2022 XT22
OWNER’S MANUAL
FEATURES
| 01. Bow cleat | 27. Bilge thru-hull outlet |
| 02. Navigation light | 28. Automatic fire extinguisher |
| 03. Anchor storage | 29. Transom remote (where equipped) |
| 04. Horn | 30. Underwater lights (two, where equipped) |
| 05. Forward ballast tank (below deck) | 31. Surf tab (one on each side) |
| 06. ZeroOff GPS puck | 32. Center surf tab (attitude adjustment plate) |
| 07. Bow subwoofer | 33. Navigation light |
| 08. Bilge thru-hull outlet | 34. Bow filler cushion (where equipped) |
| 09. Ballast thru-hull outlet | 35. Amp |
| 10. Midship cleat | 36. Trash can door |
| 11. Circuit breaker panel; battery switch | 37. Handheld fire extinguisher |
| 12. Instrument panel | 38. Glovebox |
| 13. Steering wheel | 39. Observer remote (where equipped) |
| 14. Throttle control and emergency stop switch | 40. Center drain plug |
| 15. Heated seat (where equipped) | 41. Heated observer seat (where equipped) |
| 16. Cockpit subwoofer | 42. Ballast tank (one on each side; below deck) |
| 17. Fire suppression unit manual override | 43. Tower with clamping board racks |
| 18. Starboard pop-up seatback (where equipped) | 44. Anchor light and tower tow point attachment |
| 19. Wireless cockpit chargers (where equipped) | 45. Ski pylon (where equipped) |
| 20. Cooler (under the seat) | 46. Battery/batteries (under the seat) |
| 21. Convertible center rear seating (where equipped) | 47. Ballast thru-hull vent |
| 22. Ballast thru-hull vent | 48. Fuel tank fill |
| 23. Stern cleat | 49. SurfStar rear ballast bag (below sun deck, where equipped; one on each side) |
| 24. Fuel tank fill | 50. Sun deck flip seating (where equipped) |
| 25. Engine flush valve | 51. Transom drain plug |
| 26. Engine compartment | 52. Swim platform |
SPECIFICATIONS
Length of Boat 22’ 4”
Beam 102”
Boat Weight 5,485 lbs.
Length of Boat w/ Platform 24’ 4”
Towing Length 27’ 7”
Towing Width 102”
Fuel Capacity 79 G
Maximum Capacity 16 people
or 2,400 lbs.
Bow Capacity 5 people or 700 lbs.
Weight must be evenly distributed.
XT22
100 CHEROKEE COVE DR. VONORE, TN 37885 423.884.2221
MASTERCRAFT.COM
