Jonathan Y Jyl7128c Mario 22 Inch 1 Light Modern Contemporary Instruction Manual

JYL7128C Mario 22 Inch 1 Light Modern Contemporary

Product Information

The product is a Model JYL7128 lamp. It comes with a mounting
bracket, wire connector, canopy, machine screws, ground screw, and
metal plate. The lamp has an external flexible cable or cord that
cannot be replaced. The lamp measures 5H/ 30Lx4.375Wx3.125H.

Product Usage Instructions

Warning: Inspect the item carefully before
attempting to install. If there is any damage or obvious defect, do
not install. The item may not be returned once it has been
installed.

Care and Maintenance: To clean the outside of
the fixture, use a dry or slightly dampened clean cloth (use the
surface of the fixture). To clean the inside of the fixture, first
disconnect power to the fixture by turning off the circuit breaker
or fuse at the fuse box. Next, use a dry or slightly dampened clean
cloth (use clean water, never a solvent) to wipe the interior
surface of the fixture. Do not use any cleaners with chemical,
solvents or harsh abrasives. Use only a dry soft cloth to dust or
wipe carefully.

Notice & Important Safety Instructions:

• Please make sure that you have all parts indicated before you
  begin assembly of this item
• This item should be assembled on a soft surface to prevent
  scratching the finish during assembly
• To reduce the risk of fire, electrical shock or injury to
  persons or property, please follow the guideline below for safe use
  and installation
• The external flexible cable or cord of this lamp cannot be
  replaced. If the cord is damaged, the lamp shall be destroyed

Part List and Hardware List:

Preparation: Before beginning assembly of the
product, make sure all parts are present. Compare parts with the
package contents list and hardware contents list. If any part is
missing or damaged, do not attempt to assemble the product.
Estimated assembly time is 20 minutes.

Assembly Instructions:

1. Fix the mounting bracket(B) to the outlet box with mounting
   screw(F).
2. Make wire connections, with wire connectors(A), following the
   reference chart listed below:
   Connect Hot, Black or Red Outlet Supply Wire to Black Parallel Cord
   (round & smooth)
   Connect Neutral, White Outlet Supply Wire to White Parallel Cord
   (square & ridged)
   Clear, Brown, Gold or Black without Tracer (colored stripes)
   Clear, Brown, Gold or Black with Tracer (colored stripes)
   Insulated Wire (not green) with copper metal conductor
   Insulated Wire (not green) with Silver metal conductor
   Note: When parallel wire (SPT I & SPT II) is used. The
   neutral wire is square shaped and ridged and the hot wire will be
   round in shape and smooth. ( See Illustration on the left.
   )
3. Grounding Instructions:
   a) For installation in the United States: Wrap ground wire from
   outlet box around green ground screw(E) on mounting bracket, no
   less than 2 from wire end. Tighten ground screw. If fixture is
   supplied with a ground wire, connect to outlet ground wire with a
   wire connector.
   b) For installation in Canada: If fixture is supplied with ground
   wire, wrap ground wire around green grounding screw on mounting
   bracket. Tighten ground screw.
4. Carefully remove packaging from fixture, fix the canopy(D) to
   bracket(B) using machine screw(C).

Enjoy Your Lamp!

WARNING
INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.

CARE AND MAINTENANCE

To clean the outside of the fixture, use a dry or slightly dampened clean cloth (use the surface of the fixture.
To clean the inside of the fixture, first disconnect power to the fixture by

clean water,
turning off

never a solvent) to wipe
the circuit breaker or

Model JYL7128
bPyrroedmuocvtiDngimtheensio

fuse at the fuse box. Next, use a dry or slighly damperned clean clorth (use clean water, never a solvent) to wipe the

interior surface of the fixture.

Do not use any cleaners with chemical, solvents or harsh abrasives. Use only a dry soft cloth to dust or wipe carefully.

8C/JYL7129A
5″H/ 30″Lx4.375″Wx3.125″H
5

NOTICE & IMPORTANT SAFETY INSTRUCTIONS
* Please make sure that you have all parts indicated before you begin assembly of this item * This item should be assembled on a soft surface to prevent scratching the finish during assembly * To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below for safe use
and installation
* The external flexible cable or cord of this lamp cannot be replaced
If the cord is damaged, the lamp shall be destroyed

Part List and Hardware List

PIECE DESCRIPTION PICTURE QUANTITY PIECE DESCRIPTION PICTURE QUANTITY

A wire connector

mounting

B

bracket

C machine screw

3X

E

ground screw

1X

1X

F mounting screw

2X

2X

G the metal plate

2X

D

canopy

1X

12

PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 20 minutes.
1. Fix the mounting bracket(B) to the outlet boxmwoituhnting scre(wF). 2. Make wire connections, with wire connectors(A), following the reference chart listed below.

Connect, Hot, Black or Red Outlet Supply Wire to:
Black * Parallel Cord (round & smooth)

Connect, Neutral, White Outlet Supply Wire to:
White * Parallel Cord (square & ridged)

Clear, Brown, Gold or Black without Tracer (colored stripes) Clear, Brown, Gold or Black with Tracer (colored stripes)

Insulated Wire (not green) with copper metal conductor Insulated Wire (not green) with Silver metal conductor

*Note: When parallel wire ( SPT I & SPT II ) is used. The neutral wire is square shaped and ridged and the hot wire will be round in shape and smooth. ( See Illustration on left. )

Grounding Instructions:

a) For installation in the United States: Wrap ground wire from outlet box around green

ground screw(E) on mounting bracket, no less than 2″ from wire end. Tighten ground screw.

If fixture is supplied with a ground wire, connect to outlet ground wire with a wire connector.

b) For installation in Canada: If fixture is supplied with ground wire, wrap ground wire

D C F GE B

A

around green grounding screw on mounting bracket. Tighten ground screw.

3. Carefully remove packaging from fixture, fix the canopy(D) to bracket(B) usminagchine screw(C).

ENJOY YOUR LAMP

22
