RLF-9KITD Living Fan
Product Information
This product is a fan with removable blades and front guard. It
features a motor, fan blade, front guard, back guard, and a knob
for disassembly.
Product Usage Instructions
- Use a screwdriver to loosen and remove the screw located on the
right side of the back guard. - Hold the ring guard and turn the front guard anti-clockwise to
the left to remove it. - Hold the fan blade and rotate the knob in a clockwise
direction. - Once the knob is rotated, you can remove the fan blade and
front guard. - To clean the fan, remove the inner lids of the aroma box, fan
blade, and back cover. - Clean all the removable parts thoroughly.
- After cleaning, make sure to store the fan in a dry
environment.
Please follow these instructions carefully for proper
disassembly and cleaning of the fan.
:
1. 2.() 3. 4.
()
Disassembly of the blades & front guard
1. Use a screwdriver to loosen and then take out a screw on the right side of the back guard.
2. Hold the ring guard and turn the front guard anti-clockwise to the left and remove it. 3. Hold the blade and rotate the knob clockwise direction. 4. You can clean inside after removing the fan blade and front guard. The front guard
(inner lids of aroma box must be removed), fan blade and back cover can be cleaned. Please be sure to store in a dry environment after cleaning.
Match
fan blade motor groove shaft pin
fan blade
