Product Information

The product is SPB08, a low voltage landscape fixture for
outdoor use. It has a rated voltage of 12V AC/DC and must be
installed in accordance with all local codes and ordinances. The
fixture comes with a lifetime warranty, which can be claimed with
proof of purchase. The warranty will be void if there is any damage
due to improper usage or modification to the fixture.

Important Safety Instructions

The fixture is hot, so caution must be taken while handling it.
To reduce the risk of fire or injury to persons, it is important to
comply with the instructions in the manual. Failure to do so may
increase the risk of damage or injury and will void the
warranty.

Caution

The fixture(s) must not be installed within 10 feet of a pool,
spa, or fountain.

Installation Instructions

To ensure optimal performance and safety, it is important to use
the fixture ONLY with a low voltage landscape transformer. This
transformer reduces the voltage from 120V to 12V, making it safe
and suitable for outdoor use. When installing the fixture(s),
follow these instructions carefully:

Turn off the power before installation.
Use WN12 waterproof wire nuts (sold separately) for optimal
connectivity.
Attach the fixture(s) wires to the main cable connector
suitable for direct burial and use waterproof wire nuts. WN12 (Sold
separately).
Dig a small hole and insert the spike into the ground, ensuring
it is vertical and firm for secure and stable mounting.
Adjust the light angle.
Turn on the power.

We strongly recommend that the main cable from the transformer
be buried underground for safety reasons. Additionally, please be
sure not to exceed the maximum wattage on the fixture(s) to prevent
any damage or hazards. Connect the wires using WN12 (Sold
separately).

For more information, visit www.ABBALightingUSA.com.

View Fullscreen

SPB08
INSTALLATION GUIDE
www.ABBALightingUSA.com

RATED VOLTAGE 12V AC/DC
Congratulations on your purchase of this high-quality product! We want to ensure that you have the best possible experience with it, so we kindly ask that you take a moment to carefully read and follow all instructions before assembly, installation, and use. By doing so, you’ll not only guarantee correct function and safety, but also optimize the full potential of this exceptional product. Thank you for choosing us as your trusted provider of top-notch products – we truly appreciate your business!
IMPORTANT SAFETY INSTRUCTIONS LIGHTEN LAMP IS HOT!
WARNING: TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS:
Please exercise caution when using the lamp, as it tends to HEAT up rapidly. We recommend taking necessary safety measures to ensure optimal usage. For your safety, please refrain from touching the HOT lens, guard, or enclosure. We recommend waiting for the product to cool down before handling it. To prevent any fire hazards, please ensure that the lamp is kept away from materials that may easily catch fire. We appreciate your cooperation in maintaining a safe and secure environment. For safety reasons, we recommend that only a qualified professional install this electrical product. Before attempting to install this unit, ensure all power connections are off for your own safety.
WARRANTY
We stand behind the quality of our product and offer a Lifetime warranty. Kindly ensure that you keep the proof of purchase as it will be required for any warranty claims. Warranty will be void if there is any damage due to improper usage or modification to the fixture.
Failure to comply with the instruction in this manual may increase the risk of damage or injury and will void warranty.
www.ABBALightingUSA.com

CAUTION:
fixture(s) must be installed in accordance with all local codes and ordinances. Do not instal within 10 feet of a pool, spa or fountain

INSTALLATION INSTRUCTION
To ensure optimal performance and safety, it is important to use our fixtures ONLY with a low voltage landscape transformer. This transformer reduces the voltage from 120V to 12V, making it safe and suitable for outdoor use.
When installing the fixture(s), please follow these instructions carefully:
1. Before installation, please ensure that the power is turned off for your safety.
2.To establish a dependable and enduring electrical connection between fixture wires and the main line in outdoor or underground installations, it is essential to select a suitable main cable connector designed for direct burial. This connector should be chosen based on its ability to withstand environmental conditions, resist moisture and corrosion, and provide robust insulation. By adhering to industry standards and best practices, including proper wire stripping and secure fastening techniques, a reliable connection can be established, ensuring optimal performance, safety, and longevity of the system.
We recommend using WN12 waterproof wire nuts (sold separately) for optimal connectivity.
3. Attach the fixture(s) wires to the main cable connector suitable for direct burial and use waterproof wire nuts. WN12 (Sold separately).
4. For a secure and stable mounting, dig a small hole and insert the spike into the ground, ensuring it is vertical and firm.
5. Adjust the light angle.
6. Turn on the power.
We strongly recommend that the main cable from the transformer be buried underground for safety reasons. Additionally, please be sure to avoid exceeding the maximum wattage on the fixture(s) to prevent any damage or hazards.

Connect the wires using WN12 (Sold separately)

Main Line
