XT2331-2 moto g13 Smartphone
Product Information
The product is a mobile phone with the model numbers XT2331-2
and XT2331-3. It supports various operating modes such as
Bluetooth, Wi-Fi, GNSS, NFC, GSM, UMTS, and LTE. The phone has a
main camera, depth camera, flash, front camera, macro camera,
speaker, microphone, proximity sensor, volume buttons, power
button/fingerprint sensor, and a headset jack. The phone’s SIM and
microSD card tray can hold a nano-SIM card and an optional microSD
card (sold separately) for additional storage. The phone is
water-repellent but not waterproof.
Product Usage Instructions
- To view specific absorption rate (SAR) values for the phone,
swipe up from the Home screen and tap Settings > Regulatory
labels. From the phone’s dial pad, type *#07# or visit
www.motorola.com/sar. - To insert the SIM card(s), insert the SIM tool into the hole
next to the tray to pop out the tray. Insert the SIM card(s) with
the gold contacts down and gently push the tray into the slot. Make
sure to use the correct size SIM card and not cut the SIM
card. - If desired, add an optional microSD card for additional
storage. - Press and hold the power button to turn on the phone. Follow
the prompts to get started. - To learn more about the phone’s water-repellent design and
care, swipe up from the Home screen and tap Settings >
Help. - If located in the UK or Ireland, visit motorola.com/motocare to
extend warranty coverage up to three years and take advantage of
features like accidental damage protection with moto care.
SAR information (on e-label). To view specific absorption rate (SAR) values for this phone, from the Home screen swipe up and tap Settings > , then type Regulatory labels, from your phone’s dial pad type *#07# or visit www.motorola.com/sar. Supported frequencies and power (Model XT2331-2, XT2331-3). This phone is capable of operation on the following frequencies, subject to location and network availability.
Operating mode
Bluetooth
Frequency range MHz / Band
2400 2483.5
Maximum nominal transmit power dBm
20 dBm EIRP
Wi-Fi
2400 2483.5
20 dBm EIRP
Wi-Fi
5150 5250
23 dBm EIRP
Wi-Fi
5250 5350/5470 5725
20 dBm EIRP
Wi-Fi
5725 5850
14 dBm EIRP
GNSS
1559 1610
N/A
NFC
13.56
-17.07 dBuA/m@10m
FM receive 87.5 108
N/A
GSM (Australia 2/3/5/8 not applicable)
33/30
UMTS
1/2/5/8/19 (XT2331-3 only)
24
LTE
XT2331-2: 1/2/3/5/7/8/20/38/40/41 23
XT2331-3: 1/2/3/5/7/8/18/19/20/
26/28/38/40/41
Copyright and trademarks. MOTOROLA, the stylised M logo, MOTO and the MOTO family of marks are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. Google, Android, Google Play and other related marks and logos are trademarks of Google LLC. microSD Logo is a trademark of SD-3C, LLC. USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum. All other product or service names are the property of their respective owners. © 2022 Motorola Mobility LLC. All rights reserved.
care
With moto care, extend your warranty coverage up to three years, and take advantage of features like accidental damage protection. Visit motorola.com/motocare. (UK and Ireland only)
Meet your
Main camera
Depth camera
Flash Front camera SIM and microSD card tray
Headset jack
Macro camera
Speaker Proximity sensor
Volume buttons
Power button/ fingerprint sensor
/
motorola.com
HQ607266VE000-A
Printed in China
Microphone
USB-C®/charger
Speaker
Put in the cards and power on
Nano SIM
1 Insert the SIM tool into the hole next to the tray to pop out the tray.
Make sure you use the correct size SIM card and don’t cut the SIM card.
One-SIM model Two-SIM model
SIM
2 Insert the SIM card(s) with the gold contacts down, then gently push the tray into the slot.
Add a microSD card (optional,
sold separately) for additional storage.
SIM1
SIM2
3 Press and hold the power button, then follow the prompts to get started.
Water repellent. Your phone is not waterproof. For more about your phone’s water-repellent design and care, swipe up and tap Settings > Help.
Help and more
Get answers, updates and info: ·Help is here: from the Home screen, swipe up and tap Settings > Help
to learn how to use your phone and get support. ·Get more: get software, user guides and more at
www.motorola.com/mymotog. ·Get apps: tap Play Store to browse and download apps. ·Uninstall an app: touch and hold the app, then drag it to Uninstall. ·Backup and restore: log in to your Google account to restore contacts,
calendar and more. Legal information. This guide provides important legal, safety and regulatory information that you should read before using your product. For the complete legal information, from the Home screen swipe up and tap Settings > , then type Legal information or visit www.motorola.com/device-legal. Battery safety. To prevent possible burning and injury, the battery in your phone should only be removed by a Motorola-approved service centre or similar skilled personnel. If your phone becomes unresponsive, press and hold the power button until the screen goes dark and your phone restarts. Charge your phone using a compatible Motorola charger (may be sold separately). Use of other chargers is not recommended and may impair the charging performance. Don’t charge your phone in temperatures below -20°C or above 45°C. Chargers that do not comply with applicable national standards may be unsafe, with risk of death or injury, and may cause slow charging or product damage. To view applicable standards and to learn more, see the “Legal information” section of this guide or visit www.motorola.com/device-legal. Warning about high volume usage. To prevent possible hearing damage, do not listen at high volume levels for long periods. When your headset volume reaches the high volume threshold, a warning will be shown. Tap OK to dismiss it, or wait one to five seconds, then press the Volume up button to dismiss the alert and enable the volume to continue to be adjusted. Disposal and recycling. For help recycling products and packaging responsibly, visit www.motorola.com/recycling. Class 1 laser. This device is classified as a Class 1 Laser product, which is safe in normal use per IEC60825-1:2007 CLASS 1 LASER PRODUCT and IEC60825-1:2014. This device complies with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice 50, dated 24 June 2007. Do not attempt to modify or disassemble the laser focusing system. Extreme heat or cold. Don’t use your phone in temperatures below -20°C or above 45°C. Don’t store/transport your phone in temperatures below -20°C or above 60°C. Legal disclaimers. Features, services and applications are network dependent and may not be available in all areas; additional terms/charges may apply. Product specifications and other information contained in this guide are believed to be accurate at the time of printing. Motorola reserves the right to correct or change any information without notice. Arbitration. Your purchase is governed by a binding arbitration clause. For more information and how to opt out, see the legal guide that came with your phone.
