MK-1 Motorcycle Air Ride Suspension Kit
Product Information
The Motorcycle Air Ride Suspension Modification Kit is designed
to enhance the suspension system of motorcycles. This kit allows
users to adjust and control the air pressure in their motorcycle’s
shocks, providing a customizable and comfortable ride.
Manufacturer: HornBlasters
Address: 6511 N 54th St Tampa, FL 33610
Contact: +1 (813) 783-8058
Fax: +1 (813) 783-2407
Website: www.hornblasters.com
Email: [email protected]
Product Usage Instructions
- Before installation, ensure you have all the necessary
components included in the kit and read the user manual
thoroughly. - Cutting Air Lines:
- Use a sharp knife or a hose cutter to make clean, square cuts
on the air lines. - Do not use scissors or wire cutters, as they may deform the air
line. - Ensure the lines are not cut at an angle.
- Use a sharp knife or a hose cutter to make clean, square cuts
- Installing Air Lines:
- Ensure the minimum bend radius for the 1/4 air line is
maintained at 1 inch (25mm). - Air lines are to be installed straight into fittings.
- Ensure the minimum bend radius for the 1/4 air line is
- Refer to the provided installation diagram for proper placement
of components. - Follow the step-by-step instructions in the user manual to
install the kit onto your motorcycle’s suspension system. - Once installed, use the air pressure adjustment feature
according to your desired riding preferences.
6511 N 54th St Tampa, FL 33610
+1 (813) 783-8058 Fax: +1 (813) 783-2407
MOTORCYCLE AIR RIDE SUSPENSION MODIFICATION KIT INSTALLATION DIAGRAM
www.hornblasters.com
*air fitting / shocks not included
[email protected]
6511 N 54th St Tampa, FL 33610
+1 (813) 783-8058 Fax: +1 (813) 783-2407
MOTORCYCLE AIR RIDE SUSPENSION MODIFICATION KIT INSTALLATION DIAGRAM
CUTTING AIR LINES
Use a sharp knife or a hose cutter and make clean, square cuts. Do not use scissors or wire cutters because these tools will deform the air line. Do not cut the lines at an angle.
The minimum bend radius for 1/4″ air line is 1″ (25mm). Air lines are to be installed straight into fittings.
· It is recommended to use a fuse holder in between the battery positive wire and the toggle switch. A 20-amp fuse is the ideal size for this air compressor.
· Make sure to disconnect the negative battery terminal before wiring anything to the battery. This will ensure nothing is damaged during the installation process.
· Double-check that your air lines aren’t rubbing or being pinched when inflating/deflating the bags on your bike. Fully inflate/deflate your shocks and check for rubbing or clearance issues with the air line.
· Use soapy water or a cleaning solution to check for leaks. Spray down each airline connection and inspect for bubbles. Bubbles forming up indicates that a small leak is present.
· Be careful not to over-tighten the 1/8″ x 1/4″ adapter fitting too tight into the compressor. This can cause issues with the check valve on the compressor. 12~15 Ft. Lbs. Maximum.
