Portfolio 4 Inch LED Medium Beam Reflector Self Flanged

Product Information

The Cooper Lighting Solutions Portfolio LED Selection Guide
provides a comprehensive range of adjustable LED downlights for
various aperture sizes. The guide includes information on aperture
size, nominal lumens, nominal wattage, dim to warm feature, tunable
white feature, color temperature (CCT), color rendering index
(CRI), and beam options. The guide also mentions the availability
of adjustable and field changeable optics, emergency options, and
compatibility with WaveLinx LITE, WaveLinx PRO, and WaveLinx PRO
Wireless Node systems.

Adjustable LED Selection Guide

Aperture Size	Nominal Lumens	Nominal Wattage	Dim to Warm	Tunable White	Nominal CCT	CRI	Nominal Beam	Adjustable	Field Changeable Optics	WaveLinx Compatibility	Emergency Options
2-inch	500, 1000, 1500, 2000	7.4, 11.0, 15.1, 21.2	Yes	Yes	2400K, 2700K, 3000K, 3500K, 4000K, 5000K	80, 90, 97	10-70	Yes	Yes	WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node	Available
3-inch	250, 700, 1000, 1300, 1800, 2300	N/A	N/A	N/A	2400K, 2700K, 3000K, 3500K, 4000K, 5000K	90, 97	10-70	Yes	Yes	WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node	N/A
4-inch	900, 1300, 1800, 2800	13.8, 22.9, 29.1, 44.5	No	No	2700K, 3000K, 3500K, 4000K	80, 90	N/A	Yes	Yes	N/A	N/A
6-inch	1000, 1500, 2000, 3000, 4500, 5500, 6500, 7500	15, 22.9, 29.4, 44.5, 52.2, 60.8, 78.7, 78.7	No	No	2700K, 3000K, 3500K, 4000K	80, 90	N/A	Yes	Yes	N/A	N/A

Downlights LED Selection Guide

Aperture Size	Nominal Lumens	Nominal Wattage	Nominal LPW	Dim to Warm	VividTune Tunable White	Nominal CCT	CRI	Nominal Beam	Adjustable	Field Changeable Optics	WaveLinx Compatibility	Emergency Options
2-inch	N/A	N/A	N/A	Yes	Yes	2400K, 2700K, 3000K, 3500K, 4000K, 5000K	90, 97, 98 CRI	30-55	No	No	WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node	Available
6-inch	250, 500, 800, 1000	3.9, 7.8, 10.5, 10.5	N/A	No	No	2400K, 2700K, 3000K, 3500K, 4000K, 5000K	90, 97, 98 CRI	N/A	No	No	WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node	N/A
6-inch	1500, 2000, 2500, 3000, 3500, 4000, 4500, 5000, 5500, 6000, 6500, 7000, 7500, 8000, 9000, 10000, 11000, 12000, 13000, 15000	16.6, 22.6, 32.6, 32.6, 39.9, 48.4, 50.2, 58.7, 63, 65.7, 69, 75.9, 80.9, 88, 101.2, 114.9, 127, 142.3, 151.7, 170.5	N/A	No	No	2400K, 2700K, 3000K, 3500K, 4000K, 5000K	90, 97, 98 CRI	N/A	No	No	WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node	N/A
8-inch	1000, 1500, 2000, 3000, 4000, 5000, 6000, 7000, 8000, 9000, 10000, 12000, 15000, 17500, 20000	10.2, 14.4, 21.3, 27.1, 40.9, 53, 59.5, 75.9, 74.4, 86.1, 106.3, 118, 159, 177, 177	N/A	No	No	2700K, 3000K, 3500K, 4000K, 5000K	80, 90, 97 CRI	N/A	Single, Double, Corner	Single and Double	N/A	N/A

Controls Brands Compatibility

The LED products are compatible with Greengate, Fifth Light, and
Intelligent Lighting Controls brands for control and
automation.

Product Usage Instructions

To use the adjustable LED downlights from the Cooper Lighting
Solutions Portfolio, follow these steps:

Select the appropriate aperture size based on your requirements
(2-inch, 3-inch, 4-inch, or 6-inch).
Choose the desired nominal lumens and nominal wattage based on
your lighting needs.
If you prefer a dim to warm feature or tunable white
feature

View Fullscreen

Portfolio
LED Product Selection Guide
May 2023

Portfolio
Specification grade product family combining energy efficiency with superior cutoff, optical performance and control for Architectural applications. This complete family designed for glare free illumination from recessed downlights and cylinders is complimented by directional/accent and wall wash luminaires to seamlessly complete all spaces including offices, education, retail, hospitality and healthcare. Comprehensive line includes a multitude of driver options, color temperatures, CRI, beam distributions and reflector finishes.
portfolio-lighting.com

Cooper Lighting Solutions Portfolio – LED Selection Guide

Adjustable LED Selection Guide

Aperture Size Nominal Lumens Nominal Wattage Dim to Warm Tunable White
Nom CCT
CRI
Nominal Beam Adjustable
Field changeable optics
Round adjustable Square adjustable and wall wash D010 1% D010TR/TE 120V line voltage or 120-277V 0-10V DE010 0-10V 0% D010 10% D5LT DALI DMX DL2 Lutron® forward phase DLE Lutron® Ecosytem DLVP
WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node
Emergency options

2-inch

500 1000 1500 2000

7.4 11.0 15.1 21.2

2400K / 2700K / 3000K / 3500K / 4000K / 5000K

80 / 90 / 97

10 / 15 / 20 / 25 / 30 / 35 / 40 / 45 / 50 / 55 / 60 / 65 / 70

3-inch
250 700 1000 1300 1800 2300

2400K / 2700K / 3000K / 3500K / 4000K / 5000K

90 / 97

10 / 15 / 20 / 25 / 30 / 35 / 40 / 45 / 50 / 55 / 60 / 65 / 70

4-inch

900 1300 1800 2800

13.8 22.9 29.1 44.5

2700K / 3000K / 3500K / 4000K 80 / 90

6-inch

1000 1500 2000 3000 4500 5500 6500 7500

15 22.9 29.4 44.5 52.2 60.8 78.7 78.7

2700K / 3000K / 3500K / 4000K 80 / 90

· · ·

· · · · · ·

Cooper Lighting Solutions Portfolio – LED Selection Guide

Downlights LED Selection Guide

Aperture Size Nominal Lumens Nominal Wattage Nominal LPW Dim to Warm VividTune tunable white
Nom CCT
CRI Nominal Beam Dnlt

2-inch
500 1000 1500 2000 7.3 11 16 21.2 68.5 91 93.8 94.3 ····
· 2400K / 2700K / 3000K / 3500K / 4000K / 5000K
80 / 90 / 97 15 / 25 / 40 / 55

4-inch

250 500 800 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500

3.7 7.8 10.5 10.5 16.6 22.6 32.6 32.6 39.9 48 50.1 58 62 65.7 69 75.9 80.9

68 91.3 89.5 103.8 98.2 91.7 79.8 93.4 86.2 86 94.3 90.7 92.7 88.9 92.5 90.2 101.5

·····

······

2400K / 2700K / 3000K / 3500K / 4000K / 5000K

90, 97 and 98CRI

6-inch
250 500 800 1000
3.9 7.8 10.5 10.5
95.1 93.3 108.3 ·· ·
2400K / 2700K / 3000K / 3500K / 4000K / 5000K
90, 97 and 98CRI

Narrow beam Medium beam 50° cutoff Medium beam 45° cutoff Wide beam Shallow Non conductive – dead front Open wall wash Lensed wall wash Square medium beam downlight 50° cutoff Square medium beam downlight 45° cutoff Square shallow downlight Square lensed wall wash Retrofit Remodel Cylinder Shallow Cylinder D010 1% D010TR/TE 120V line voltage or 120-277V 0-10V DE010 0-10V 0% D5LT DALI DMX DL2 Lutron® forward phase DLE Lutron® Ecosytem DLVP
WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node
Emergency options

15° 25°
40°, 55° ·
· ·
· · · · · · ···· TR TR ·· ·· ·· ·· ·· ···· · ·

30° 50° 50° 70° 70° 90° Single, double, corner Single and double 55° 55° 95° · Round Round up to 4000 lumens up to 3000 lumens ················· ················· ················ ················ ··············· ··············· ··············· ······ ················· ·················

30° 50° 50° 80° 70° 90° Single, double, corner Single and double 55° 55° 100° · Round Round up to 6000 lumens up to 4000 lumens ···· ···· ··· ···
·· ·· ·· ·· ···· ····

Downlights LED Selection Guide

6-inch

1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 9000 10000 11000 12000 13000 15000

16.6 22.6 32.6 32.6 39.9 48.4 50.2 58.7 63 65.7 69 75.9 80.9 88 101.2 114.9 127 142.3 151.7 170.5

102.3 95.7 83.2 97.4 89.9 89.7 98.4 94.6 96.7 92.8 96.5 94.1 105.9 104.1 102.2 92.8 90 89.2 96.8

···

········

2400K / 2700K / 3000K / 3500K / 4000K / 5000K

90, 97 and 98CRI

8-inch

1000 1500 2000 3000 4000 5000 6000 7000 8000 9000 10000 12000 15000 17500 20000

10.2 14.4 21.3 27.1 40.9 53 59.5 75.9 74.4 86.1 106.3 118 159 177 177

98 104.2 93.9 110.7 97.8 94.3 100.8 92.2 107.5 104.5 94.1 101.4 94.6 98.8 113

·····

2700K / 3000K / 3500K / 4000K / 5000K
80 / 90 / 97

30°

50°

80°

70°

90°

Single, double, corner

Single and double

55°

100°

Round

up to 6000 lumens

up to 4000 lumens

·················

············

·················

············

··········

·················

15°

30°

34°

40°

44°

46°

73°

86°

Single and double

up to 6,000 lumens

·····

··

TR TR TR TR TR TE TE TE TR TR TE TE TE TE TE

·····

··

·····

··

·····

··

·····

··

·····

··

···

Multi-head LED Selection Guide

Aperture Size Nominal Lumens Nominal Wattage
Nom CCT
CRI
Nominal Beam Adjustable
Field changeable optics
New construction Install from below D010 1% D010TR/TE 120V line voltage or 120-277V 0-10V DE010 0-10V 0% D010 10% D5LT DALI DMX DL2 Lutron® forward phase DLE Lutron® Ecosytem DLVP
WaveLinx LITE / WaveLinx PRO / WaveLinx PRO Wireless Node
Emergency options

1-inch downlight
200 3.1 – 34.7 2700K / 3000K / 3500K / 4000K
90 30/50
N
· · ·
·
· · · · · · · · ·

1-inch adjustable
200 3.1 – 34.7 2700K / 3000K / 3500K / 4000K
90 30/50
N
· · ·
·
· · · · · · · · ·

4-inch

800

1200

10-56

2400K / 2700K / 3000K / 3500K / 4000K / 5000K
90 / 97

10 /15/20/25/30/35/40/45/50/55/60/65/70

Cooper Lighting Solutions Portfolio – LED Selection Guide

Lighting Brands Ametrix AtLite Corelite Ephesus Fail-Safe HALO HALO Commercial Invue iO Iris Lumark Lumière McGraw-Edison Metalux MWS Neo-Ray Portfolio PrentaLux – 3D Printed Lighting RSA Shaper Streetworks Sure-Lites Telensa

Controls Brands Greengate Fifth Light Intelligent Lighting Controls
Connected Lighting Systems and Smart Spaces Platform WaveLinx

SCAN for more Portfolio information

Cooper Lighting Solutions 1121 Highway 74 South Peachtree City, GA 30269 P: 770-486-4800 www.cooperlighting.com
Canada Sales 5925 McLaughlin Road Mississauga, OntarioL5R 1B8 P: 905-501-3000 F: 905-501-3172

Cooper Lighting Solutions is a registered trademark.
All other trademarks are property of their respective owners.
Product availability, specifications, and compliances are subject to change without notice.
