SASE Wire Shelving

Product Information: Seismic Wire Shelving

These instructions are for the installation and usage of Seismic
Wire Shelving. The Seismic Wire Shelving can be used with Metro
Super Erecta, Super Adjustable Super Erecta, and qwikSLOT to
connect the product to the floor. The sway braces are optional on
Super Erecta and Super Adjustable. However, qwikSLOT sway braces
are required on qwikSLOT. The seismic foot plates and sway braces
in this document can be used for site-specific approvals. Anchors,
however, are not included.

List of Components

The following is a list of components for the Single Unit and
Back-to-Back Unit:

Product Usage Instructions: Seismic Wire Shelving

Single Unit (SES / SASE)

Two people are required to assemble the unit. The following are
the instructions for usage:

1. Assemble your shelving unit as described in the instruction
   sheet packed with the shelving.
2. Sway braces are optional on Super Erecta and Super
   Adjustable.
3. Sway brace clamp position: Spread the clamp and fit on all sway
   brace clamps.
4. Anchor the foot plates to the floor using approved diameter
   expansion anchors or thru-bolts (not provided).
5. Be certain to follow any site-specific or local
   requirements.

Back-to-Back Unit (SES / SASE)

Two people are required to assemble the unit. The following are
the instructions for usage:

1. Assemble your shelving unit as described in the instruction
   sheet packed with the shelving.
2. Sway braces are optional on Super Erecta and Super
   Adjustable.
3. Refer to page 3 for installation of back sway braces on single
   unit without back sway braces.
4. Refer to page 3 for installation of end sway braces on single
   unit.
5. Anchor the foot plates to the floor using approved diameter
   expansion anchors or thru-bolts (not provided).
6. Be certain to follow any site-specific or local
   requirements.

Note: Follow site-specific or local requirements when installing
shelving.

INSTRUCTIONS FOR USE
INSTALLATION GUIDE FOR SEISMIC WIRE SHELVING
(For installations not requiring OSHPD pre-approval. These seismic components may be used for site specific approvals.)

SINGLE UNIT

SES
Sway braces are OPTIONAL on Super Erecta and Super Adjustable.

BACK-TO-BACK UNIT

qwikSLOT Sway braces are REQUIRED on
qwikSLOT.
NOTE: The seismic foot plates and sway braces in this document can be used with Metro Super Erecta, Super Adjustable Super Erecta and qwikSLOT to connect the product to the floor. Anchors are not included.

SEISMIC WIRE SHELVING — INSTRUCTIONS FOR USE

NOTE: Read the following prior to assembling your shelving unit. · Your shelving must be assembled as per any site-specific or local requirements. · Assemble the first shelf a maximum of 7″ from the floor. · There must be a clearance of at least 18″ below sprinkler systems. · Each shelving unit, whether single or back-to-back, is a “stand-alone unit” it does not connect
to other shelving units or walls. · Shelving must be assembled using designated seismic posts only.
Reference product spec sheet# 10.16.
LIST OF COMPONENTS
F
A

B

C

D

E

GH

I

J

ITEM A
B C D E J

SINGLE UNIT
DESCRIPTION End Sway Brace Back Sway Brace Sway Brace Clamp 3/8 Hex Bolt 3/8 Hex Nut TEK Screw Foot Plate Single Hole

QTY. 4 2 12 12 12 12 4

BACK-TO-BACK UNIT

ITEM DESCRIPTION

QTY.

A End Sway Brace

4

Back Sway Brace

2

B Sway Brace Clamp

12

C 3/8 Hex Bolt

12

D 3/8 Hex Nut

12

E TEK Screw

12

F Post Clamp

6

G 10-24 Nut

6

H 10-24 Screw

6

I

Washer

12

J Foot Plate Single Hole

8

2 www.metro.com

L01-152 REV C 07/21

SEISMIC WIRE SHELVING — INSTRUCTIONS FOR USE

SINGLE UNIT (SES / SASE)
Two People Required to Assemble Unit.
NOTE: Sway braces are OPTIONAL on Super Erecta and Super Adjustable.

1

2

3 SWAY BRACE CLAMP POSITION 4

Post
4x

ASSEMBLE YOUR SHELVING UNIT AS DESCRIBED IN THE INSTRUCTION SHEET PACKED WITH THE
SHELVING

Sway Brace Clamp

Foot Plate

BE CERTAIN TO FOLLOW ANY
SITE-SPECIFIC OR LOCAL REQUIREMENTS

12x

5
End Sway Brace

6
Nut

SPREAD THE CLAMP AND FIT

Back

Bolt

Sway

Brace

7
ON ALL SWAY BRACE
CLAMPS

8

9

TEK Screw
3/16 Dia Hole

3 www.metro.com

10
ANCHOR THE FOOT PLATES TO THE FLOOR USING APPROVED DIAMETER EXPANSION ANCHORS OR THRU-BOLTS (NOT PROVIDED). NOTE: For site-specific approval the anchorage to the structure must be independently verified for each installation by the Structural Engineer of Record. The Engineer of Record must also verify that the structure itself is adequate for applied loads.
L01-152 REV C 07/21

SEISMIC WIRE SHELVING — INSTRUCTIONS FOR USE

BACK-TO-BACK UNIT (SES / SASE)
Two People Required to Assemble Unit.
NOTE: Sway braces are OPTIONAL on Super Erecta and Super Adjustable.

1

2

3

4

Post
4x
Foot Plate

ASSEMBLE YOUR SHELVING UNIT AS DESCRIBED IN THE INSTRUCTION SHEET PACKED WITH THE
SHELVING
BE CERTAIN TO FOLLOW ANY SITE-SPECIFIC OR LOCAL REQUIREMENTS

REFER TO PAGE3 FOR INSTALLATION OF
BACK SWAY BRACES ON SINGLE UNIT

Single Unit
without Back Sway Braces

5

Clamp

Washer 10-24 Nut

8

6x
10-24 Screw

Single Unit with Back Sway
Braces

6
REFER TO PAGE3 FOR INSTALLATION OF END SWAY BRACES ON SINGLE UNIT
7
ANCHOR THE FOOT PLATES TO THE FLOOR USING APPROVED DIAMETER EXPANSION ANCHORS OR THRU-BOLTS (NOT PROVIDED).

NOTE: For site-specific approval the anchorage to the structure must be independently verified for each installation by the Structural Engineer of Record. The Engineer of Record must also verify that the structure itself is adequate for applied loads.

NOTE: Follow site-specific or local requirements when installing shelving.

THIS COMPLETES THE ASSEMBLY OF BACK-TO-BACK UNIT

4 www.metro.com

L01-152 REV C 07/21

SEISMIC WIRE SHELVING — INSTRUCTIONS FOR USE
qwikSLOT
Assemble your qwikSLOT shelving unit as described in the instruction sheet packed with the shelving.
qwikSLOT Assembly Specific Rules: · Locking clips must be used with the qwikSLOT shelves (9985QSL). · Top and Bottom Shelves MUST be round collar Super Erecta style shelving. · Follow the assembly instructions included with the qwikSLOT shelves and posts.

SES SES

qwikSLOT Locking
clip

5 www.metro.com

L01-152 REV C 07/21

SEISMIC WIRE SHELVING — INSTRUCTIONS FOR USE

SINGLE UNIT (qwikSLOT) Two People Required to Assemble Unit.
NOTE: Sway braces are REQUIRED on qwikSLOT.

1
Post
4x
Foot Plate
5
End Sway Brace

2

3 SWAY BRACE CLAMP POSITION 4

ASSEMBLE YOUR SHELVING UNIT AS DESCRIBED IN THE INSTRUCTION SHEET PACKED WITH THE
SHELVING
BE CERTAIN TO FOLLOW ANY SITE-SPECIFIC OR LOCAL
REQUIREMENTS
6

Sway Brace Clamp
12x
SPREAD THE CLAMP AND FIT

Nut Bolt

Back Sway Brace

7

8

9

ON ALL SWAY BRACE
CLAMPS

3/16 Dia Hole

TEK Screw

6 www.metro.com

10
ANCHOR THE FOOT PLATES TO THE FLOOR USING APPROVED DIAMETER EXPANSION ANCHORS OR THRU-BOLTS (NOT PROVIDED). NOTE: For site-specific approval the anchorage to the structure must be independently verified for each installation by the Structural Engineer of Record. The Engineer of Record must also verify that the structure itself is adequate for applied loads.
L01-152 REV C 07/21

SEISMIC WIRE SHELVING — INSTRUCTIONS FOR USE

BACK-TO-BACK UNIT (qwikSLOT) Two People Required to Assemble Unit.
NOTE: Sway braces are REQUIRED on qwikSLOT.

1

2

3

4

Post
4x
Foot Plate

ASSEMBLE YOUR SHELVING UNIT AS DESCRIBED IN THE INSTRUCTION SHEET PACKED WITH THE
SHELVING
BE CERTAIN TO FOLLOW ANY SITE-SPECIFIC OR LOCAL REQUIREMENTS

REFER TO PAGE6 FOR INSTALLATION OF
BACK SWAY BRACES ON SINGLE UNIT

Single Unit
without Back Sway Braces

Single Unit with Back Sway
Braces

5

Clamp

10-24 Washer Nut

8

6x
10-24 Screw

6
REFER TO PAGE6 FOR INSTALLATION OF END SWAY BRACES ON SINGLE UNIT
7
ANCHOR THE FOOT PLATES TO THE FLOOR USING APPROVED DIAMETER EXPANSION ANCHORS OR THRU-BOLTS (NOT PROVIDED).

NOTE:
For site-specific approval the anchorage to the structure must be independently verified for each installation by the Structural Engineer of Record. The Engineer of Record must also verify that the structure itself is adequate for applied loads.

NOTE:
Follow site-specific or local requirements when installing shelving.

THIS COMPLETES THE ASSEMBLY OF BACK-TO-BACK UNIT

7 www.metro.com

L01-152 REV C 07/21

SEISMIC FOOT PLATE WITH SINGLE HOLE
* Save this document for future application, load rating and/or safety reference.
© 2021 InterMetro Industries Corporation, Wilkes-Barre, PA 18705 L01-152 REV C 07/21
