.0mm, 2.5mm, 3.0mm), 1/4″ drive |
| 8719 | Speed Bit Master Set, nut driver, 6-piece, includes premium handle (medium), travel pouch, and nut drivers (4.0mm, 4.5mm, 5.0mm, 5.5mm, 7.0mm, 8.0mm), 1/4″ drive |
| 8716 | Speed Bit Set, hex driver, 2-piece ball-end (2.0mm, 2.5mm), 1/4″ drive |
| 8716X | Speed Bit Set, hex driver, 3-piece ball-end (2.0mm, 2.5mm, 3.0mm) 1/4″ drive |
| 8715 | Speed Bit Set, hex driver, 3-piece straight (1.5mm, 2.0mm, 2.5mm), 1/4″ drive |
| 8715X | Speed Bit Set, hex driver, 4-piece straight (1.5mm, 2.0mm, 2.5mm, 3.0mm), 1/4″ drive |
| 8714 | Speed Bit Set, screwdriver, 3-piece straight (3mm slotted, #1 Phillips, and #2 Phillips bits), 1/4″ drive |
| 2748R | Tool set (includes 1.5mm hex wrench / 2.0mm hex wrench / 2.5mm hex wrench/ 4-way wrench/ 8mm & 4mm wrench/ U- joint wrench) |
| 3415 | Tool set with pouch (includes 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4mm drivers/4mm. 5mm, 5.5mm, 7mm, and 8mm nut drivers/ 2mm, 3mm, and 4mm slotted screwdrivers/ #00 Phillips, #0 Phillips, and #1 Phillips screwdrivers/ 4mm and 8mm wrenches/ driver handle) |
| Turnbuckles & Threaded Rods | |
| 3643X | Camber links, front (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3643G | Camber links, front (TUBES green-anodized, 7075-T6 aluminum, stronger than Titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3643R | Camber links, front (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644X | Camber links, rear (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644G | Camber links, rear (TUBES green-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 3644R | Camber links, rear (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3×15 BCS (4) required for installation) |
| 5525 | Rod ends (12)/ hollow balls (12) |
| 6742X | Toe links (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 6742G | Toe links (TUBES green-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 6742R | Toe links (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (87mm) (2)/ rod ends (4) aluminum wrench (1) |
| 3644 | Turnbuckles, camber link, 39mm (69mm center to center) (assembled with rod ends and hollow balls) (1 left, 1 right) (fits front & rear on Slash) |
| 3643 | Turnbuckles, camber link, 49mm (82mm center to center) (assembled with rod ends and hollow balls) (1 left, 1 right) |
| 5539 | Turnbuckles, camber links, 58mm (assembled with rod ends and hollow balls) (2) |
- If you have questions or need technical assistance, call Traxxas at 1-888-TRAXXAS (1-888-872-9927) (U.S. residents only)
- For orders, calls outside the U.S., and other information, call 972-549-3000, or fax to 972-549-3011 e-mail Traxxas at [email protected]
- TRAXXAS.com
- BFGoodrich and all associated names are trademarks used with permission. Distributed under license by Traxxas LP. Copyright © 2023 MNA, Inc. All rights reserved. REV. 230724 1445
