XCV06Z 18V X2 LXT Lithium-Ion Brushless Cordless 2.1 Gallon Wet-Dry Dust Extractor-Vacuum
Product Information
The XCV06Z is a wet/dry shop vacuum designed and manufactured by
Makita Corporation. It is a powerful tool that provides exceptional
performance and convenience for various cleaning tasks.
Product Highlights
- Power: The XCV06Z offers excellent power to
tackle tough cleaning jobs effectively. - Run Time: It provides up to 75 minutes of
continuous run time on the low setting and 40 minutes on the high
setting, allowing for extended cleaning sessions.
Features
- Ergonomics: The XCV06Z is designed with an
oversized on-off switch for operator convenience, ensuring easy
operation and control.
Specifications
- Convenience: The XCV06Z offers convenient
features that enhance the user experience.
Standard Equipment
- Filter Dust Bag, 5/pk (A-48430)
- Anti-Static Hose, 1-1/2 x 8′ (195434-1)
- Curved Pipe (192562-3)
- Straight Pipe (192563-1)
*Please note that all specifications are subject to change
without prior notice. All models and accessories are subject to
stock availability.
The Makita Teal Color is the trade dress of Makita Corporation
and is protected under common law and registered with the U.S.
Patent and Trademark Office.
This brochure was downloaded from wet-dry-vac.com. Visit the website
for more information about wet/dry shop vacuums, purchasing guides,
detailed specifications, manuals, parts lists, brochures, and to
find the best prices for vacuums and filters.
Product Usage Instructions
- Ensure that the wet/dry shop vacuum is connected to a power
source. - Before use, check if the filter dust bag is properly installed.
If not, refer to the user manual for installation
instructions. - If required, attach the anti-static hose to the vacuum. Make
sure it is securely connected. - Choose the appropriate pipe (curved or straight) based on your
cleaning needs. - Turn on the vacuum by pressing the oversized on-off
switch. - To adjust the power setting, use the provided controls. The low
setting offers up to 75 minutes of continuous run time, while the
high setting provides 40 minutes. - Direct the nozzle or attachment to the desired area to start
cleaning. - Move the vacuum in a back-and-forth motion or as needed to
thoroughly clean the surface. - Once finished, turn off the vacuum by pressing the on-off
switch again. - Disconnect the power source and store the wet/dry shop vacuum
in a safe place.
18V X2 LXT® LITHIUM-ION (36V) BRUSHLESS CORDLESS 2.1 GALLON WET/DRY DUST EXTRACTOR/VACUUM, TOOL ONLY
NEW TOOL OVERVIEW
XCV06Z
PRODUCT HIGHLIGHTS
POWER
Makita Brushless motor delivers 74 CFM using two 18V LXT® 5.0Ah batteries (batteries not included)
RUN TIME
Up to 75 minutes of continuous run time on low setting and 40 minutes on high setting
FEATURES
· Efficient BLTM Brushless motor is electronically controlled to optimize battery energy use for up to 50% longer run time per charge
· The BLTM Brushless Motor eliminates carbon brushes, enabling the BLTM Motor to run cooler and more efficiently for longer life
· Efficient cloth filter captures small dust particulates · Precision lightweight motor components and efficient air
ducting produce an overall weight of only 16.8 lbs with batteries (batteries not included) · Motor chamber constructed of quality sound-absorbing materials for quiet operating sound levels of 66 dB(A)
· Variable speed control dial for a variety of applications · Large rubber bumper helps prevent damage to the work environment
· Locking cover for added protection of batteries (batteries not included) · Quick-release metal latches for easy removal and disposal of
debris from canister · Rear casters feature locking levers to prevent the vacuum from moving · Removable storage box for storing attachment and batteries
ERGONOMICS
Oversized on-off switch for operator convenience
SPECIFICATIONS
Gross Container Size………………………………………………….. 2.1 gal. Wet Capacity ……………………………………………………………… 1.5 gal. Air Flow Rate ………………………………………………………………74 CFM Static Water Lift……………………………………………………………….39″ Continuous Use (max, in minutes) ………………………………75 min. Battery………………………………………………. 2X 18V LXT® Lithium-Ion Filter Cleaning………………………………………………………………….. No HEPA filter………………………………………………………………………… No Working Sound Level ………………………………………………..66 dB(A) Net Weight (with battery)…………………………………………. 16.8 lbs. UPC Code………………………………………………………..088381-841047 Power Type ………………………………………………………………. Cordless
CONVENIENCE
Dual L.E.D. battery indicators show charge level for each 18V LXT® battery (batteries not included)
STANDARD EQUIPMENT
· Anti-Static Hose, 1-1/2″ x 8′ (195434-1) · Curved Pipe (192562-3) · Straight Pipe (192563-1) · 12″ Universal Floor Nozzle (122512-4) · 13″ Ivory Crevice Nozzle (410306-2) · Plastic Disposal Bag, 10/pk (195432-5) · Cloth Vacuum Filter (140248-3)
RELATED PRODUCTS
1. Filter Dust Bag, 5/pk (A-48430) 2. Anti-Static Hose, 1-1/2″ x 8′ (195434-1)
1
2
3
4
5
3. Curved Pipe (192562-3)
4. LXT® and LXT® X2 (36V) Portable Backpack Power Supply (PDC01)
5. Straight Pipe (192563-1)
All specifications subject to change without prior notice. All models and accessories subject to stock on hand. The Makita Teal Color is the trade dress of Makita Corporation and is protected under common law and registered with the U.S. Patent and Trademark Office. NTF-0320 MA-8448-20
