Sea Breeze Cantilever Umbrella
Product Information
The product consists of the following parts:
- Umbrella
- Umbrella Base
- Sandbag
- Umbrella Fans With Lights x3
The product requires 3 AA batteries for each fan, totaling 9 AA
batteries (not included).
The product comes with a wrench, 4 bolts, and 4 washers for
assembly.
Manufacturer: BL83052
Country of Origin: Made in China | Designed in the USA
For more information, visit www.berninifountains.com
Product Usage Instructions
- Attach the Umbrella Base Mount to the Cross Base using the
provided 4 bolts and washers (Figure 1). - Attach the Upper Umbrella shade to the Base and tighten the 2
screws indicated by arrows (Figure 2). - Place the filled Sandbag over the Cross Base (Figure 3). Note:
When filled with sand, the Sandbag will be very heavy, so it is
strongly recommended to use caution and have a 2-person lift. - Pull the hand lever down to open the shade (Figure 4).
- Slide in the secure pin to lock the shade open (Figure 5).
- Use the fan hooks to place fans in desired spots on the metal
ribs of the shade structure (Figure 6). - Insert 3 AA batteries into each fan, totaling 9 AA batteries
(not included). - Adjust the fan to the desired angle.
- Press the power button on the fan to cycle through the
following sequences: First press: Fan On Only, Second press: Bright
Lite only, Third Press: Fan + Ambient Light, Fourth Press:
Off.
For moving and lifting the product, use the handles on each side
and it is recommended to have a 2-person lift (Figure 7).
For any warranty concerns, refer to the limited one-year
warranty provided by BL83052.
To access the latest version of these instructions, scan the QR
code provided.
Umbrella Parts:
Umbrella
Umbrella Base
Umbrella Base
Sandbag
Sea Breeze Umbrella Instructions
Umbrella Assembly Instructions:
Figure 1
www.berninifountains.com
Figure 3
1
2
3
4
Figure 2
Figure 4
Attach Umbrella Base Mount
To Cross Base (4 Bolts and Washers)
Attached Upper Umbrella shade to Base & Tighten the 2 screws (Arrows)
Place Filled Sandbag OVER Cross Base
Pull hand lever down to open shade
Wrench, 4-Bolts & 4-Washers Included
Umbrella Fans With Lights X3
3-AA Batteries FOR EACH FAN 9-AA TOTAL (Not Included)
secure pin to lock the shade open
Figure 5
** Please Note: Sand Bag once filled with sand WILL be very heavy and it is strongly recommended to use caution and use a 2 person lift **
IStep 1: Attach Umbrella Base Mount To Cross Base (4 Bolts & Washers) (Figure 1).
Step 2: Attached Upper Umbrella shade to Base & Tighten the 2 screws (Arrows) (Figure 2).
Step 3: Place Filled Sandbag OVER Cross Base (Figure 3). Step 4: Pull hand lever down to open shade (Figure 4).
Step 5: slide in Secure pin to lock the shade open (Figure 5)
Step 6: use the fan hooks to place fans in desired spots on the metal ribs of the structure of the shade (Figure 6). Uses 3-AA Batteries PER FAN, 9-AA Batteries Total (Not Included),
Step 7: Adjust Fan to desired angle. Power button fan sequence: first press: Fan On Only Second press: Bright Lite only Third Press: Fan + Ambient Light Fourth Press: Off
January 2023 © Yeiser Research & Development LLC and Bernini Fountains® Trade names, product names and logos used in this document are the trademarks or registered trademarks of Yeiser Research & Development LLC, Santee, CA 92071
Umbrella Assembly Instructions:
Base Sandbag
Sea Breeze Umbrella Instructions
www.berninifountains.com
hook & loop/ buckle
open sandbag flap and pour in all purpose sand (75 LBS Max)
Adustable Angle
use the fan hooks to place fans in desired spots on
the metal ribs of the structure of the shade
EACH Fan Uses 3 AA Batteries 9 AA BATTERIES
TOTAL (Not Included)
Scan this QR code for the latest version of these
instructions
Use Handles on each side to move and lift
(2 person lift recommended)
Figure 6
Figure 7
Power button fan sequence: first press: Fan On Only Second press: Bright Lite only Third Press: Fan + Ambient Light Fourth Press: Off
BL83052 LIMITED ONE YEAR WARRANTY
This warranty gives you specific legal rights and you may also have other rights which vary from state to state. This product has a one year limited warranty on all materials and workmanship. Bernini® warrants the original purchaser of this product that the product will be free from manufacturing defects in workmanship and material for a period of one (1) year from the date of original purchase. If within one (1) year this product fails due to defect in material or workmanship, Bernini® will repair, replace or supply any defective part at their discretion. The purchaser must contact Bernini® and provide a description of the defective part, including digital pictures if requested, with this original purchase documentation as validation of warranty coverage. This warranty does not cover or apply to: (a) damage to the product due to misuse, mishandling, and abuse, (b) products not used in accordance with instructions, (c) product not assembled or installed according to instructions, and (d) normal wear and tear. Call us for assistance at +1 (619) 449-2392 or you can email or mail us at: 9545 Pathway Street, Santee, CA 92071, [email protected], Our Customer Care Department is available: Monday – Friday 8:30am to 4:00pm PST / 11:30am – 7:00pm EST
Please read first before returning: Please call us for assistance at 1-619-449-2392 or email us at [email protected]. Our Customer Care Department is available: Monday – Friday 8:30am to 4:00pm PST, 11:30am to 7:00pm EST. If you have any questions regarding assembly, parts, or operation, please visit our website at www.berninifountains.com. You will find instructional videos on how to assemble and operate your fountain, and keeps you up to date on our newest products. You can also email us with any questions you have. This product comes with a one year limited warranty against materials and workmanship.
Santee, California 92071 | World Wide Patents Pending | Email: [email protected] | On the web: www.berninifountains.com Facebook & Pinterest: Bernini Fountain Company | Instagram: @berninifountains Twitter: @yrdllc © Yeiser Research & Development, LLC; 2023. All rights reserved.
Made in China | Designed in the USA
001355 BFSBUI rev v1a us
